MeanECP

A reimplementation of the school internal substitution system using the MEAN-stack.

link to animation: https://gyazo.com/c754c716a77e20ca53071efe663987c8

Development server

Run ng serve for a dev server. Navigate to http://localhost:4200/. The app will automatically reload if you change any of the source files.

Build

Run ng build to build the project. The build artifacts will be stored in the dist/ directory. Use the -prod flag for a production build.

Deployment server

Run node server to start the deployment server. Make sure having build the project in advance using ng build

Deployment Server Config API

The deployment server has 3 routes for configuring it. The access to these has to be authorized by using a client certificate trusted by '/cert/ClientRootCA.crt' All paths only accept valid JSON.

/api/config/Client

This path is used to configure which client shall get which content.
Useage:

{
    [CN]: {
        "type": [baseType],
        "params": [params]
    }
    (,[CN]: {
        "type": [baseType],
        "params": [params]
    })
}

placeholder	type	explaination
[CN]	string	the CommonName of the client to be configured, used in its certificate
[baseType]	string	a member of BaseType, see below
[params]	object	an object of type Params, see below

example:

{
    "ClientTest1": {
        "type": "LandscapePlan",
        "params": {
            "db": "./api/JSON/LehrerPlan",
            "index1": 0,
            "index2": 1,
            "slideshow": {
                "interval": "5000",
                "timeStart": "2017-6-19 20:10:00",
                "timeEnd": "2017-6-20 20:10:00",
                "params": {
                    "id": "1DOeyOhWo9hjwJDhcMJLW8Kb2kA9SEHAGcuSOLNV9sKU",
                    "iterations": 2,
                    "delay": 1000
                }
            }
        }
    }
}

/api/config/Server

This path is used to configure all settings that affect globally all clients. Useage:

{
    [setting]: [value]
    (,[setting]: [value])
}

placeholder	type	explaination
[setting]	string	setting to be set or modified
[value]	any	value to be set

example:

{
    "defaultTimeout": "5000",
    "pollInterval": 5000
}

/api/config/KeyCode

This path is used to configure what shall be displayed on a keypress. Useage:

{
    [keyCode]: {
        "type": [type],
        "params": [params]
    }
}

placeholder	type	explaination
[keyCpde]	integer	keyCode to be configured
[type]	string	a member of Type, see below
[params]	object	an object of type Params, see below

example:

{
    "32": {
        "type": "FilteredPlan",
        "params": {
            "db": "./api/JSON/LehrerPlan",
            "index1": 0,
            "filter": "And",
            "timeout": 5000
        }
    }
}

/api/config/Presentation

This path is a shortcut to set an presentation for a certain client. Useage:

{
    "CN": [CN],
    "slideshow":[slideshow]
}

placeholder	type	explaination
[CN]	string	CommonName of the client the presentation shall be asigned to
[slideshow]	string	an object of type Slideshow, see below

example:

{
    "CN": "testClient1",
    "slideshow": {
        "interval": "5000",
        "timeStart": "2017-6-19 20:10:00",
        "timeEnd": "2017-6-20 20:10:00",
        "params": {
            "id": "1DOeyOhWo9hjwJDhcMJLW8Kb2kA9SEHAGcuSOLNV9sKU",
            "iterations": 2,
            "delay": 1000
        }
    }
}

BaseType

one of the following:

value	explaination
"LandscapePlan"	View which displays 2 plans in landscape orientation
"PortraitPlan"	View which displays 1 plan in portrait orientation
"MultiplePlan"	View which displays multiple plans in portrait orientation

Type

one of the following:

value	explaination
any BaseType	/
"FilteredPlan"	View which displays multiple plans in portrait orientation with a filter applied
"Png"	View which displays a png

Slideshow

an object containing the following Properties:

property	type	explaination
"db"	string	database used to obtain the plan data from
"interval"	integer	time in ms after which the presentation shall be shown
"timeStart"	string	ISO formatted time to beginn showing the presentation at all
"timeEnd"	string	ISO formatted time to end showing the presentation at all
"params"	Params	object of type Params, see below

Params

an object containing the following Properties, which are optional if not used.

property	type	explaination	used in
"db"	string	database used to obtain the plan data from	any
"index1"	integer	index in db of the first plan which shall be displayed	LandscapePlan, PortraitPlan
"index2"	integer	index in db of the second plan which shall be displayed	PortraitPlan
"firstIndex"	integer	the first index of all plans that shall be displayed	MultiplePlan
"slideshow"	Slideshow	and Shlidshow object that shall be attached to aview	any BaseTypes
"filter"	string	filter to be applied on a filteredPlan page	FilteredPlan
"file"	string	file to be shown, must be an png	Png
"timeout"	integer	timeout in ms until switching from a keypress	FilteredPlan,Png
"id"	string	id of te presentation to be shown	Slideshow
"iterations"	integer	how many times the presentation shall be iterated through	Slideshow
"delay"	integer	time in ms a slide shall be shown before switching to the next one	Slideshow
