An STM32F401 EEPROM driver written entirely in Assembler.
/**
* FILE: main.s
*
* DESCRIPTION:
* An STM32F401 EEPROM driver written entirely in Assembler.
*
* AUTHOR: Kevin Thomas
* CREATION DATE: March 7, 2024
* UPDATE DATE: June 22, 2025
*/
.syntax unified // use unified assembly syntax
.cpu cortex-m4 // target Cortex-M4 core
.fpu softvfp // use software floating point
.thumb // use Thumb instruction set
/**
* The start address for the .data section defined in linker script.
*/
.word _sdata // start of .data
/**
* The end address for the .data section defined in linker script.
*/
.word _edata // end of .data
/**
* The start address for the initialization values of the .data section defined in
* linker script.
*/
.word _sidata // start of .data init values
/**
* The start address for the .bss section defined in linker script.
*/
.word _sbss // start of .bss
/**
* The end address for the .bss section defined in linker script.
*/
.word _ebss // end of .bss
/**
* Provide weak aliases for each Exception handler to the Default_Handler. As they
* are weak aliases, any function with the same name will override this definition.
*/
.macro weak name
.global \name // make symbol global
.weak \name // mark as weak
.thumb_set \name, Default_Handler // set to Default_Handler
.word \name // vector entry
.endm
/**
* Initialize the .isr_vector section. The .isr_vector section contains vector
* table.
*/
.section .isr_vector, "a" // vector table section
/**
* The STM32F401RE vector table. Note that the proper constructs must be placed
* on this to ensure that it ends up at physical address 0x00000000.
*/
.global isr_vector // export vector table
.type isr_vector, %object // object type
isr_vector:
.word _estack // Initial Stack Pointer
.word Reset_Handler // Reset Handler
weak NMI_Handler // NMI Handler
weak HardFault_Handler // HardFault Handler
weak MemManage_Handler // MemManage Handler
weak BusFault_Handler // BusFault Handler
weak UsageFault_Handler // UsageFault Handler
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
weak SVC_Handler // SVC Handler
weak DebugMon_Handler // Debug Monitor Handler
.word 0 // Reserved
weak PendSV_Handler // PendSV Handler
weak SysTick_Handler // SysTick Handler
.word 0 // Reserved
weak EXTI16_PVD_IRQHandler // EXTI Line 16 Interrupt PVD
weak TAMP_STAMP_IRQHandler // Tamper/TimeStamp Interrupt
weak EXTI22_RTC_WKUP_IRQHandler // RTC Wakeup Interrupt
weak FLASH_IRQHandler // FLASH Global Interrupt
weak RCC_IRQHandler // RCC Global Interrupt
weak EXTI0_IRQHandler // EXTI Line0 Interrupt
weak EXTI1_IRQHandler // EXTI Line1 Interrupt
weak EXTI2_IRQHandler // EXTI Line2 Interrupt
weak EXTI3_IRQHandler // EXTI Line3 Interrupt
weak EXTI4_IRQHandler // EXTI Line4 Interrupt
weak DMA1_Stream0_IRQHandler // DMA1 Stream0 Global Interrupt
weak DMA1_Stream1_IRQHandler // DMA1 Stream1 Global Interrupt
weak DMA1_Stream2_IRQHandler // DMA1 Stream2 Global Interrupt
weak DMA1_Stream3_IRQHandler // DMA1 Stream3 Global Interrupt
weak DMA1_Stream4_IRQHandler // DMA1 Stream4 Global Interrupt
weak DMA1_Stream5_IRQHandler // DMA1 Stream5 Global Interrupt
weak DMA1_Stream6_IRQHandler // DMA1 Stream6 Global Interrupt
weak ADC_IRQHandler // ADC1 Global Interrupt
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
weak EXTI9_5_IRQHandler // EXTI Line[9:5] Interrupts
weak TIM1_BRK_TIM9_IRQHandle // TIM1 Break/TIM9 Global Interrupt
weak TIM1_UP_TIM10_IRQHandler // TIM1 Update/TIM10 Global Interrupt
weak TIM1_TRG_COM_TIM11_IRQHandler // TIM1 T/C/TIM11 Global Interrupt
weak TIM1_CC_IRQHandler // TIM1 Capture Compare Interrupt
weak TIM2_IRQHandler // TIM2 Global Interrupt
weak TIM3_IRQHandler // TIM3 Global Interrupt
weak TIM4_IRQHandler // TIM4 Global Interrupt
weak I2C1_EV_IRQHandler // I2C1 Event Interrupt
weak I2C1_ER_IRQHandler // I2C1 Error Interrupt
weak I2C2_EV_IRQHandler // I2C2 Event Interrupt
weak I2C2_ER_IRQHandler // I2C2 Error Interrupt
weak SPI1_IRQHandler // SPI1 Global Interrupt
weak SPI2_IRQHandler // SPI2 Global Interrupt
weak USART1_IRQHandler // USART1 Global Interrupt
weak USART2_IRQHandler // USART2 Global Interrupt
.word 0 // Reserved
weak EXTI15_10_IRQHandler // EXTI Line[15:10] Interrupts
weak EXTI17_RTC_Alarm_IRQHandler // RTC Alarms EXTI
weak EXTI18_OTG_FS_WKUP_IRQHandler // USB OTG FS Wakeup EXTI
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
weak DMA1_Stream7_IRQHandler // DMA1 Stream7 Global Interrupt
.word 0 // Reserved
weak SDIO_IRQHandler // SDIO Global Interrupt
weak TIM5_IRQHandler // TIM5 Global Interrupt
weak SPI3_IRQHandler // SPI3 Global Interrupt
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
weak DMA2_Stream0_IRQHandler // DMA2 Stream0 Global Interrupt
weak DMA2_Stream1_IRQHandler // DMA2 Stream1 Global Interrupt
weak DMA2_Stream2_IRQHandler // DMA2 Stream2 Global Interrupt
weak DMA2_Stream3_IRQHandler // DMA2 Stream3 Global Interrupt
weak DMA2_Stream4_IRQHandler // DMA2 Stream4 Global Interrupt
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
weak OTG_FS_IRQHandler // USB OTG FS Global Interrupt
weak DMA2_Stream5_IRQHandler // DMA2 Stream5 Global Interrupt
weak DMA2_Stream6_IRQHandler // DMA2 Stream6 Global Interrupt
weak DMA2_Stream7_IRQHandler // DMA2 Stream7 Global Interrupt
weak USART6_IRQHandler // USART6 Global Interrupt
weak I2C3_EV_IRQHandler // I2C3 Event Interrupt
weak I2C3_ER_IRQHandler // I2C3 Error Interrupt
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
.word 0 // Reserved
weak SPI4_IRQHandler // SPI4 Global Interrupt
/**
* @brief This code is called when processor starts execution.
*
* @details This is the code that gets called when the processor first
* starts execution following a reset event. We first define and init
* the bss section and then define and init the data section, after which
* the application supplied main routine is called.
*
* @param None
* @retval None
*/
.type Reset_Handler, %function // function type
.global Reset_Handler // export symbol
Reset_Handler:
.Reset_Handler_Setup:
LDR R4, =_estack // load addr at end of stack R4
MOV SP, R4 // move addr at end of stack SP
LDR R4, =_sdata // copy data seg init flash to SRAM
LDR R5, =_edata // copy data seg init flash to SRAM
LDR R6, =_sidata // copy data seg init flash to SRAM
MOVS R7, #0 // zero offset
B .Reset_Handler_Loop_Copy_Data_Init // branch
.Reset_Handler_Copy_Data_Init:
LDR R8, [R6, R7] // copy data seg init to regs
STR R8, [R4, R7] // copy data seg init tp regs
ADDS R7, R7, #4 // increment offset
.Reset_Handler_Loop_Copy_Data_Init:
ADDS R8, R4, R7 // initialize the data segment
CMP R8, R5 // compare
BCC .Reset_Handler_Copy_Data_Init // branch if carry is clear
LDR R6, =_sbss // copy bss seg init flash to SRAM
LDR R8, =_ebss // copy bss seg init flash to SRAM
MOVS R7, #0 // zero offset
B .Reset_Handler_Loop_Fill_Zero_BSS // branch
.Reset_Handler_Fill_Zero_BSS:
STR R7, [R6] // zero fill the bss segment
ADDS R6, R6, #4 // increment pointer
.Reset_Handler_Loop_Fill_Zero_BSS:
CMP R6, R8 // compare
BCC .Reset_Handler_Fill_Zero_BSS // branch if carry is clear
.Reset_Handler_Call_Main:
BL main // call main
/**
* @brief This code is called when the processor receives an unexpected interrupt.
*
* @details This simply enters an infinite loop, preserving the system state for
* examination by a debugger.
*
* @param None
* @retval None
*/
.type Default_Handler, %function // function type
.global Default_Handler // export symbol
Default_Handler:
BKPT // set processor into debug state
B.N Default_Handler // infinite loop
/**
* Initialize the .text section.
* The .text section contains executable code.
*/
.section .text // code section
/**
* @brief Entry point for EEPROM driver initialization and main loop.
*
* @details This function initializes the GPIO and I2C peripherals for EEPROM
* communication and enters an infinite loop. All code and comments
* are tailored for EEPROM.
*
* @param None
* @retval None
*/
.type main, %function
.global main
main:
.Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.GPIOB_Enable:
BL GPIOB_Enable // call function
.GPIOB_PB8_Alt_Function_Mode_Enable:
BL GPIOB_PB8_Alt_Function_Mode_Enable // call function
.GPIOB_PB8_Open_Drain_Enable:
BL GPIOB_PB8_Open_Drain_Enable // call function
.GPIOB_PB9_Alt_Function_Mode_Enable:
BL GPIOB_PB9_Alt_Function_Mode_Enable // call function
.GPIOB_PB9_Open_Drain_Enable:
BL GPIOB_PB9_Open_Drain_Enable // call function
.I2C1_Enable:
BL I2C1_Enable // call function
.I2C1_Init:
BL I2C1_Init // call function
.EEPROM_Write_Byte_16bit:
MOV R0, #0x50 // EEPROM I2C device address
MOV R1, #0x00 // EEPROM memory address high byte
MOV R2, #0x00 // EEPROM memory address low byte
MOV R3, #0x22 // data byte to write
BL EEPROM_Write_Byte_16bit // call function
BL Thirty_Microsecond_Delay // call function
.EEPROM_Read_Byte_16bit:
MOV R0, #0x50 // EEPROM I2C device address
MOV R1, #0x00 // EPROM memory address high byte
MOV R2, #0x00 // EEPROM memory address low byte
BL EEPROM_Read_Byte_16bit // call function
.Loop:
BL Loop // call function
.Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Enables the GPIOB peripheral by setting the corresponding RCC_AHB1ENR bit.
*
* @details This function enables the GPIOB peripheral by setting the corresponding
* RCC_AHB1ENR bit. It loads the address of the RCC_AHB1ENR register, retrieves
* the current value of the register, sets the GPIOBEN bit, and stores the
* updated value back into the register.
*
* @param None
* @retval None
*/
GPIOB_Enable:
.GPIOB_Enable_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.GPIOB_Enable_Load_RCC_AHB1ENR:
LDR R4, =0x40023830 // RCC_AHB1ENR register address
LDR R5, [R4] // load value from RCC_AHB1ENR
ORR R5, #(1<<1) // set GPIOBEN bit
STR R5, [R4] // store value back
.GPIOB_Enable_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Configures PB8 as I2C1 SCL (alternate function, open-drain).
*
* @details Sets PB8 to alternate function mode and open-drain for I2C1 SCL line.
*
* @param None
* @retval None
*/
GPIOB_PB8_Alt_Function_Mode_Enable:
.GPIOB_PB8_Alt_Function_Mode_Enable_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.GPIOB_PB8_Alt_Function_Mode_Enable_Set_Moder:
LDR R4, =0x40020400 // GPIOB_MODER register address
LDR R5, [R4] // load value from GPIOB_MODER
ORR R5, #(1<<17) // set MODER8[1]
BIC R5, #(1<<16) // clear MODER8[0]
STR R5, [R4] // store value back
.GPIOB_PB8_Alt_Function_Mode_Enable_Set_AFRH:
LDR R4, =0x40020424 // GPIOB_AFRH register address
LDR R5, [R4] // load value from GPIOB_AFRH
BIC R5, #(1<<3) // clear AFRH8[3]
ORR R5, #(1<<2) // set AFRH8[2]
BIC R5, #(1<<1) // clear AFRH8[1]
BIC R5, #(1<<0) // clear AFRH8[0]
STR R5, [R4] // store value back
.GPIOB_PB8_Alt_Function_Mode_Enable_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Configures PB8 as open-drain for I2C1 SCL.
*
* @details Sets PB8 to open-drain output type for I2C1 SCL line.
*
* @param None
* @retval None
*/
GPIOB_PB8_Open_Drain_Enable:
.GPIOB_PB8_Open_Drain_Enable_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.GPIOB_PB8_Open_Drain_Enable_Set_OTYPER:
LDR R4, =0x40020404 // GPIOB_OTYPER register address
LDR R5, [R4] // load value from GPIOB_OTYPER
ORR R5, #(1<<8) // set OT8 bit
STR R5, [R4] // store value back
.GPIOB_PB8_Open_Drain_Enable_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Configures PB9 as I2C1 SDA (alternate function, open-drain).
*
* @details Sets PB9 to alternate function mode and open-drain for I2C1 SDA line.
*
* @param None
* @retval None
*/
GPIOB_PB9_Alt_Function_Mode_Enable:
.GPIOB_PB9_Alt_Function_Mode_Enable_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.GPIOB_PB9_Alt_Function_Mode_Enable_Set_Moder:
LDR R4, =0x40020400 // GPIOB_MODER register address
LDR R5, [R4] // load value from GPIOB_MODER
ORR R5, #(1<<19) // set MODER9[1]
BIC R5, #(1<<18) // clear MODER9[0]
STR R5, [R4] // store value back
.GPIOB_PB9_Alt_Function_Mode_Enable_Set_AFRH:
LDR R4, =0x40020424 // GPIOB_AFRH register address
LDR R5, [R4] // load value from GPIOB_AFRH
BIC R5, #(1<<7) // clear AFRH9[3]
ORR R5, #(1<<6) // set AFRH9[2]
BIC R5, #(1<<5) // clear AFRH9[1]
BIC R5, #(1<<4) // clear AFRH9[0]
STR R5, [R4] // store value back
.GPIOB_PB9_Alt_Function_Mode_Enable_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Configures PB9 as open-drain for I2C1 SDA.
*
* @details Sets PB9 to open-drain output type for I2C1 SDA line.
*
* @param None
* @retval None
*/
GPIOB_PB9_Open_Drain_Enable:
.GPIOB_PB9_Open_Drain_Enable_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.GPIOB_PB9_Open_Drain_Enable_Set_OTYPER:
LDR R4, =0x40020404 // GPIOB_OTYPER register address
LDR R5, [R4] // load value from GPIOB_OTYPER
ORR R5, #(1<<9) // set OT9 bit
STR R5, [R4] // store value back
.GPIOB_PB9_Open_Drain_Enable_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Enables I2C1 Peripheral for EEPROM communication.
*
* @details Enables the I2C1 peripheral by setting the I2C1EN bit in the RCC_APB1ENR
* register.
*
* @param None
* @retval None
*/
I2C1_Enable:
.I2C1_Enable_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.I2C1_Enable_Set_APB1ENR:
LDR R4, =0x40023840 // RCC_APB1ENR register address
LDR R5, [R4] // load value from RCC_APB1ENR
ORR R5, #(1<<21) // set I2C1EN bit
STR R5, [R4] // store value back
.I2C1_Enable_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Initializes I2C1 peripheral for EEPROM operation.
*
* @details Configures I2C1 registers for standard EEPROM I2C operation (100kHz, 7-bit
* addr).
*
* @param None
* @retval None
*/
I2C1_Init:
.I2C1_Init_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.I2C1_Init_Reset_CR1:
LDR R4, =0x40005400 // I2C1_CR1 register address
LDR R5, [R4] // load value from I2C1_CR1
ORR R5, #(1<<15) // set SWRST bit (software reset)
STR R5, [R4] // store value back
BIC R5, #(1<<15) // clear SWRST bit
STR R5, [R4] // store value back
.I2C1_Init_Set_CR2:
LDR R4, =0x40005404 // I2C1_CR2 register address
LDR R5, [R4] // load value from I2C1_CR2
ORR R5, #(1<<5) // set FREQ[5] 50 MHz (PIML)
ORR R5, #(1<<4) // set FREQ[5] 50 MHz (PIML)
BIC R5, #(1<<3) // clear FREQ[5] 50 MHz (PIML)
BIC R5, #(1<<2) // clear FREQ[5] 50 MHz (PIML)
ORR R5, #(1<<1) // set FREQ[5] 50 MHz (PIML)
BIC R5, #(1<<0) // clear FREQ[5] 50 MHz (PIML)
STR R5, [R4] // store value back
.I2C1_Init_Set_CCR:
LDR R4, =0x4000541C // I2C1_CCR register address
LDR R5, [R4] // load value from I2C1_CCR
ORR R5, #(1<<15) // set F/S bit (fast/std mode)
ORR R5, #(1<<14) // set DUTY bit
ORR R5, #(1<<1) // set CCR[1] (clock control)
STR R5, [R4] // store value back
LDR R4, =0x40005420 // I2C1_TRISE register address
LDR R5, [R4] // load value from I2C1_TRISE
BIC R5, #(1<<5) // clear TRISE[5] (max rise time)
ORR R5, #(1<<4) // set TRISE[4] (max rise time)
BIC R5, #(1<<3) // clear TRISE[5] (max rise time)
ORR R5, #(1<<2) // set TRISE[4] (max rise time)
BIC R5, #(1<<1) // clear TRISE[5] (max rise time)
BIC R5, #(1<<0) // clear TRISE[4] (max rise time)
STR R5, [R4] // store value back
LDR R4, =0x40005400 // I2C1_CR1 register address
LDR R5, [R4] // load value from I2C1_CR1
ORR R5, #(1<<0) // set PE bit (peripheral enable)
STR R5, [R4] // store value back
.I2C1_Init_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Writes a byte to the EEPROM via I2C1 with 16-bit addressing.
*
* @details This function writes a byte to the EEPROM using I2C1 with 16-bit memory
* addressing. It sends the device address, high byte of memory address,
* low byte of memory address, and data byte, then generates a stop condition.
*
* @param R0: EEPROM I2C device address (7-bit, e.g., 0x50 for 0xA0)
* @param R1: EEPROM memory address high byte
* @param R2: EEPROM memory address low byte
* @param R3: Data byte to write
* @retval None
*/
EEPROM_Write_Byte_16bit:
.EEPROM_Write_Byte_16bit_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.EEPROM_Write_Byte_16bit_Init_Load_Registers:
LDR R4, =0x40005400 // I2C1_CR1 register
LDR R5, =0x40005410 // I2C1_DR register
LDR R6, =0x40005414 // I2C1_SR1 register
LDR R7, =0x40005418 // I2C1_SR2 register
.EEPROM_Write_Byte_16bit_Generate_Start:
LDR R8, [R4] // read CR1
ORR R8, #(1<<8) // set START
STR R8, [R4] // write CR1
.EEPROM_Write_Byte_16bit_Wait_Start_Bit:
LDR R8, [R6] // read SR1
TST R8, #1 // test SB
BEQ .EEPROM_Write_Byte_16bit_Wait_Start_Bit // wait until set
.EEPROM_Write_Byte_16bit_Send_Device_Address:
LSL R8, R0, #1 // left-align address, write=0
STR R8, [R5] // write DR
.EEPROM_Write_Byte_16bit_Wait_For_Addr:
LDR R8, [R6] // read SR1
TST R8, #(1<<1) // test ADDR
BEQ .EEPROM_Write_Byte_16bit_Wait_For_Addr // wait until set
LDR R8, [R7] // clear ADDR by reading SR2
.EEPROM_Write_Byte_16bit_Send_Memory_Addr_High_Byte:
STR R1, [R5] // write DR
.EEPROM_Write_Byte_16bit_Wait_For_TxE_1:
LDR R8, [R6] // read SR1
TST R8, #(1<<7) // test TxE
BEQ .EEPROM_Write_Byte_16bit_Wait_For_TxE_1 // wait until set
.EEPROM_Write_Byte_16bit_Send_Memory_Addr_Low_Byte:
STR R2, [R5] // write DR
.EEPROM_Write_Byte_16bit_Wait_For_TxE_2:
LDR R8, [R6] // read SR1
TST R8, #(1<<7) // test TxE
BEQ .EEPROM_Write_Byte_16bit_Wait_For_TxE_2 // wait until set
.EEPROM_Write_Byte_16bit_Send_Data_Byte:
STR R3, [R5] // write DR
.EEPROM_Write_Byte_16bit_Wait_For_TxE_3:
LDR R8, [R6] // read SR1
TST R8, #(1<<7) // test TxE
BEQ .EEPROM_Write_Byte_16bit_Wait_For_TxE_3 // wait until set
.EEPROM_Write_Byte_16bit_Generate_Stop:
LDR R8, [R4] // read CR1
ORR R8, #(1<<9) // set STOP
STR R8, [R4] // write CR1
.EEPROM_Write_Byte_16bit_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Reads a byte from the EEPROM via I2C1 with 16-bit addressing.
*
* @details This function reads a byte from the EEPROM using I2C1 with 16-bit memory
* addressing. It sends the device address, high byte of memory address, low
* byte of memory address, then a repeated start and device address (read),
* and reads the data byte with proper NACK generation for single byte read.
*
* @param R0: EEPROM I2C device address (7-bit, e.g., 0x50 for 0xA0)
* @param R1: EEPROM memory address high byte
* @param R2: EEPROM memory address low byte
* @retval R0: Data byte read
*/
EEPROM_Read_Byte_16bit:
.EEPROM_Read_Byte_16bit_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
.EEPROM_Read_Byte_16bit_Init_Load_Registers:
LDR R4, =0x40005400 // I2C1_CR1 register
LDR R5, =0x40005410 // I2C1_DR register
LDR R6, =0x40005414 // I2C1_SR1 register
LDR R7, =0x40005418 // I2C1_SR2 register
.EEPROM_Read_Byte_16bit_Generate_Start:
LDR R8, [R4] // read CR1
ORR R8, #(1<<8) // set START
STR R8, [R4] // write CR1
.EEPROM_Read_Byte_16bit_Wait_Start_Bit_1:
LDR R8, [R6] // read SR1
TST R8, #1 // test SB
BEQ .EEPROM_Read_Byte_16bit_Wait_Start_Bit_1 // wait until set
.EEPROM_Read_Byte_16bit_Send_Device_Address_1:
LSL R8, R0, #1 // left-align address, write=0
STR R8, [R5] // write DR
.EEPROM_Read_Byte_16bit_Wait_For_Addr_1:
LDR R8, [R6] // read SR1
TST R8, #(1<<1) // test ADDR
BEQ .EEPROM_Read_Byte_16bit_Wait_For_Addr_1 // wait until set
LDR R8, [R7] // clear ADDR by reading SR2
.EEPROM_Read_Byte_16bit_Send_Memory_Addr_High_Byte:
STR R1, [R5] // write DR
.EEPROM_Read_Byte_16bit_Wait_For_TxE_1:
LDR R8, [R6] // read SR1
TST R8, #(1<<7) // test TxE
BEQ .EEPROM_Read_Byte_16bit_Wait_For_TxE_1 // wait until set
.EEPROM_Read_Byte_16bit_Send_Memory_Addr_Low_Byte:
STR R2, [R5] // write DR
.EEPROM_Read_Byte_16bit_Wait_For_TxE_2:
LDR R8, [R6] // read SR1
TST R8, #(1<<7) // test TxE
BEQ .EEPROM_Read_Byte_16bit_Wait_For_TxE_2 // wait until set
.EEPROM_Read_Byte_16bit_Generate_Repeated_Start:
LDR R8, [R4] // read CR1
ORR R8, #(1<<8) // set START
STR R8, [R4] // write CR1
.EEPROM_Read_Byte_16bit_Wait_Start_Bit_2:
LDR R8, [R6] // read SR1
TST R8, #1 // test SB
BEQ .EEPROM_Read_Byte_16bit_Wait_Start_Bit_2 // wait until set
.EEPROM_Read_Byte_16bit_Send_Device_Address_2:
LSL R8, R0, #1 // left-align address
ORR R8, #1 // set read=1
STR R8, [R5] // write DR
.EEPROM_Read_Byte_16bit_Wait_For_Addr_2:
LDR R8, [R6] // read SR1
TST R8, #(1<<1) // test ADDR
BEQ .EEPROM_Read_Byte_16bit_Wait_For_Addr_2 // wait until set
.EEPROM_Read_Byte_16bit_Dis_ACK_For_Single_Byte_Read:
LDR R8, [R4] // read CR1
BIC R8, #(1<<10) // clear ACK bit
STR R8, [R4] // write CR1
LDR R8, [R7] // clear ADDR by reading SR2
.EEPROM_Read_Byte_16bit_Generate_Stop_Before_Read:
LDR R8, [R4] // read CR1
ORR R8, #(1<<9) // set STOP
STR R8, [R4] // write CR1
.EEPROM_Read_Byte_16bit_Wait_For_RxNE:
LDR R8, [R6] // read SR1
TST R8, #(1<<6) // test RxNE
BEQ .EEPROM_Read_Byte_16bit_Wait_For_RxNE // wait until set
.EEPROM_Read_Byte_16bit_Read_Data_Byte:
LDR R0, [R5] // read DR
.EEPROM_Read_Byte_16bit_Re_Enable_ACK:
LDR R8, [R4] // read CR1
ORR R8, #(1<<10) // set ACK bit
STR R8, [R4] // write CR1
.EEPROM_Read_Byte_16bit_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Delay for approximately 30 microseconds.
*
* @details This function creates a delay of approximately 30 microseconds at 16 MHz
* system clock.
*
* @param None
* @retval None
*/
Thirty_Microsecond_Delay:
.Thirty_Microsecond_Delay_Push_Registers:
PUSH {R4-R12, LR} // push registers R4-R12, LR to the stack
MOV R4, #7 // number of loops
.Thirty_Microsecond_Delay_Outer_Loop:
MOV R5, #0xA0 // set initial delay count
.Thirty_Microsecond_Delay_Inner_Loop:
SUB R5, #1 // decrement delay count
CMP R5, #0 // check delay count reached zero
BNE .Thirty_Microsecond_Delay_Inner_Loop // cont loop delay count not zero
SUB R4, #1 // decrement loop counter
CMP R4, #0 // check if delay count zero
BNE .Thirty_Microsecond_Delay_Outer_Loop // cont outer loop if more
.Thirty_Microsecond_Delay_Pop_Registers:
POP {R4-R12, LR} // pop registers R4-R12, LR from the stack
BX LR // return to caller
/**
* @brief Infinite loop function.
*
* @details This function implements an infinite loop using an unconditional branch
* (B) statement. It is designed to keep the program running indefinitely
* by branching back to itself.
*
* @param None
* @retval None
*/
Loop:
B . // branch infinite loop
/**
* Test data and constants.
* The .rodata section is used for constants and static data.
*/
.section .rodata // read-only data section
/**
* Initialized global data.
* The .data section is used for initialized global or static variables.
*/
.section .data // data section
/**
* Uninitialized global data.
* The .bss section is used for uninitialized global or static variables.
*/
.section .bss // BSS section
