This is my take on #4462, that adds an end argument to coord_polar() to allow partial polar plots.

In brief:

  • There are no visual changes if end is not used.
  • It was straightforward to rescale to [start, end] instead of [0, 2π] to get the partial polar coordinates.
  • After that rescaling, I had to account for the bounding box of the circle sector.
  • The bit I found more difficult were the radius axis placement. I've resolved this as detailed below.

Normally, the axis is placed in the upper part of the y-axis. If we have only the lower part of a circle, I had to reflect the break positions:

devtools::load_all("~/packages/ggplot2/")
#> ℹ Loading ggplot2

p <- ggplot(mpg, aes(displ, hwy, colour = factor(cyl))) +
  geom_point()

p + coord_polar(start = 0.5 * pi, end = 1.5 * pi)

If 0 or π are not in the [start, end] interval, I have placed the axis in the x-direction. (Below also reflected because left instead of right).

p + coord_polar(start = 1.25 * pi, end = 1.75 * pi)

If no integer multiple of 0.5π is in that interval, I can't appropriately place an axis anywhere. In that case, I've thrown a message with instructions.

p + coord_polar(start = 0.1 * pi, end = 0.4 * pi)
#> Could not find appropriate placement for the radius axis.
#> ℹ A radius axis requires the [`start`-`end`] range to include one of: `c(0,
#>   0.5, 1, 1.5) * pi`.

Created on 2022-11-03 by the reprex package (v2.0.1)

After the guides are ported over to the ggproto system, we might consider a more complete solution for axis placement than this.
