Quest ArUco Marker Tracking

This repository enables single and multi-marker detection and tracking using OpenCV with the Passthrough Camera API for Meta Quest 3/3S.
It provides sample scenes that support both ArUco(Single/Multi) and ChArUco(Single) markers for augmented reality applications on Quest devices.

For a demonstration, check out the following videos:

• Single Marker Tracking Demo (ArUco)


• Multi-Marker Tracking Demo (ArUco)


• ChArUco Marker Tracking Demo


---

Dependencies

⚠ Important Notice
When opening the project for the first time, you will likely encounter errors. This is because OpenCV for Unity is not yet installed.
Please ignore the errors initially, proceed to open the project, and install OpenCV for Unity manually.

This project uses OpenCV for Unity.
Please purchase and install it from the Unity Asset Store:
OpenCV for Unity

Tested with OpenCV for Unity v2.6.5.

---

Usage

Marker Preparation

To use this project, please download and install the required marker files from the following links:

• ArUco Markers: ArUcoMarker.pdf
• ChArUco Marker: ChArUcoMarker.pdf

Unity Scenes

• ArUco Marker Tracking (Single & Multi): ArUcoMarkerTracking.unity
• ChArUco Marker Tracking: ChArUcoMarkerTracking.unity

Default Settings

ArUco Marker

• Marker Dictionary: DICT_4X4_50
• Marker Size: 0.1m
  Feel free to modify these settings to suit your needs.

ChArUco Marker

• Marker Dictionary: DICT_4X4_50
• Board Configuration: 5 x 4 squares
• Square Size: 0.05m
  These values are used by default in the ChArUco sample scene. Adjust them as needed.

View Mode Switching

You can switch the view mode by pressing the A button on the controller.

---

How to Change the Number of ArUco Markers

If you want to track multiple ArUco markers simultaneously or change the number of markers in the scene, follow these steps.

1. Open the ArUcoMarkerTracking.unity scene and select the ArUcoTrackingAppCoordinator GameObject.
2. In the Inspector, locate the ArUcoMarkerTrackingAppCoordinator component and find the MarkerGameObjectPairs array.
3. Change the size of this array to match the number of markers you want to use.
4. For each Element, specify:
   • Marker Id: The ID of the marker you want to detect.
   • Game Object: The GameObject to display on top of the detected marker.
5. Important Notes:
   • Make sure there are no duplicate Marker IDs across the Elements.
   • Keep the Marker IDs within the valid range defined by the dictionary you are using (for example, DICT_4X4_50 allows IDs from 0 to 49).

Below is an example of how Marker Id and Game Object pairs are set up in the Inspector:

---

Reference Repositories

This implementation is based on the following sample repositories:

• Unity-PassthroughCameraApiSamples
• QuestCameraKit

---

Contact

If you have any questions, feel free to reach out:

• X (Twitter):
  • @Tks_Yoshinaga
• LinkedIn: Tks Yoshinaga
