- Python >= 3.8.5
- Numpy >= 1.24.4
- Scipy >= 1.10.1
- Numba >= 0.58.1
- ASE >= 3.22.1
- libfp >= 3.1.2
- mpi4py >= 3.1.6
- qepy >= 6.5.0 (optional)
To install the C implementation of Fingerprint Library
First, you need create a conda environment:
conda create -n reformpy python=3.8 pip ; conda activate reformpy
python3 -m pip install -U pip setuptools wheelThen use conda to install LAPACK (or you can load intel module to use MKL):
conda install conda-forge::lapackNext, you need to download the libfp using git:
git clone https://github.com/Rutgers-ZRG/libfp.gitAlso set the corresponding DYLD_LIBRARY_PATH in your .bashrc file as:
export DYLD_LIBRARY_PATH="$CONDA_PREFIX/lib:$DYLD_LIBRARY_PATH"Then:
cd libfp ; python3 -m pip install --no-cache-dir -e .
Then install the remaining Python dependencies through pip
python3 -m pip install numpy>=1.21.4 scipy>=1.8.0 numba>=0.56.2 ase==3.22.1Finally, we can install ReformPy
git clone https://github.com/Rutgers-ZRG/ReformPy.git
cd ReformPy ; python3 -m pip install --no-cache-dir -e .After installation, you can test the integrity of libfp and reformpy in Python3
import libfp
from reformpy.calculator import Reform_CalculatorIf you saw MPI related error, you can try to reinstall mpi4py with MPICH or openmpi.
Following is an example to fix this issue using MPICH on CentOS cluster:
module load intel/17.0.4
python3 -m pip uninstall mpi4py
python3 -m pip install --no-cache-dir "mpi4py<4.0"If you encounter errors when installing qepy from source, you probably need to manually set the build options and flags.
python3 -m pip uninstall -y qepy
cd qepy ; rm -rf build/ dist/ *.egg-infoFollowing is a install_QEpy.sh bash script using intel MKL library:
#!/bin/bash
# Set the installation directory
QE_DIR=$HOME/apps/qepy-qe-7.2
# Clean the old installation
if [ -d "${QE_DIR}" ]; then
echo "Cleaning old QE installation..."
rm -rf ${QE_DIR}
fi
# Set environment variables for compilation
export BLAS_LIBS="-L$MKLROOT/lib/intel64 -lmkl_intel_lp64 -lmkl_sequential -lmkl_core"
export LAPACK_LIBS="-L$MKLROOT/lib/intel64 -lmkl_intel_lp64 -lmkl_sequential -lmkl_core"
export CC=icc
export CXX=icpc
export FC=ifort
export F77=ifort
export F90=ifort
export MPIF90=mpif90
export MPICC=mpicc
export FFLAGS="-fPIC -O3"
export FCFLAGS="-fPIC -O3"
export CFLAGS="-fPIC -O3"
export try_foxflags="-fPIC"
# Extract QE from the release pack
echo "Extracting QE from release pack..."
mkdir -p ${QE_DIR}
tar -xzf $HOME/apps/qe-7.2-ReleasePack.tar.gz -C ${QE_DIR} --strip-components=1
# Configure QE with all necessary flags
echo "Configuring QE..."
cd ${QE_DIR}
# Create make.inc manually to ensure proper configuration
cat > make.inc << EOF
# make.inc for QE 7.2
DFLAGS = -D__FFTW3 -D__MPI
FDFLAGS = \$(DFLAGS)
IFLAGS = -I. -I\$(TOPDIR)/include
CC = icc
CFLAGS = -fPIC -O3
CPPFLAGS = -P -traditional -Uvector
F90 = ifort
MPIF90 = mpif90
F77 = ifort
FFLAGS = -fPIC -O3
FFLAGS_NOOPT = -O0 -g
F90FLAGS = \$(FFLAGS) -cpp
F77FLAGS = \$(FFLAGS)
LD = mpif90
LDFLAGS = -g
# BLAS and LAPACK
BLAS_LIBS = -L\$(MKLROOT)/lib/intel64 -lmkl_intel_lp64 -lmkl_sequential -lmkl_core
LAPACK_LIBS = -L\$(MKLROOT)/lib/intel64 -lmkl_intel_lp64 -lmkl_sequential -lmkl_core
# FFT (use MKL FFT)
FFT_LIBS = -L\$(MKLROOT)/lib/intel64 -lmkl_intel_lp64 -lmkl_sequential -lmkl_core
# MPI
MPI_LIBS =
# SCALAPACK (disabled)
SCALAPACK_LIBS =
# AR and ARFLAGS
AR = ar
ARFLAGS = ruv
# WGET
WGET = wget -O
# ranlib
RANLIB = ranlib
EOF
echo "Fixing specific files with FFTW3 allocate issue..."
if [ -f "FFTXlib/src/fft_scalar.FFTW3.f90" ]; then
sed -i 's/ALLOCATE( data_dp, MOLD=data_dp_aux )/ALLOCATE( data_dp(SIZE(data_dp_aux)) )/g' FFTXlib/src/fft_scalar.FFTW3.f90
sed -i 's/ALLOCATE( data_sp, MOLD=data_sp_aux )/ALLOCATE( data_sp(SIZE(data_sp_aux)) )/g' FFTXlib/src/fft_scalar.FFTW3.f90
fi
echo "Generating dependencies..."
for dir in LAXlib FFTXlib XClib UtilXlib upflib Modules PW PP KS_Solvers; do
echo "Generating dependencies for $dir..."
cd $dir
if [ -d "src" ]; then
cd src
touch make.depend
make depend
cd ..
else
touch make.depend
make depend
fi
cd ..
done
echo "Compiling QE..."
make all -j 8
echo "Cloning QEpy..."
cd ..
if [ -d "qepy" ]; then
echo "Cleaning old QEpy installation..."
rm -rf qepy
fi
git clone https://gitlab.com/shaoxc/qepy.git
cd qepy
export qedir=${QE_DIR}
export qepydev=no # Clean build
echo "Installing QEpy..."
python3 -m pip install --no-cache-dir -e .
echo "Creating test script..."
cat > test_qepy.py << 'EOF'
#!/usr/bin/env python
import os
import sys
try:
import qepy
print("QEpy version:", qepy.__version__)
print("QE directory:", os.environ.get('qedir', 'Not set'))
print("QEpy successfully imported!")
except ImportError as e:
print("Error importing qepy:", e)
try:
import qepy.qepy_pw as qepy_pw
print("Successfully imported qepy_pw module!")
except ImportError as e:
print("Error importing qepy_pw:", e)
EOF
echo "Installation completed. Try running the test script:"
echo "export qedir=${QE_DIR}"
echo "python test_qepy.py"See details for ASE calculator class and ASE calculator proposal
Fingerprint Calculator interface for ASE
Implemented Properties:
'energy': Sum of atomic fingerprint distance (L2 norm of two atomic
fingerprint vectors)
'forces': Gradient of fingerprint energy, using Hellmann–Feynman theorem
'stress': Cauchy stress tensor using finite difference method
Parameters:
atoms: object
Attach an atoms object to the calculator.
contract: bool
Calculate fingerprint vector in contracted Guassian-type orbitals or not
ntype: int
Number of different types of atoms in unit cell
nx: int
Maximum number of atoms in the sphere with cutoff radius for specific cell site
lmax: int
Integer to control whether using s orbitals only or both s and p orbitals for
calculating the Guassian overlap matrix (0 for s orbitals only, other integers
will indicate that using both s and p orbitals)
cutoff: float
Cutoff radius for f_c(r) (smooth cutoff function) [amp], unit in Angstroms
import numpy as np
import ase.io
from ase.optimize import BFGS, LBFGS, BFGSLineSearch, QuasiNewton, FIRE
from ase.optimize.sciopt import SciPyFminBFGS, SciPyFminCG
from ase.constraints import StrainFilter, UnitCellFilter
from ase.io.trajectory import Trajectory
from reformpy.calculator import Reform_Calculator
# from reformpy.mixing import MixedCalculator
# from ase.calculators.vasp import Vasp
atoms = ase.io.read('.'+'/'+'POSCAR')
ase.io.vasp.write_vasp('input.vasp', atoms, direct=True)
trajfile = 'opt.traj'
from functools import reduce
chem_nums = list(atoms.numbers)
znucl_list = reduce(lambda re, x: re+[x] if x not in re else re, chem_nums, [])
ntyp = len(znucl_list)
znucl = znucl_list
calc = fp_GD_Calculator(
cutoff = 6.0,
contract = False,
znucl = znucl,
lmax = 0,
nx = 300,
ntyp = ntyp
)
atoms.calc = calc
# calc.test_energy_consistency(atoms = atoms)
# calc.test_force_consistency(atoms = atoms)
print ("fp_energy:\n", atoms.get_potential_energy())
print ("fp_forces:\n", atoms.get_forces())
print ("fp_stress:\n", atoms.get_stress())
# af = atoms
# af = StrainFilter(atoms)
traj = Trajectory(trajfile, 'w', atoms=atoms, properties=['energy', 'forces', 'stress'])
############################## Relaxation method ##############################
# opt = BFGS(af, maxstep = 1.e-1)
opt = FIRE(af, maxstep = 1.e-1)
# opt = LBFGS(af, maxstep = 1.e-1, memory = 10, use_line_search = True)
# opt = LBFGS(af, maxstep = 1.e-1, memory = 10, use_line_search = False)
# opt = SciPyFminCG(af, maxstep = 1.e-1)
# opt = SciPyFminBFGS(af, maxstep = 1.e-1)
opt.attach(traj.write, interval=1)
opt.run(fmax = 1.e-3, steps = 500)
traj.close()
traj = Trajectory(trajfile, 'r')
atoms_final = traj[-1]
ase.io.write('fp_opt.vasp', atoms_final, direct = True, long_format = True, vasp5 = True)
final_cell = atoms_final.get_cell()
final_cell_par = atoms_final.cell.cellpar()
final_structure = atoms_final.get_scaled_positions()
final_energy_per_atom = float( atoms_final.get_potential_energy() / len(atoms_final) )
final_stress = atoms_final.get_stress()
print("Relaxed lattice vectors are \n{0:s}".\
format(np.array_str(final_cell, precision=6, suppress_small=False)))
print("Relaxed cell parameters are \n{0:s}".\
format(np.array_str(final_cell_par, precision=6, suppress_small=False)))
print("Relaxed structure in fractional coordinates is \n{0:s}".\
format(np.array_str(final_structure, precision=6, suppress_small=False)))
print("Final energy per atom is \n{0:.6f}".format(final_energy_per_atom))
print("Final stress is \n{0:s}".\
format(np.array_str(final_stress, precision=6, suppress_small=False)))If you use this Fingerprint Library (or modified version) for your research please kindly cite our paper:
@article{taoAcceleratingStructuralOptimization2024,
title = {Accelerating Structural Optimization through Fingerprinting Space Integration on the Potential Energy Surface},
author = {Tao, Shuo and Shao, Xuecheng and Zhu, Li},
year = {2024},
month = mar,
journal = {J. Phys. Chem. Lett.},
volume = {15},
number = {11},
pages = {3185--3190},
doi = {10.1021/acs.jpclett.4c00275},
url = {https://pubs.acs.org/doi/10.1021/acs.jpclett.4c00275}
}
If you use Fingerprint distance as a metric to measure crystal similarity please also cite the following paper:
@article{zhuFingerprintBasedMetric2016,
title = {A Fingerprint Based Metric for Measuring Similarities of Crystalline Structures},
author = {Zhu, Li and Amsler, Maximilian and Fuhrer, Tobias and Schaefer, Bastian and Faraji, Somayeh and Rostami, Samare and Ghasemi, S. Alireza and Sadeghi, Ali and Grauzinyte, Migle and Wolverton, Chris and Goedecker, Stefan},
year = {2016},
month = jan,
journal = {The Journal of Chemical Physics},
volume = {144},
number = {3},
pages = {034203},
doi = {10.1063/1.4940026},
url = {https://doi.org/10.1063/1.4940026}
}
