Continual Learning and Lifting of Koopman Dynamics for Linear Control of Legged Robots

Feihan Li, Abulikemu Abuduweili, Yifan Sun, Rui Chen, Weiye Zhao and Changliu Liu

Carnegie Mellon University, Robotics Institute, Intelligent Control Lab.

News

• 21 Nov 2024: We released our paper on Arxiv and submit it to L4DC 2025.
• 25 Dec 2024: We uploaded the video of our work to Youtube.
• 01 Mar 2025: Our work were accepted by L4DC 2025!
• 19 Mar 2025: We released our code on Github.

Abstract

Project Features and Contributions

• Incremental Koopman Algorithm: We propose an incremental Koopman algorithm tailored for high-dimensional legged robot dynamics, enabling continual learning and refinement of Koopman linearization.

• Continual Learning Mechanism: By progressively expanding the training dataset and the latent space dimension, our method improves the Koopman linearization, effectively reducing approximation errors.

• Theoretical Convergence Guarantee: We provide a theoretical analysis and guarantee that the learned Koopman dynamics converge to the true Koopman dynamics.

• First Data-Driven Koopman Control for High-Dimensional Legged Robots: This work is the first to implement data-driven Koopman-based whole-body dynamics linearization combined with linear MPC controllers for locomotion control of high-dimensional legged robots.

• Reduced Dependence on Domain Expertise and Improved Generalization: Compared to traditional Koopman approaches, our method reduces reliance on expert knowledge and enhances generalizability across different tasks.

Introduction Videos

Getting Started

Installation

• Follow the installation steps of IsaacLab. Make sure to install rsl_rl during the installation process.
• Notice that our code is tested on IsaacLab v2.0.2.

Training

• Activate the environment built by IsaacLab.

• Initiate the codes for isaaclab, training RL data collector, build initial dataset and build reference repository.

  ./init.sh <Path to IsaacLab Root Dir> <Task Type> <Specifide Data Dir>


  • Here <Path to IsaacLab Root Dir> is the location of your IsaacLab Repository, <Task Type> is your wanted task type (choices are unitree_go2_flat, unitree_a1_flat, anymal_d_flat, g1_flat, h1_flat) and <Specifide Data Dir> is your specified data saving directory.
  • Initial dataset will be saved to <Specifide Data Dir>/<Task Type>/initial_dataset and reference repository will be saved to <Specifide Data Dir>/<Task Type>/reference_repository/
  • RL data collector checkpoints and videos for visualizing the generating process will be saved to <Path to IsaacLab Root Dir>/logs/rsl_rl/<Task Type>/

• Build dynamics based on current dataset and generate tracking data with MPC data collector.

  ./iterate.sh <Path to IsaacLab Root Dir> <Task Type> <Specifide Data Dir>


  • Trained Koopman Dynamics model will be saved to Incremental-Koopman/logs/<Task Type>/Iter<Num>_<Running Time>. Here Iter<Num> represents the number of current iteration which actually depends on the files number in <Specifide Data Dir>/<Task Type>/tracking_dataset/.
  • Tracking dataset generated by MPC data generator and current Koopman Dynamics will be saved to <Specifide Data Dir>/<Task Type>/tracking_dataset/.
  • Repeat running this file will iteratively train Koopman dynamics.
  • Please check configs/<Task Type>.txt for specific training hyperparameters for each iteration.

Visualizing

./visualize.sh <Path to IsaacLab Root Dir> <Task Type> <Koopman Log Dir> <Path to Reference Repository>

• Here <Koopman Log Dir> is the specific Koopman dynamics model you want to test and <Path to Reference Repository> is path to your wanted reference repository.
• Videos will be saved to <Path to IsaacLab Root Dir>/logs/rsl_rl/<Task Type>/.

Acknowledgements

We would like to show our greatest respect to authors of the following repos for making their works public:

• IsaacLab
• DeepKoopmanWithControl

Citation

If you find Incremental Koopman is useful in your research or applications, please consider giving us a star 🌟 and citing it by the following BibTeX entry.

@misc{li2024continuallearningliftingkoopman,
      title={Continual Learning and Lifting of Koopman Dynamics for Linear Control of Legged Robots},
      author={Feihan Li and Abulikemu Abuduweili and Yifan Sun and Rui Chen and Weiye Zhao and Changliu Liu},
      year={2024},
      eprint={2411.14321},
      archivePrefix={arXiv},
      primaryClass={cs.RO},
      url={https://arxiv.org/abs/2411.14321},
}
