EDP Optimize

Interactive demo 📦📦 📦

A JavaScript library for reducing image colors and dithering them to fit (color) eInk displays with optimal visual quality.

We are using it for our eInk picture frames at paperlesspaper.

The library works with both front end js (using the Browser Canvas API) and node.js (using node-canvas)

Blogpost

Btw. you can order our new Spectra 6 eInk picture frame here. 🎉

Supported Displays

• AcEP
• Spectra 6

You can easily add your own displays and use custom color tables.

Features

• Dithering Algorithms: Multiple high-quality dithering options to improve color blending and gradients.
• Color Calibration: Match device-specific color characteristics for more accurate results.

Installation

npm install epdoptimize

Usage Example

<canvas id="inputCanvas" />
<canvas id="ditheredCanvas" />
<canvas id="ditheredCanvasWithDeviceColors" />

import { ditherImage, getDefaultPalettes, getDeviceColors } from 'epdoptimize';

// Access the canvas elements
const inputCanvas = document.getElementById("inputCanvas");
const ditheredCanvas =  document.getElementById("ditheredCanvas");
const ditheredCanvasWithDeviceColors =  document.getElementById("ditheredCanvasWithDeviceColors");

const palette = getDefaultPalettes('spectra6');
const spectra6colors = getDeviceColors('spectra6'); // Spectra 6 color set (can be default, spectra6 or acep)

const options = {
  algorithm: 'floydSteinberg',
  palette,
};

// Dither the image
const dithered = ditherImage(inputCanvas, ditheredCanvas, options);

// Convert the colors to the displays native colors
const prepared = replaceColors(ditheredCanvas,ditheredCanvasWithDeviceColors {
    originalColors: palette,
    replaceColors: spectra6colors
});

Dithering Options

Option	Type	Default	Description
ditheringType	string	"errorDiffusion"	The main dithering algorithm. Options: errorDiffusion, ordered, random, quantizationOnly.
errorDiffusionMatrix	string	"floydSteinberg"	Error diffusion kernel. Options: floydSteinberg, falseFloydSteinberg, jarvis, stucki, burkes, sierra3, sierra2, sierra2-4a.
serpentine	boolean	false	If true, alternates scan direction for each row (serpentine scanning) in error diffusion.
orderedDitheringType	string	"bayer"	Type of ordered dithering. Currently only bayer is supported.
orderedDitheringMatrix	[number, number]	[4, 4]	Size of the Bayer matrix for ordered dithering.
randomDitheringType	string	"blackAndWhite"	Type of random dithering. Options: blackAndWhite, rgb.
palette	string/array	"default"	Palette to use for quantization. Can be a string (predefined) or a custom array of colors.
sampleColorsFromImage	boolean	false	If true, generates palette by sampling colors from the image.
numberOfSampleColors	number	10	Number of colors to sample from the image if sampleColorsFromImage is true.

Add these options to your ditherImage call to customize dithering behavior for your use case.

How It Works

Color Calibration

eInk displays often render colors less vibrantly than their digital values suggest (e.g., a device red like #ff0000 may appear duller in reality). By calibrating with real-world color measurements, the library ensures that dithering and color reduction use the actual appearance of colors on your target display. After processing, you can map the calibrated colors back to the device's required values.

Dithering Algorithms

Dithering helps create the illusion of intermediate colors by distributing quantization errors across neighboring pixels. This is especially important for eInk displays with limited color palettes.

Available Diffusion Algorithms

Algorithm	Description
floydSteinberg	Classic Floyd-Steinberg error diffusion. Distributes error to four neighbors. Visually pleasing.
falseFloydSteinberg	Simplified Floyd-Steinberg. Distributes error to three neighbors. Faster, slightly different look.
jarvis	Jarvis, Judice, and Ninke. Spreads error over three rows for smooth gradients, more blurring.
stucki	Similar to Jarvis, different weights. Balances smoothness and sharpness.
burkes	Simplified Stucki. Fewer neighbors, less computation, good results.
sierra3	Sierra-3 (original). High-quality, less blurring than Jarvis.
sierra2	Reduced Sierra-3. Fewer neighbors, faster, less diffusion.
sierra2-4a	Lightweight, fast. Distributes error to three neighbors. Good for speed-critical use.

Using Your Own Colors

You can use your own custom color palette by passing an array of colors to the palette option. Colors should be provided as hex strings (e.g., #FF0000).

Example:

const myPalette = [
  "#000000", // black
  "#FFFFFF", // white
  "#FF0000", // red
  "#00FF00", // green
  "#0000FF", // blue
];

const options = {
  ditheringType: "errorDiffusion",
  palette: myPalette,
};

const dithered = ditherImage(image, options);

Resources

• paperlesspaper

Credits

• Dither me this
• Inkify

---

Contributions and feedback are welcome!
