📌Real Time IDS

Real Time IDS is an Intrusion Detection System designed to analyze network flow in real time and identify potential threats. By leveraging a machine learning-based detection layer, it provides accurate insights into network activity, allowing users to make informed security decisions. This system enhances network protection by detecting anomalies and giving users control over the next steps.

✨Highlights

• Detects different threats like DoS, Portscan, and Bot from network packets with an accuracy of 90%.
• Simulates a real-time IDS using pcap files that may contain malicious packets.
• The entire machine learning layer is built from scratch using C++ and CUDA for high-performance detection.
• Utilizes PyFlowmeter to convert raw packets into flows and extract key network features.
• Provides detailed IP address and host information for potential threats.

🔧Installation

📋Prerequisites

Ensure you have the following installed on your system:

• Python 3
• G++ (GNU Compiler Collection)
• CUDA Toolkit (for GPU acceleration) – Install it using:

  sudo apt install nvidia-cuda-toolkit

⚙️Setting Up the Environment

• Requirements : This scripts/requirements.txt file contains all the necessary Python dependencies for the project. Place any additional required dependencies here.

• Virtual Environment: :

  source {path to dependencies.sh}

  Execute the command, and voila! It will automatically create the virtual environment (if it doesn't already exist) and install all the required dependencies for you. You can run the script from any directory. Easy Peasy!

🛠️Compiling Machine Learning Layer

The compile.sh script is responsible for compiling the machine learning layer and generating a .so file, which serves as the Python binding for the C++ logic.

Execute

 source {path to compile.sh}

The compiled .so file will be placed inside the build/ directory.

📁Configuration

The project relies on a configuration file located at config/path.json to define paths for various components like training data, model paths, and other relevant directories. The root project path is dynamically updated by the run.sh script, based on the location of the project.

This allows for seamless portability across different environments, ensuring that all the paths within the configuration file are relative to the project root.

▶️Running the Project

To start the Intrusion Detection System, simply execute run.sh inside the scripts/, providing only the name of the pcap file (which should be placed in the data/ folder):

source {path to run.sh} <pcap_filename>

Viola! 🚀 Your IDS is up and running! 🎯

📖 Documentation

The project comes with detailed documentation covering all Python and C++ classes, functions, and modules.

To access the documentation, open the following file in your browser:

docs/index.html

Simply navigate to the docs/ folder and open index.html in any web browser to explore the full documentation.

🎥 Demo

Watch the project in action! Check out the demo video:

Click the image or this link to watch the demo.
