GlobeTrotter is an application used to plan multi-leg adventures and create day-by-day itineraries for each stop along the way. This API serves as the backend for the application. It utilizes GraphQL to handle database queries and mutations, as well as one RESTful endpoint to retrieve and format data from the Yelp API.
This API is deployed to Heroku here, and the frontend application can be found here.
If Python 3 and/or Pipenv are not installed on your machine, please execute the following commands before continuing:
brew install python3
brew install pipenv
In order to setup the repo and install dependencies, navigate into your desired directory and execute the following:
git clone git@github.com:johnktravers/globe_trotter_api.git
cd globe_trotter_api
pipenv shell
pipenv install
Now create, migrate, and seed the development database by executing these commands:
psql
CREATE DATABASE globe_trotter_api_dev;
\q
python3 manage.py migrate
python3 manage.py loaddata trips.json
The following environment variables are required. These can be added to a .env file, for which integration is already established. All API keys are free to obtain.
- DATABASE_URL set to
postgres://postgres@localhost:5432/globe_trotter_api_dev - GEOCODE_API_KEY set to your registered Google Geocoding API key
- AIRPORT_CODES_API_KEY set to your registered Airport Codes API key
- AIRPORT_CODES_API_SECRET set to the secret given to you by the Airport Codes API
- YELP_API_KEY set to your registered Yelp Fusion API key
In order to make sure setup was executed properly, run the test suite by executing the following command:
python3 manage.py test
If you would like to examine test coverage, execute the following instead:
coverage run --source='.' manage.py test
coverage report
The GraphQL endpoint is found by making POST requests to /graphql/, regardless of whether a query or mutation is desired. This endpoint interacts with the database to create, read, update, or delete information that a user has saved, such as trips, destinations, and activities. The following are the available attributes for each resource:
| User | Trip | Destination | TripDestination | Activity |
|---|---|---|---|---|
id |
id |
id |
id |
id |
name |
name |
location |
trip |
name |
email |
origin |
abbrev |
destination |
address |
originAbbrev |
lat |
startDate |
category |
|
originLat |
long |
endDate |
rating |
|
originLong |
tripdestinationSet |
activitySet |
image |
|
tripdestinationSet |
tripSet |
lat |
||
destinationSet |
long |
|||
user |
date |
|||
tripDestination |
Each request requires authentication through a userApiKey parameter, which is created with a user's account and is passed between the frontend and backend applications.
This query retrieves an array of all of a user's trips. See the table above for attributes that can be added to the query.
Request body example:
query {
allTrips(userApiKey: "<USER_API_KEY>") {
id
name
origin
originAbbrev
originLat
originLong
tripdestinationSet {
destination {
location
abbrev
lat
long }
startDate
endDate
}
}
}
Response body example:
{
"data": {
"allTrips": [
{
"id": "1",
"name": "Spring Break",
"origin": "Denver, CO, USA",
"originAbbrev": "DEN",
"originLat": "39.7392",
"originLong": "104.9903",
"tripdestinationSet": [
{
"destination": {
"location": "Barcelona, Spain",
"abbrev": "BCN",
"lat": "41.3851",
"long": "2.1734"
},
"startDate": "2020-03-16",
"endDate": "2020-03-19"
},
{
"destination": {
"location": "Prague, Czech Republic",
"abbrev": "PRG",
"lat": "50.0755",
"long": "14.4378"
},
"startDate": "2020-03-19",
"endDate": "2020-03-23"
}
]
}
]
}
}
This mutation creates a trip for an authenticated user. The required input parameters are name and origin. See the table above for attributes that can be added to the mutation.
Request body example:
mutation {
createTrip(userApiKey: "<USER_API_KEY>", name: "Northern Lights", origin: "Reykjavik, Iceland") {
trip {
id
name
origin
originAbbrev
originLat
originLong
}
}
}
Response body example:
{
"data": {
"createTrip": {
"trip": {
"id": "2",
"name": "Northern Lights",
"origin": "Reykjavík, Iceland",
"originAbbrev": "REK",
"originLat": "64.146582",
"originLong": "-21.9426354"
}
}
}
}
This mutation creates a destination for an authenticated user's trip given the tripId, location, startDate, and endDate. See the table above for attributes that can be added to the mutation.
Request body example:
mutation {
createDestination(userApiKey: "<USER_API_KEY>", tripId: 2, location: "Stockholm, Sweden", startDate: "2021-12-18", endDate: "2021-12-24") {
destination {
id
location
abbrev
lat
long
tripdestinationSet {
startDate
endDate
trip {
name
origin
}
}
}
}
}
Response body example:
{
"data": {
"createDestination": {
"destination": {
"id": "3",
"location": "Stockholm, Sweden",
"abbrev": "STO",
"lat": "59.32932349999999",
"long": "18.0685808",
"tripdestinationSet": [
{
"startDate": "2021-12-18",
"endDate": "2021-12-24",
"trip": {
"name": "Northern Lights",
"origin": "Reykjavík, Iceland"
}
}
]
}
}
}
}
This mutation creates an activity for a destination on an authenticated user's trip given the tripDestinationId, date, activity information. See the table above for attributes that can be added to the mutation.
Request body example:
mutation {
createActivity(userApiKey: "<USER_API_KEY>", tripDestinationId: 1, name: "Arc de Triomf", date: "2020-03-18", address: "Passeig de Sant Joan, s/n, 08010 Barcelona, Spain", category: "Landmarks & Historical Buildings", rating: 4.0, image: "https://s3-media3.fl.yelpcdn.com/bphoto/bmWXY-0so2VYI_lYv-pbVg/o.jpg", lat: 41.3910646236233, long: 2.1806213137548) {
activity {
name
date
address
category
rating
lat
long
tripDestination {
trip {
name
}
destination {
location
abbrev
}
}
}
}
}
Response body example:
{
"data": {
"createActivity": {
"activity": {
"name": "Arc de Triomf",
"date": "2020-03-18",
"address": "Passeig de Sant Joan, s/n, 08010 Barcelona, Spain",
"category": "Landmarks & Historical Buildings",
"rating": 4,
"image": "https://s3-media3.fl.yelpcdn.com/bphoto/bmWXY-0so2VYI_lYv-pbVg/o.jpg",
"lat": "41.3910646236233",
"long": "2.1806213137548",
"tripDestination": {
"trip": {
"name": "Spring Break"
},
"destination": {
"location": "Barcelona, Spain",
"abbrev": "BCN"
}
}
}
}
}
}
This mutation deletes a trip and all resources belonging to that trip by tripId for an authenticated user. All trip attributes except relationships to other tables can be added to the mutation response.
Request body example:
mutation {
deleteTrip (userApiKey: "<USER_API_KEY>", tripId: 5) {
id
name
origin
originAbbrev
originLat
originLong
}
}
Response body example:
{
"data": {
"deleteTrip": {
"id": "5",
"name": "Celebratory Adventure",
"origin": "London, UK",
"originAbbrev": "LON",
"originLat": "51.5073509",
"originLong": "-0.1277583"
}
}
}
This mutation deletes an activity by activityId for an authenticated user. All activity attributes except relationships to other tables can be added to the mutation response.
Request body example:
mutation {
deleteActivity (userApiKey: "<USER_API_KEY>", activityId: 2) {
id
name
address
date
category
rating
lat
long
}
}
Response body example:
{
"data": {
"deleteActivity": {
"id": "2",
"name": "Castell de Montjuïc",
"address": "Carretera de Montjuïc, 66, 08038 Barcelona, Spain",
"date": "2022-03-18",
"category": "Castles",
"rating": 4.0,
"image": "https://s3-media1.fl.yelpcdn.com/bphoto/qvvaNwsAnLxa_g8_0IYiVA/o.jpg",
"lat": "41.3633333212171",
"long": "2.16618073941884"
}
}
}
This endpoint is used to retrieve and format the top 20 landmarks for a given latitude and longitude. The endpoint can be accessed by sending a GET request to /api/v1/yelp_activities/?lat=<LATITUDE>&long=<Longitude>. No user authentication is necessary.
Response body example:
{
"activities": [
{
"name": "Pantheon - Basilica di Santa Maria ad Martyres",
"address": "Piazza della Rotonda, 00186 Rome, Italy",
"category": "Churches",
"rating": 4.5,
"image": "https://s3-media3.fl.yelpcdn.com/bphoto/wDcbtQyxePfBYfHHXYiwGw/o.jpg",
"lat": 41.898614,
"long": 12.476869
},
{
"name": "Colosseo",
"address": "Piazza del Colosseo 1, 00184 Rome, Italy",
"category": "Local Flavor",
"rating": 4.5,
"image": "https://s3-media1.fl.yelpcdn.com/bphoto/QcMxqdZmJTMpeeuT_NfHAg/o.jpg",
"lat": 41.8902496828181,
"long": 12.4922484062616
},
.
.
.
]
}
- Using GraphQL to create a CRUD API
- Gaining familiarity with Python and Django applications
- Python
- Django
- GraphQL
- PostgresQL
- UnitTest
- Travis CI
