Temporal ridesharing demo application

This repository contains code for a ridesharing demo application that highlights Temporal's durability and support for external interactions. It's implemented in TypeScript and integrates with Stripe's Stripe's usage-based billing. Want to see it in action? Check out this demonstration from the Stripe Sessions conference (the demo starts at 13:09):

Navigating the Codebase

The application is composed of three parts, each in its own subdirectory.

Subdirectory	Description
frontend	Browser-based UI
api	API that interfaces between the browser and Temporal workflows
backend	Temporal Workflow and Activities for ride management and billing

Running the Application

There are five steps to running the application:

1. Set up usage-based billing in Stripe
2. Start the Temporal Service
3. Run the application backend
4. Run the application API
5. Run the application frontend

Set Up Usage-Based Billing in Stripe

See (this document for step-by-step instructions for the prerequisite Stripe setup.

Start the Temporal Service

The sample is configured by default to connect to a local Temporal Service running on localhost:7233. You can use this command to start it:

temporal server start-dev

To instead connect to Temporal Cloud, set the following environment variables, replacing them with your own Temporal Cloud credentials. The instructions below assume the use of a Bourne-compatible UNIX shell (such as bash), so you'll need to adjust them slightly if using a different shell (such as Windows cmd.exe or Powershell).

With mTLS:

export TEMPORAL_ADDRESS=testnamespace.sdvdw.tmprl.cloud:7233
export TEMPORAL_NAMESPACE=testnamespace.sdvdw
export TEMPORAL_CLIENT_CERT_PATH="/path/to/file.pem"
export TEMPORAL_CLIENT_KEY_PATH="/path/to/file.key"

With an API key:

export TEMPORAL_ADDRESS=us-west-2.aws.api.temporal.io:7233
export TEMPORAL_NAMESPACE=testnamespace.sdvdw
export TEMPORAL_API_KEY="your-api-key"

If using API key authentication, ensure that the TEMPORAL_CLIENT_CERT_PATH and TEMPORAL_CLIENT_KEY_PATH environment variables are not set.

Run the Application Backend

To run the application backend, first open a terminal and change to the backend directory.

cd backend

Next, set the STRIPE_API_KEY environment variable in that terminal to the value of your Stripe secret key.

export STRIPE_API_KEY=sk_test_34RZ6V4AJr...kFq

Now, install the project dependencies:

npm install

Finally, start the Temporal Worker for the backend:

npm run start

To run the backend unit tests, see backend/TESTING.md.

Run the Application API

Open another terminal and change to the api directory.

cd api

Install the application API dependencies:

npm install

Configure the application API by creating a .env file in the root directory with the following variables (adjust these if using Temporal Cloud or other non-local Temporal Service):

TEMPORAL_HOST=localhost
TEMPORAL_PORT=7233

Start the API server in developer mode with hot reload:

npm run dev

Run the Application Frontend

Open another terminal and change to the frontend directory.

cd frontend

Install the dependencies for the frontend:

pnpm install

Next, start the development server:

pnpm dev

The app should now be available at http://localhost:5173, although it may use a different port number if that one is already in use. You can navigate to the URL it displays to begin the demo.

Running Tests

Each component has its own test suite that can be run independently:

• Frontend: cd frontend && npm test
• API: cd api && npm test
• Backend: cd backend && npm test

Alternatively, you can run all tests in sequence using the provided Bash script:

./run-all-tests.sh

This will execute all test suites and provide a summary of results.

Why Temporal?

This is a natural fit for Temporal due to several key advantages:

• Durable state tracking: Temporal maintains state over time without requiring external persistence. The session's duration, distance, and accumulated cost are managed in-memory by the Workflow and survive process restarts or crashes.
• Interaction with external applications: Signals from the mobile app or scooter firmware (e.g., addDistance, endRide) allow real-time updates without polling or manual state reconciliation. Similarly, Queries provide those external applications with current information about the Workflow Execution (such as the scooter ID, the current total cost of the ride, or the email address of the rider).
• Built-in Timers: This feature of Temporal is used to assess charges based on time spent using the scooter, while the ride is in progress. It has many other applications in this scenario, such as enforcing a promptness of user response and to end the Workflow after a set time limit (e.g., to limit charges associated with abandoned scooters). This capability is built into Temporal and does not require cron jobs, external schedulers, or separate infrastructure.
• Exactly-once billing: thanks to Temporal's built-in retry semantics and idempotency built into the application, failures do not result in duplicated calls to Stripe's Billing API.
• Operational simplicity: Temporal Workflows encapsulate the full lifecycle of the ride, using clear business logic expressed in code. The Temporal Web UI provides observability, enabling you to see the current state and progress for each ride, regardless of whether they have recently completed or are still running.

Demonstration Scenario Summary

Before performing any demonstration, you must do some one-time setup in Stripe, as documented in these instructions to establish the Customer, Product, Meter, and Subscription associated with usage-based billing in Stripe.

For all scenarios below, you will have at least two terminal windows (or tabs). In each, set the STRIPE_API_KEY environment variable to your Stripe secret API key.

In the first terminal, run the npm install command to install the dependencies and npm run start to start the Worker, as described above. In the second, follow the steps below to demonstrate a specific scenario.

Happy Path

In this scenario, everything works as expected on the first try. There are no failures. The e-mail address must correspond to the one you set up in Stripe, as per these instructions.

Use scooter ID 1230 for this scenario.

This starts the Workflow Execution, which bills the user some number of tokens for an initial "unlock the scooter" charge and consumes some additional number of tokens for each subsequent 15 seconds of use.

The ride will automatically end after three minutes, but you can click the End Ride button in the UI to end it sooner.

Network Outage

In this scenario, the first Activity in the Workflow (which calls a Stripe API to look up the customer ID corresponding to the email address used to start the Workflow Execution) initially fails due to a (simulated) network outage. On the fourth attempt, the failure resolves itself, after which the Activity will succeed.

The steps for this scenario are identical to the ones above, except for the scooter ID, which must be 1234 (this triggers the failure).

Non-Retryable Failure

In this scenario, the Activity that invokes a Stripe API to look up the Customer ID corresponding to the email address fails because there is no record for that customer in Stripe. Unlike a network outage, we'd prefer to end the Workflow Execution in this case instead of retrying the call again and again.

For this scenario, use 1233 as the scooter ID and test@example.com as the email address when starting the ride.

Temporal's Retry Policies support not only defining the cadence of retry attempts, but also designating certain error types as non-retryable. The specific exception type in this scenario is CustomerNotFoundException (defined in the src/activities.ts file) and the Retry Policy defined in src/workflows.ts specifies this type of exception as non-retryable.

Discover and Fix a Bug in the Running Application

In this scenario, the BeginRide Activity that assesses the initial charge for unlocking the scooter attempts to do some validation on the scooter ID. The comment above the relevant line of code states that the scooter ID (a string) must consist only of digits, but the regular expression that performs this validation has a typo. It checks that each character is in the range 0-8 instead of 0-9, so it incorrectly fails if the scooter ID contains a 9.

You can use this scenario to demonstrate how you can fix a bug in the application code, even for a Workflow Execution already in progress. We especially recommend using the Temporal Web UI here, since its Pending Activities tab will show the error that's causing the Activity Execution to fail and will also identify the specific line of code responsible.

To trigger the bug, use a scooter ID that contains a 9, such as 1239.

Wait for the Activity to fail, use the Temporal Web UI to identify the source of the failure, and then fix the bug by changing 0-8 in the regex to 0-9. Afterwards, you will need to kill and re-run the npm run start process you started in the other terminal for the change to take effect (if not using nodemon to do that automatically). Once you have done these things, you should find that the Activity will succeed upon the next retry attempt.

Ride Awaits Approval to Continue (Human-in-the-Loop)

To prevent riders from incurring excessive charges, the Workflow is designed to pause the ride after 70 tokens have been consumed. In order to continue the ride, you must send the approveRide Signal to the Workflow Execution. You can do this with the Temporal Web UI, or if you prefer, by using the Temporal CLI (replace 1000 in the command below with the scooter ID for your ride):

temporal workflow signal --workflow-id scooter-session-1000 --name approveRide
