Lightweight Sorting in Approximate Homomorphic Encryption

---

This repository contains the source code for the preprint paper Lightweight Sorting in Approximate Homomorphic Encryption. With this code it is possible to sort a vector of encrypted values in "reasonable" time (e.g., few seconds for 128 elements in $[0, 1]$, with precision up to $10^{-2}$).

The proposal (and the code) is split in two parts:

• We propose a concrete improvement in terms of runtime and memory from [MEHP25], although we use precisely the same framework.
• We propose an implementation of a bitonic sorting network based on compare-and-swap operations approximated with the ReLU function

Both algorithms have been implemented in the OpenFHE implementation of the RNS-CKKS scheme

Requirements

It is pretty straightforward to use this source code, first of all be sure that all requirements are satisfied.

• cmake
• OpenFHE

How to use it

First of all clone the repository:

git clone https://github.com/lorenzorovida/Lightweight-Sorting-In-Approximate-Homomorphic-Encryption

Then, make a build folder and build the project with cmake

mkdir build
cmake -B "build" -S Sort

Before launching the program, go to the just created folder:

cd build

A sample usage to test if everything is setup might be:

./Sort --random 16 --delta 0.01 --toy --permutation

That sort 16 random elements using permutation-based approach, with toy parameters.

Now it is possible to launch the program! Notice that, before doing that, some arguments are mandatory

Required arguments:

In order to work properly, we must define some required arguments:

Input values:

One of the following three arguments are required in order to correctly give the input to the circuit.

• Random: To use as input a vector of values from 0 to n randomly shuffled, use --random n where n is a power of two. Also, set the delta value --delta d where d represents the $\delta$ term used in the paper. For example:

--random 8 --delta 0.01

• Input file: To use as input a file, use --file FILENAME where FILENAME is the selected file. Notice that the file must contain a power-of-two number of values. For example:

 --file "../inputs/sample.txt"

• Input inline: Alternatively, you can provide a vector directly by enclosing it in square brackets, for example: "[0.5, 0.12, 0.71, 0.42]". Notice that, also in this case, the length of the vector $|v|$ must be a power of two.

"[0.5, 0.12, 0.71, 0.42]"

Sorting method

Moreover, you have to pick the sorting algorithm, that can be either the permutation-based (light and fast, requires $\Theta(n^2$ slots) or the network-based (heavier and requires bootstrapping, but uses $\Theta(n)$ slots).

• Permutation-based: simply use:

--permutation

• Network-based: simply use:

--network

As an example, if we want to sort 64 random values at maximum distance 0.001 with permutation-based, we can execute:

./Sort --random 64 --delta 0.001 --permutation

Optional arguments:

Be sure to check the paper in order to fully understand the impact of each argument!

It is possible to change the behavior of the program by using some optional argument:

• --tieoffset: use this argument in the permutation-based approach if the inputs contain repeated elements.

./Sort --random 32 --delta 0.1 --permutation --tieoffset --toy_parameters

Important

If the input contains repeated elements and this flag is not on, sorting will not work properly.

• --toy: with this argument the cryptosystem will not have the minimum requirement of $\lambda \geq 128$ security bits against classical computers. Suggested in case you want to play around with the algorithm. For example:

./Sort --random 32 --delta 0.01 --permutation --toy_parameters

• --verbose: prints some (hopefully) useful stuff. For example:

./Sort --random 32 --delta 0.01 --toy_parameters --network --verbose

Suggestions

As this work is still partially WIP, Feel free to open issues or to send us messages with suggestions/comments/critics!

Presentation

You can find a presentation of this work clicking here:

Authors

• Lorenzo Rovida (lorenzo.rovida@unimib.it)
• Alberto Leporati (alberto.leporati@unimib.it)
• Simone Basile (s.basile@campus.unimib.it)

Made with <3 at Bicocca Security Lab, at University of Milan-Bicocca.

Declaration

This is a proof of concept and, even though parameters are created with $\lambda \geq 128$ security bits (according to Homomorphic Encryption Standards), this circuit is intended for educational purposes only.

References

[MEHP25] Federico Mazzone, Maarten Everts, Florian Hahn and Andreas Peter, Efficient Ranking, Order Statistics, and Sorting under CKKS in: USENIX Security '25
