Adding new Ristic microphysics scheme #1308
Closed
Conversation
This file contains hidden or bidirectional Unicode text that may be interpreted or compiled differently than what appears below. To review, open the file in an editor that reveals hidden Unicode characters.
Learn more about bidirectional Unicode characters
|
Typically we do not accept new physics options this way.
You need to go through the physics review panel for a new official option.
An alternative is to
create a feature branch that you can maintain and support yourself that is
not part of the official
physics.
https://www2.mmm.ucar.edu/wrf/users/physics_review.php
…On Thu, Oct 29, 2020 at 7:24 AM Nikola Ristic ***@***.***> wrote:
@Nikolar97 <https://github.com/Nikolar97> requested review from
@wrf-model/physics on: #1308 <#1308>
Adding a new microphysics as a code owner.
—
You are receiving this because your review was requested.
Reply to this email directly, view it on GitHub
<#1308 (comment)>, or
unsubscribe
<https://github.com/notifications/unsubscribe-auth/AEIZ77G2WR5ZZSTBTKYMALTSNFUKFANCNFSM4TDXJAHA>
.
|
davegill
reviewed
Feb 9, 2021
| package p3_1category_nc mp_physics==51 - moist:qv,qc,qr,qi;scalar:qnc,qni,qnr,qir,qib;state:re_cloud,re_ice,vmi3d,rhopo3d,di3d,refl_10cm,th_old,qv_old | ||
| package p3_2category mp_physics==52 - moist:qv,qc,qr,qi,qi2;scalar:qnc,qni,qnr,qir,qib,qni2,qir2,qib2;state:re_cloud,re_ice,vmi3d,rhopo3d,di3d,vmi3d_2,rhopo3d_2,di3d_2,refl_10cm,th_old,qv_old | ||
| package morr_tm_aero mp_physics==40 - moist:qv,qc,qr,qi,qs,qg;scalar:qnc,qni,qns,qnr,qng;state:rqrcuten,rqscuten,rqicuten,EFCG,EFIG,EFSG,WACT,CCN1_GS,CCN2_GS,CCN3_GS,CCN4_GS,CCN5_GS,CCN6_GS,CCN7_GS,re_cloud,re_ice,re_snow,mskf_refl_10cm | ||
| package ivanr_micro mp_physics==150 - moist:qv,qc,qr,qs;scalar:qt;state:cld,tw2,pw2,qw2,f_snow |
There was a problem hiding this comment.
@dudhia @weiwangncar
Is there a better MP scheme value than 150?
There was a problem hiding this comment.
@davegill
We just used a random one that does not overlap with the others, whatever value is free can be used if 150 is too big/not following a rule.
|
@Nikolar97 |
davegill
reviewed
Feb 9, 2021
Registry/Registry.EM_COMMON
Outdated
Comment on lines
1193
to
1197
| state real cld ikj misc 1 - r "CLD" "w2id " "" | ||
| state real tw2 ikj misc 1 - r "TW2" "w2id " "" | ||
| state real pw2 ikj misc 1 - r "PW2" "w2id " "" | ||
| state real qw2 ikj misc 1 - r "QW2" "w2id " "" | ||
| state real f_snow ikj misc 1 - r "F_SNOW" "w2id " "" |
There was a problem hiding this comment.
@Nikolar97
Please include a description of these fields with units. An example is the line directly above.
Since these are "r" restart variables, have you tested that you do indeed get reproducible results with a restart?
There was a problem hiding this comment.
@davegill
Added the descriptions to the fields in the EM_COMMON and NMM registry. The variables should be r, they were used in a similar way to other r fields in other custom schemes already in the model.
|
@weiwangncar @dudhia |
davegill
changed the title
|
Note that this is still awaiting WPRP approval and is not for V4.3.
qt is sometimes used as a sum of other things but can't be added to moist
to avoid double-counting in the drag.
…On Tue, Feb 9, 2021 at 2:39 PM Dave Gill ***@***.***> wrote:
@weiwangncar <https://github.com/weiwangncar> @dudhia
<https://github.com/dudhia>
Tangential to this PR ... why is "qt" (the total condensate mixing ratio)
part of scalar, and not moist? The units are kg/kg.
—
You are receiving this because you were mentioned.
Reply to this email directly, view it on GitHub
<#1308 (comment)>, or
unsubscribe
<https://github.com/notifications/unsubscribe-auth/AEIZ77DOH2CYSLZKPY4UYRTS6GTSFANCNFSM4TDXJAHA>
.
|
|
@davegill |
TYPE: text only KEYWORDS: improve MAD-WRF section of README.namelist SOURCE: internal + Pedro Jimenez DESCRIPTION OF CHANGES: Improve option description and refer to doc file LIST OF MODIFIED FILES: M run/README.namelist TESTS CONDUCTED: none needed
…#1517) TYPE: bug fix KEYWORDS: topo_wind option 1, data flag got_var_sso SOURCE: reported by Y. Zhang, fixed by internal DESCRIPTION OF CHANGES: Problem: topo_wind option 1 requires input field var_sso (variance of the subgrid scale orography). When program real is run, a logical variable got_var_sso is defined upon checking whether the variance field exists or not. In the model, both namelist option for topo_wind as well as this internal logical are required to use this topo_wind option. If got_var_sso is not found when the topo_wind option is requested, the model produces an error "topo_wind requires VAR_SSO data", even if the field VAR_SSO field itself exists in the input. When the model history file is used in a DA cycle, missing this logical causes the model to stop. Solution: The registry file is modified to add 'got_var_sso' to the history file. LIST OF MODIFIED FILES: M Registry/Registry.EM_COMMON TESTS CONDUCTED: The modification has been tested to show it corrects the problem reported. Jenkins tests are passing. RELEASE NOTE: Logical variable got_var_sso is added to the history file for cycling DA application for use with the topo_wind option.
… WRFDA (wrf-model#1528) Add mod_clddet_geoir.o as compilation dependency to da_radiance.o for WRFDA. TYPE: bug fix KEYWORDS: WRFDA,bug fix SOURCE: "Marc Honnorat (EXWEXs)" ISSUE: Fixes wrf-model#1527 LIST OF MODIFIED FILES: var/build/depend.txt RELEASE NOTE: Fixes compilation of WRFDA.
TYPE: text change KEYWORDS: units in Registry SOURCE: internal, Tzu-Chin Tsai (NTU) DESCRIPTION OF CHANGES: Problem: The units for 7 new NTU microphysics variables are incorrectly specified in Registry.EM_COMMON. Solution: This PR corrects them. LIST OF MODIFIED FILES: M Registry/Registry.EM_COMMON TESTS CONDUCTED: Text change only. No effect on results The Jenkins tests are all passing. RELEASE NOTE: Units specified in Registry are corrected for several NTU microphysics variables.
|
I am reminding the review panel to look at this scheme now. |
TYPE: bug fix KEYWORDS: eclipse module, radiation driver dependency SOURCE: internal DESCRIPTION OF CHANGES: Problem: The newly added module_ra_eclipse.F was not added to the dependency list of radiation driver. This sometimes causes compilation failures. Solution: Add module_ra_eclipse to radiation dependency list. LIST OF MODIFIED FILES: M main/depend.common TESTS CONDUCTED: - It is hard to test that there are no more intermittent build failures caused by this missing dependency. :) - Jenkins tests are passing. RELEASE NOTE: Adding module_ra_eclipse.o to radiation driver's dependency list to avoid occasional compilation failures.
TYPE: enhancement KEYWORDS: Local Climate Zones (LCZ), urban parameters, urban canopy models SOURCE: Matthias Demuzere (Ruhr University Bochum), Andrea Zonato (Trento University) DESCRIPTION OF CHANGES: Problem: The values in the current version of the URBPARM_LCZ.TBL are specific for Zonato et al. (2020), reflecting city properties in Italy. Some of these values should be more universal. Solution: Changing some of the urban parameter values, to make them more generic. These universal values are based upon the following published materials: Stewart ID, Oke TR. Local Climate Zones for Urban Temperature Studies. Bull Am Meteorol Soc. 2012;93(12):1879-1900. doi:10.1175/BAMS-D-11-00019.1 Stewart ID, Oke TR, Krayenhoff ES. Evaluation of the ‘local climate zone’ scheme using temperature observations and model simulations. Int J Climatol. 2014;34(4):1062-1080. doi:10.1002/joc.3746 Varentsov M, Samsonov T, Demuzere M. Impact of Urban Canopy Parameters on a Megacity’s Modelled Thermal Environment. Atmosphere (Basel). 2020;11(12):1349. doi:10.3390/atmos11121349 LIST OF MODIFIED FILES: M run/URBPARM_LCZ.TBL TESTS CONDUCTED: Only concerns some parameter value changes. Jenkins testing is all PASS. RELEASE NOTE: LCZ-specific urban canopy parameters values in URBPARM_LCZ.TBL are sourced from Stewart and Oke (2012), Stewart et al. (2014) and Varentsov et al. (2020) where available, and made more generic - the table values in 4.3 release are specific for Zonato et al. (2020). Still users are advised to check and adjust these for specific applications.
TYPE: bug fix KEYWORDS: dimension, module_bc, spec_bdytend_perturb* SOURCE: internal, Samm Elliott (TQI) DESCRIPTION OF CHANGES: Fixed a dimension error in perturbed bc routine Problem: Variables field_tend_perturb in spec_bdytend_perturb and field_scalar_perturb in spec_bdytend_perturb_chem should be dimensioned by jms:jme, but jms:kme was used. Solution: Fix the two dimension errors. ISSUE: For use when this PR closes an issue. Fixes wrf-model#1524 LIST OF MODIFIED FILES: M share/module_bc.F TESTS CONDUCTED: It would be difficult to design a test to catch this bug. The Jenkins tests are ok. RELEASE NOTE: Fixed a dimensional errors in subroutine spec_bdytend_perburb and spec_bdytend_perturb_chem in module_bc.F. This routine is used to perturb fields on the model lateral boundaries for stochastic processing, and only affects results if perturb_bdy or perturb_chem_bdy are not 0 and they are 0 by default.
TYPE: text only KEYWORDS: misspelling SOURCE: Piotr Kasprzyk (IETU Katowice) DESCRIPTION OF CHANGES: Problem: One misspelled letter in "required" word. Solution: Nothing was changed except for the wrong letter. LIST OF MODIFIED FILES: M Registry/Registry.NMM TESTS CONDUCTED: 1. No tests were conducted since this is text only. 2. Jenkins tests are all PASS.
…l#1566) TYPE: bug fix KEYWORDS: module_stoch, RAND_PERT_UPDATE arguments SOURCE: internal DESCRIPTION OF CHANGES: Problem: In the initialization of the rand_perturb=1 option, the arguments to RAND_PERT_UPDATE were wrong. The results would be that initially the stochastic perturbation had no cutoff standard deviations, but during the run this would have been corrected. Effect likely minor and generic rand_perturb option not used much. Solution: Correction so that argument list is same as from the call in first_rk_step_part2 LIST OF MODIFIED FILES: M dyn_em/module_stoch.F TESTS CONDUCTED: 1. mod has been tested - Judith Berner is OK 2. Jenkins is OK RELEASE NOTE: Fix in initialization for rand_perturb=1 option for the stochastic capabilities, due to an incorrect argument list. The effect is minor.
TYPE: text only KEYWORDS: README file, version_decl SOURCE: internal DESCRIPTION OF CHANGES: Update the top-level README file, and the inc/version_decl file with the correct version. LIST OF MODIFIED FILES: M README M inc/version_decl TESTS CONDUCTED: NA
Finalize WRFV4.3.1 by merging fixes from release-v4.3.1 branch onto master.
TYPE: bug fix KEYWORDS: HPE, CCE, syntax SOURCE: Tricia Balle (HPE) DESCRIPTION OF CHANGES: Problem: There were three types of syntax errors that were uncovered by the HPE CCE compiler. 1. Open statement used `action="append"`. 2. Multiple unary operators next to each other `*+` 3. Multiple unary operators next to each other `*-1`. Solution: 1. The correct usage is `position="append"`. 2. The developer agrees with the new modification to `GS3*+SASR1` was the original intent. 3. Typically, `*(-1)` is intended, and this is the case. Via some grep'ing, no other occurrences of `*+` or `*-` exist in the physics directory in the compilable source code. Syntactically OK source code with `/-` (such as for DATA statements) were the only compilable examples found. So, we fixed the above problems identified in this PR, and we could not find any other similar examples in the source code. LIST OF MODIFIED FILES: modified: phys/module_mp_nssl_2mom.F modified: phys/module_mp_ntu.F modified: phys/module_sf_noahmplsm.F TESTS CONDUCTED: 1. These fixes allow the WRF code to build with the CCE compiler. 2. Jenkins tests are all PASS. 3. One of the errors was a typo in the sink term of aggregates number from hail. A quick evaluation of its impact was quite minor from the 2D idealized simulation (the figure is not shown). RELEASE NOTE: A few syntax errors in NSSL, NTU, an NoahMP were fixed. Most compilers skipped over them. Either "small impact" or "no impact" for users for whom the code already compiled.
…of the net fuel load (wrf-model#1516) TYPE: bug fix KEYWORDS: fuel moisture initialisation, net fuel load computation, WRF-Fire SOURCE: Theodore M. Giannaros (National Observatory of Athens, Greece) DESCRIPTION OF CHANGES: Problem: Incorrect indexing in the initialization of fuel moisture content in subroutine `read_namelist_fire`, in WRF file `phys/module_fr_fire_phys.F`. Solution: Changed `fmc_gc_initial_value(3)=fmc_1000h` to `fmc_gc_initial_value(4)=fmc_1000h` in subroutine `read_namelist_fire`, in WRF file `phys/module_fr_fire_phys.F`. LIST OF MODIFIED FILES: M phys/module_fr_fire_phys.F TESTS CONDUCTED: 1. The correction applied resolved the erroneous initialization of both 1000h and 100h fuel moisture content. Prior to this correction, `fmc_gc_initial_value(3)=fmc_1000h` and no initialization was carried out for fmc_gc_initial_value(4). This resulted to erroneously setting `fmc_gc_initial_value(3)=fmc_1000h` and `fmc_gc_initial_value(4)=0` (was left uninitialized). Following the correction, both variables are correctly set (`fmc_gc_initial_value(3)=fmc_100h` and `fmc_gc_initial_value(4)=fmc_1000h`). 2. Jenkins is all PASS. RELEASE NOTE: Bug fix for fire module related to the initialization of 1000-h fuel moisture content due to an incorrect indexing assignment from the namelist entries for fuel classes.
TYPE: text only KEYWORDS: correct misspellings SOURCE: Piotr Kasprzyk (IETU Katowice) DESCRIPTION OF CHANGES: Problem: The "pressure" spelling was wrong. Solution: Words "pressure" were corrected. LIST OF MODIFIED FILES: M share/mediation_integrate.F M share/mediation_nest_move.F TESTS CONDUCTED: 1. Tests were not conducted, as this is a text only change. 2. Jenkins tests are all passing (as expected).
…1580) TYPE: bug fix KEYWORDS: ERA5, smooth_cg_topo, elevation data SOURCE: internal DESCRIPTION OF CHANGES: Problem: If a user does not include all of the correct ERA5 invariant files, then there could be no soil elevation field coming from the metgrid program. Without that field, the flag `flag_soilhgt` is not set. Then the real program will not generate any topo differences along the lateral boundary (when requested with smooth_cg_topo = T). This is a quiet failure, and difficult to track down. Solution: If the user asks to smooth the lateral boundary topo on d01, AND the user has no input soil elevation data from the first-guess model, then this is now a fatal error. LIST OF MODIFIED FILES: modified: dyn_em/module_initialize_real.F TESTS CONDUCTED: 1. The original intent of the option still works - smoothed topo on d01 along the outer few rows and columns. The first figure shows the change in topography. The second figure below shows which grid cells are impacted. Basically, these two figures show that topography smoothing still is available. <img width="1296" alt="Screen Shot 2021-11-05 at 11 27 03 AM" src="https://user-images.githubusercontent.com/12666234/140584624-40a71752-d718-44d3-8c3a-05f6fd710ee1.png"> <img width="1295" alt="Screen Shot 2021-11-05 at 11 45 57 AM" src="https://user-images.githubusercontent.com/12666234/140584653-f3546331-1c95-4ea3-a324-5f3a6e0cb3ee.png"> 2. By artificially setting the metgrid flags in a debugging mode within the real program, we can successfully emulate missing soil elevation data by setting flag_soilhgt = 0. Whether or not we artificially set the value, there is now a controlled stop to the real program. ``` -------------- FATAL CALLED --------------- FATAL CALLED FROM FILE: <stdin> LINE: 766 --- ERROR: NML option smooth_cg_topo=T, but no first guess soil elevation data ------------------------------------------- ``` 3. All jenkins tests are PASS. RELEASE NOTE: A fatal error in the real program is now issued when a user requests lateral boundary topography smoothing, but lacks the first-guess soil elevation data to do the weighted averaging of topography. Previously, this discrepancy was ignored, and the d01 high-resolution elevation data was quietly left undisturbed. We have seen this problem when a user chooses to initialize the model with ERA5 data, but when insufficient time invariant files are used.
TYPE: bug fix
KEYWORDS: configure, shell, echo
SOURCE: internal
DESCRIPTION OF CHANGES:
Problem:
When building with NetCDF that does not support compression, the warning statements that
are printed out are misaligned, due to missing trailing quotes at the end of some `echo` statements in the
`configure` script.
Solution:
Add those quotes back in.
LIST OF MODIFIED FILES:
modified: configure
TESTS CONDUCTED:
1. The printout is now aesthetically appealing. Initially we had a mortifying display of the word `echo`, and the
accompanying alignment disarray that would be associated with banal shell scripting encroaching upon a user's otherwise elevated build experience:
```
Please make sure NETCDF version is 4.1.3 or later and was built with
--enable-netcdf4
OR set NETCDF_classic variable
bash/ksh : export NETCDF_classic=1
echo csh : setenv NETCDF_classic 1
```
After much soul searching, an appropriate solution was uncovered, resulting in reduced messaging dissonance:
```
Please make sure NETCDF version is 4.1.3 or later and was built with
--enable-netcdf4
OR set NETCDF_classic variable
bash/ksh : export NETCDF_classic=1
csh : setenv NETCDF_classic 1
```
2. Jenkins is all PASS.
TYPE: no impact KEYWORDS: Chem, photolysis, history SOURCE: Jordan Schnell (NOAA) DESCRIPTION OF CHANGES: Remove photolysis rates not used by most modules from the default history stream. LIST OF MODIFIED FILES: M Registry/registry.chem TESTS CONDUCTED: None, remove history 1. Jenkins tests all PASS. RELEASE NOTE: In WRF Chem, remove photolysis rates from the default history stream (these photolysis rates are not used by most modules).
…total loading of all bins. (wrf-model#1573) TYPE: no impact KEYWORDS: dustload5, dust, GOCART, Chem SOURCE: Jordan Schnell (NOAA), Yaping Shao (Universität zu Köln) & Martina Klose (Karlsruhe Institute of Technology (KIT)) DESCRIPTION OF CHANGES: Changes the description of "dustload5" to be the load in size bin 5, not the total loading of all bins. LIST OF MODIFIED FILES: M Registry/registry.chem TESTS CONDUCTED: 1. Jenkins tests are all PASS.
TYPE: bug fix KEYWORDS: CLM, PCT_PFT SOURCE: internal DESCRIPTION OF CHANGES: Problem: CLM specific variable PCT_PFT appears in standard wrfout file, even if CLM option is not selected. Solution: The packaged variable name should be pct_pft_input, rather than pct_pft. LIST OF MODIFIED FILES: Registry/Registry.EM_COMMON TESTS CONDUCTED: 1. The change removes PCT_PFT from wrfout file when CLM option is not selected. 2. The Jenkins tests are all passing. RELEASE NOTE: Starting with release-v4.3, the CLM specific variable PCT_PFT appeared in standard wrfout file, even when the CLM option was not selected. A small modification to the standard Registry file removed this incorrectly output 3d array. Other than removing this innocuous zero-valued 3d array from the output stream, there is no other impact for users.
) TYPE: bug fix KEYWORDS: syntax, physics, *+ SOURCE: Patricia Balle (HPE) DESCRIPTION OF CHANGES: Problem: As in hash 7c6fd57, PR wrf-model#1577 "Syntax errors in physics routines: *- and *+", there is a single remaining example of the unary operators next to each other. Solution: The author agreed that the `*+` combination was supposed to be just `+`. I searched the WRF code for instances of this `*+` in PR wrf-model#1577. When I did not find any, I put back one of them from NTU code to make sure that my grep was working. It found that example, and no others that I cared about. I forgot to undo that change before the `git add`, `git commit`. LIST OF MODIFIED FILES: modified: phys/module_mp_ntu.F TESTS CONDUCTED: 1. Passes Cray compiler. 2. Jenkins tests are OK
TYPE: bug fix (?) KEYWORDS: WRFDA, CRTM, ftn compiler SOURCE: Jamie Bresch (NCAR) DESCRIPTION OF CHANGES: Problem: One of the CRTM modules does not compile with Cray Fortran : Version 12.0.3 with default or -O2 optimization. ftn -hnoomp -c -N1023 -f free -h byteswapio SOI_Module.f90 ERROR - Trying to add using unusual type properties op1_type :: <array[t$90] of real*8> op2_type :: <array[t$90] of real*8> Error message :: Optimization internal error Error detected :: File 'pdgcs/v_expr_pls.c', line 197 Optimizer built :: 2021-08-16 (production) File :: SOI_Module.f90 Function :: crtm_soi_ad at or near line :: 656 Solution: Edit CRTM makefile to compile SOI_Module.f90 with -O1 flag when ftn compiler is used. LIST OF MODIFIED FILES: M var/external/crtm_2.3.0/libsrc/makefile TESTS CONDUCTED: 1. WRFDA builds on Cheyenne crayenv after the fix. (note that configure.wrf has to be edited to uncomment two lines that specify LIB_LOCAL as noted in 207c89e) 2. Jenkins tests passed. RELEASE NOTE: N/A
TYPE：enhancement KEYWORDS: ARM DESCRIPTION OF CHANGES: Problem: There are no ARM-only stanzas in arch/configure.defaults. As the suggestion from wrf-model#1535 , we need a separate PR for ARM specific update. Solution: Edit the arch/configure.defaults file and add a stanza for aarch64 and armv7l, using the GNU compiler options. The default optimization is -03, up from the usual -02. On two 36-h nested simulations on a raspberry pi, the difference is a consistent 3% speed increase across the radiation and non-radiation time steps. This used CONUS, so the -03 option seems reasonably robust with the GNU compiler. LIST OF MODIFIED FILES: M arch/configure.defaults RELEASE NOTE: Added a new stanza that is only for ARM processors (right now aarch64 and armv7l) with GNU.
TYPE: bug fix KEYWORDS: PBL, LES SOURCE: internal DESCRIPTION OF CHANGES: Problem: A few PBL schemes include scalar components that are advected. These fields are required on all domains. With an LES option on a finer domain, that grid does not have the additional scalar component, which causes a segfault when trying to access that field. Solution: Restrict what PBL schemes are eligible for use with the LES (no PBL) option. ISSUE: Fixes wrf-model#1514 LIST OF MODIFIED FILES: modified: Registry/Registry.EM_COMMON modified: share/module_check_a_mundo.F TESTS CONDUCTED: 1. When an incompatible CG PBL and FG LES are selected, the code successfully stops. ``` &physics bl_pbl_physics = 5, 0, --- ERROR: LES PBL on fine grid does not work with CG PBL option 5 Choose a CG PBL option without any scalar components Fix bl_pbl_physics in namelist.input Alternatively, remove all of the packaged variables from the CG PBL selection -------------- FATAL CALLED --------------- FATAL CALLED FROM FILE: <stdin> LINE: 2523 NOTE: 1 namelist settings are wrong. Please check and reset these options ``` ``` &physics bl_pbl_physics = 6, 0, --- ERROR: LES PBL on fine grid does not work with CG PBL option 6 Choose a CG PBL option without any scalar components Fix bl_pbl_physics in namelist.input Alternatively, remove all of the packaged variables from the CG PBL selection -------------- FATAL CALLED --------------- FATAL CALLED FROM FILE: <stdin> LINE: 2523 NOTE: 1 namelist settings are wrong. Please check and reset these options ``` ``` &physics bl_pbl_physics = 16, 0, --- ERROR: LES PBL on fine grid does not work with CG PBL option 16 Choose a CG PBL option without any scalar components Fix bl_pbl_physics in namelist.input Alternatively, remove all of the packaged variables from the CG PBL selection -------------- FATAL CALLED --------------- FATAL CALLED FROM FILE: <stdin> LINE: 2523 NOTE: 1 namelist settings are wrong. Please check and reset these options ``` 2. All jenkins tests are a PASS. RELEASE NOTE: A test was introduced to stop the incorrect combination of particular PBL schemes on coarser grids with the LES PBL option selected on a finer grid. Previously, this problem caused an inconsistent number of variables on the CG and FG, which caused segmentation faults when trying to do feedback or advection of unavailable fields.
…el#1598) TYPE: enhancement KEYWORDS: time-varying greenhouse gases, RRTMG-sw SOURCE: internal DESCRIPTION OF CHANGES: Problem: Time-varying greenhouse gases were added to the WRF code in 2013. It was added to CAM longwave and shortwave options. But it was only added to RRTMG longwave scheme. Solution: 1. After consulting with the original contributors of the code, the time-varying gases are added to the RRTMG-sw and RRTMG-swf code in this PR. 2. Also included in this PR is to remove dependency of clwrf_support code for RRTMG-lwk (KIM version) - that code does not use the capability. In a single 15 km domain test in July 2018, there are small differences between temperature and height at 24 h forecast time as shown below in the domain averaged profile plot:  LIST OF MODIFIED FILES: M main/depend.common M phys/module_ra_rrtmg_sw.F M phys/module_ra_rrtmg_swf.F TESTS CONDUCTED: 1. Time varying gases are added to RRTMG-swf and RRTMG-sw 2. The Jenkins tests all passing. RELEASE NOTE: Added time-varying greenhouse gases to RRTMG shortwave options: RRTMG and RRTMG-fast.
…ration for release (wrf-model#1599) Update top-level README and inc/version_decl files to v4.3.2 in preparation for release TYPE: text only KEYWORDS: update, README, version_decl, v4.3.2, release SOURCE: Internal DESCRIPTION OF CHANGES: Updated the top-level README and inc/version_decl files to v4.3.2 in preparation for release LIST OF MODIFIED FILES: M README M inc/version_decl TESTS CONDUCTED: No tests needed Jenkins tests passed.
Nikolar97
requested review from
a team,
brankokosovic,
domingom and
pedro-jm
as code owners
|
@Nikolar97 |
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
18 participants
Add this suggestion to a batch that can be applied as a single commit.
This suggestion is invalid because no changes were made to the code.
Suggestions cannot be applied while the pull request is closed.
Suggestions cannot be applied while viewing a subset of changes.
Only one suggestion per line can be applied in a batch.
Add this suggestion to a batch that can be applied as a single commit.
Applying suggestions on deleted lines is not supported.
You must change the existing code in this line in order to create a valid suggestion.
Outdated suggestions cannot be applied.
This suggestion has been applied or marked resolved.
Suggestions cannot be applied from pending reviews.
Suggestions cannot be applied on multi-line comments.
Suggestions cannot be applied while the pull request is queued to merge.
Suggestion cannot be applied right now. Please check back later.
TYPE: New feature
KEYWORDS: microphysic, forecast, cloud, precipitation
SOURCE: Ivan Ristic (Weather2 - www.weather2.rs)
DESCRIPTION OF CHANGES:
In order to improve cloud and precipitation forecast we developed new cloud prediction scheme and we implemented it in WRF model. Fractional cloud cover, cloud liquid water, cloud ice and cloud snow are explicitly predicted by adding three
prognostic equations for fractional cloud cover, cloud mixing ratio and snow per cloud fraction to the model. Sedimentation of ice and snow is also included in parameterization. Precipitation of rain and snow are determined from cloud fields. Clouds predicted like this can be used also in radiation parameterization.
Thermodynamic wet bulb temperature will be used for describing clouds because it is constant during water phase changes. By using this temperature moist static energy of model grid box and cloudy part inside the grid box is the same and principle of energy conservation is satisfied.
A complete description is now found in Ristic I., Kordic I., 2018: Cloud parameterization and cloud prediction scheme in the Eta numerical weather model. NWCM - Serbian Academy of Sciences and Arts which can be found at https://www.sanu.ac.rs/wp-content/uploads/2018/10/11_Cloud%20parameterization%20and%20cloud%20prediction%20scheme%20in%20Eta%20numerical%20weather%20model.pdf .
LIST OF MODIFIED FILES:
phys/Makefile
phys/module_microphysics_driver.F
phys/module_mp_ivanr_micro.F
Registry/Registry.EM_COMMON
Registry/Registry.NMM
dyn_em/solve_em.F
dyn_nmm/module_PHYSICS_CALLS.F
dyn_nmm/solve_nmm.F
TESTS CONDUCTED:
All the wrf-coop tests passed and the microphysics is being actively used for running a model with NMM.
Integration of the model for test cases indicate that new cloud prediction scheme improved forecast compared to the original model. New fractional cloud cover formula showed good results in practice, since the fractional cloud cover, predicted in this way, was much closer to the real cloud cover values. Significant progress has been made in stratiform precipitation forecast. Positive impact on convection scheme is also noticed.
One test was run on 17. November 2011 with the Wrf model with ECMWF as boundary data. Model run for 72 hours in horizontal resolution of about 22 km and vertical resolution of 38 layers for the Europe domain. Fog was first to be tested.
The second test was run on 24. June 2015 with Wrf model with ECMWF as boundary data. Model was run for 24 hours in
horizontal resolution of about 22 km and a vertical resolution of 38 layers for the Europe domain. The second test situation tested mid-morning precipitation over northern Serbia.
More details can be found in the aforementioned pdf file.
RELEASE NOTE: Ivan Ristic: Custom implementation of microphysics
