Storage in Kubernetes MASTERCLASS

Video reference for the MASTERCLASS is the following:

⭐ Support the Project

If this repository helps you, give it a ⭐ to show your support and help others discover it!

Introduction
Understanding Storage in Docker
Storage in Docker: How Does It Work?
- 1. Storage Drivers
- 2. Volume Drivers
How Docker Storage Works on macOS, Windows, and Linux
Understanding Docker Volumes
- Where Are Docker Volumes Stored?
Demo: With Persistent Storage (Docker Volume)
- Note for macOS and Windows Users
Types of Docker Volumes: Which to Use When?
Kubernetes Core and Extended Architecture
Ephemeral Storage
- EmptyDir
- Demo: emptyDir
Downward API
- Why is it Used?
- Demo: downwardAPI - Environment variables
- Demo: downwardAPI - Files via Volumes
ConfigMaps & Secrets (Preview)
Evolution of Storage in Kubernetes: From In-Tree to CSI Drivers
Persistent Storage
- hostPath
- Demo: hostPath
Persistent Volumes (PVs) & Persistent Volume Claims (PVCs)
- Understanding Scope & Relationships of PV and PVC in Kubernetes
- 1-to-1 Binding Relationship Between PVC and PV
- Kubernetes Persistent Storage Flow (Manual Provisioning)
- Demo: Persistent Volumes and PVCs with Reclaim Policy
Access Modes in Kubernetes Persistent Volumes
- Explanation of Storage Types
- Key Differences: Block Storage vs. File Storage
Reclaim Policies in Kubernetes
PVC and PV Binding Conditions
Storage Classes & Dynamic Provisioning
- Dynamic Provisioning in Action
- Demo: Storage Class
ConfigMaps
- Demo 1: Using ConfigMap as Environment Variables
- Demo 2: Using ConfigMap as a Configuration File (Volume Mount)
- Best Practices for ConfigMap
Kubernetes Secrets
- Demo 1: Injecting Secrets into a Pod
- Best Practices for Using Kubernetes Secrets
Understanding Dynamic Updates with ConfigMaps and Secrets
Conclusion
References

Introduction

This MASTERCLASS on Storage in Kubernetes provides a deep and structured walkthrough of storage concepts starting from Docker to advanced Kubernetes volumes. Whether you're preparing for the CKA exam or aiming to gain a robust understanding of containerized storage in production environments, this session offers a unified view of how ephemeral and persistent storage is managed.

The session begins by exploring how Docker handles image layers, writable layers, and the use of storage and volume drivers. It then transitions into Kubernetes, covering core and modular architecture, ephemeral storage mechanisms like emptyDir, the use of hostPath, and the lifecycle of Persistent Volumes (PVs) and Persistent Volume Claims (PVCs). Special attention is given to ConfigMaps, Secrets, reclaim policies, access modes, volume modes, and the CSI plugin architecture that powers modern Kubernetes storage management.

This content merges Days 24 to 28 of the CKA 2025 course, offering hands-on demos, YAML manifests, and clear explanations to ensure learners can apply concepts directly to real-world Kubernetes clusters.

Understanding Storage in Docker

Imagine we have a host system—this could be a VM or your laptop—that has the Docker Engine installed. We’re hosting three containers on this host: Container 1, Container 2, and Container 3. All these containers are based on an image created using the following Dockerfile:

FROM python:3.9-slim
WORKDIR /app
ADD app.py app.py
RUN pip install flask
EXPOSE 5000
CMD ["python", "app.py"]

We’ve already discussed this Dockerfile in Day-3’s lecture. You can revisit the lecture for a recap:

YouTube link: Day-3 Lecture
GitHub link: Day-3 Resources

The image created from this Dockerfile is named my-image and has a size of approximately 50MB (used here for simplicity; actual size may vary).

Layers in a Dockerfile

The instructions in the Dockerfile are a mix of layer-creating instructions and non-layer-creating instructions. These layers play a key role in determining the image size. If your Dockerfile contains multiple layer-creating instructions, it results in a larger image size. This is why multi-stage builds are often recommended—they allow the separation of layer-creating instructions into different "stages," producing more optimized and smaller images.

To deepen your understanding of multi-stage Docker builds (Day 5), you can explore the following resources:

YouTube Tutorial: Multi-Stage Docker Builds Explained
GitHub Repository: Day 05: Multi-Stage Docker Builds

Layer-Creating Instructions	Non-Layer-Creating Instructions
`FROM`, `RUN`, `COPY`, `ADD`	`CMD`, `ENTRYPOINT`, `WORKDIR`, `EXPOSE`, `ENV`, `LABEL`, `USER`, `VOLUME`, `STOPSIGNAL`, `ARG`

Example: Layers in Our Dockerfile

Let’s review the Dockerfile to identify which instructions create new layers:

Layer-Creating Instructions:
- FROM python:3.9-slim: Defines the base image.
- ADD app.py app.py: Copies the app.py file into the image.
- RUN pip install flask: Installs Flask (creates a new layer).
Non-Layer-Creating Instructions:
- WORKDIR /app: Sets the working directory.
- CMD ["python", "app.py"]: Defines the default command.
- EXPOSE 5000: Exposes port 5000.

How to Inspect Image Layers

You can inspect the layers of a Docker image using the docker image history command. For example:

docker image history my-image

This will display a breakdown of the instructions and how much storage each layer-creating instruction contributes. Here’s an example output:

IMAGE          CREATED        CREATED BY                                      SIZE      COMMENT
dbc9f6d3b551   17 hours ago   CMD ["python" "app.py"]                         0B        buildkit.dockerfile.v0
<missing>      17 hours ago   EXPOSE map[5000/tcp:{}]                         0B        buildkit.dockerfile.v0
<missing>      17 hours ago   RUN /bin/sh -c pip install flask # buildkit     11.5MB    buildkit.dockerfile.v0
<missing>      17 hours ago   ADD app.py app.py # buildkit                    170B      buildkit.dockerfile.v0
<missing>      17 hours ago   WORKDIR /app                                    0B        buildkit.dockerfile.v0
<missing>      3 months ago   FROM python:3.9-slim                            97.1MB    debuerreotype 0.15

How Docker Containers Use Image Layers

When you create a container from an image:

Read-Only Layers:
The layers in the image are read-only. Each container shares the same image layers, meaning if your image is 50MB, all containers will collectively use the same 50MB of storage for those read-only layers.
Writable Layer (Delta Data):
Any new changes or files you add to the container are stored in a writable layer unique to that container. This is known as delta data.

Storage Calculation Example

Let’s assume:

The base image size is 50MB.
Three containers are running from the same image:
- Container 1: Adds 4MB of new data (delta).
- Container 2: Adds 10MB of new data.
- Container 3: Adds 6MB of new data.

Total Storage Usage:

Shared image layers: 50MB (used by all containers).
Delta data: 4MB + 10MB + 6MB = 20MB.
Final Total: 50MB + 20MB = 70MB.

Handling Data Loss in Writable Layers

Since the image layers are read-only, any changes made to the container are stored in the writable layer. If a container is stopped or fails:

For instance, if Container 2 stops, the 10MB of delta data in its writable layer will be lost.
This highlights the need for a mechanism to persist container data, ensuring important data survives beyond the container's lifecycle.

Need for Persistent Storage

To avoid such data loss, Docker provides volumes—a powerful mechanism for storing data outside the container in a persistent manner. Volumes allow data to be accessible and survive even when containers are stopped, restarted, or deleted.

Storage in Docker: How Does It Work?

When you create a Docker container, it needs a way to store data. Docker achieves this with two key components:

Storage Drivers
Volume Drivers

1. Storage Drivers

Purpose:
Storage drivers handle ephemeral container data, which exists only during the lifecycle of a container. When a container is removed, any data stored by the storage driver is lost unless persistent storage (e.g., volumes) is explicitly configured.
Analogy:
Think of storage drivers as the file systems for containers, responsible for managing and organizing how container-internal storage operates.
Key Responsibilities:
1. Manage the container layers, which include the base image and any subsequent changes made during runtime.
2. Organize files and ensure efficient storage operations inside the container.
Kubernetes Connection:
Kubernetes relies on storage drivers through container runtimes like containerd or CRI-O. These runtimes use storage drivers (e.g., OverlayFS) to handle ephemeral container data in the same way Docker does.
Common Examples of Docker Storage Drivers:
- OverlayFS: The default storage driver on most modern Linux distributions. It efficiently handles layered filesystems by creating a "stack" of read-only and writable layers.
- AUFS: A legacy driver used on older systems. It has been replaced by OverlayFS due to better performance and simplicity.
- ZFS: An advanced storage driver that supports snapshots, compression, and scalable storage. Ideal for environments requiring advanced data management.
- Btrfs: A modern, high-performance storage driver that supports features like snapshots, quotas, and subvolumes, making it suitable for large-scale and complex storage requirements.
Why It Matters:
Storage drivers are crucial for handling ephemeral data efficiently, but they are not designed to manage persistent storage. That’s why Docker and Kubernetes use volume drivers for data that must persist beyond the lifecycle of a container.

Check your storage driver:

docker info

Look for: Storage Driver: overlay2

Inside the VM, Docker typically uses the overlay2 storage driver. This driver manages image layers and the writable container layer.

2. Volume Drivers

Purpose:
Volume drivers manage persistent data storage that exists outside the container’s lifecycle. They allow data to survive beyond container restarts, failures, or deletions, ensuring long-term accessibility.
Analogy:
Think of volume drivers as external hard drives for containers, providing a separate, reliable space to store and manage data that needs to persist independently of the containers.
Key Responsibilities:
1. Provide a mechanism to store data outside the ephemeral writable layer of containers.
2. Allow data sharing between multiple containers, enabling collaborative or distributed workflows.
3. Integrate with external storage systems for advanced storage solutions (e.g., cloud-based storage or networked file systems).
Kubernetes Connection:
- Kubernetes operates similarly but manages Persistent Volumes (PVs) at the cluster level, instead of at the container level.
- Kubernetes uses Persistent Volume Claims (PVCs) as an abstraction for applications to request storage, with backend storage provisioned by CSI drivers.
- Storage in Kubernetes integrates with volume drivers, enabling flexibility across nodes and distributed systems.
Common Examples of Volume Drivers:
- Local (Default Driver):
  - Provides local storage on the host machine.
  - Simple and reliable for most use cases, but limited to the host.
- NFS (Network File System):
  - Offers shared storage that multiple containers can access across hosts.
  - Useful in distributed environments requiring shared data.
- AWS EBS (Elastic Block Store):
  - Cloud storage for containers running on AWS infrastructure.
  - Highly scalable and integrates with other AWS services.
- Azure Disks:
  - Microsoft’s cloud-based storage solution.
  - Ideal for containers running in Azure environments.
Why It Matters:
1. Volumes decouple data from the container lifecycle, ensuring it remains intact regardless of container states.
2. They enable seamless integration with external storage systems, making them ideal for production and distributed applications.
3. Volume drivers allow data portability, scalability, and reliability, especially for large-scale, multi-container deployments.

Check your Volume Drivers

Docker uses the local volume driver by default.
On macOS and Windows, volumes live inside the VM (not directly visible from the host).

To share files between host and container, you can bind-mount a host directory:

macOS:

docker run -v /Users/yourname/data:/app/data ...

Windows:

docker run -v C:\Users\yourname\data:/app/data ...

Inspect a volume:

docker volume inspect <volume_name>

Look for: "Driver": "local"

Note: Kubernetes Storage vs Docker Volumes
While Docker uses volumes to save data and storage drivers to handle temporary container files, Kubernetes takes things a step further—especially when you have many machines working together in a cluster.

In Kubernetes:

It introduces something called Persistent Volumes (PVs) – think of these like shared hard drives for your apps.
And then there are Persistent Volume Claims (PVCs) – your app just "asks" for the storage it needs, and Kubernetes takes care of finding it.

Behind the scenes, Kubernetes uses special plugins called CSI (Container Storage Interface) drivers to connect to storage from different cloud providers like AWS EBS, Azure Disks, or NFS.

For short-term (temporary) data, Kubernetes still uses the same type of storage drivers as Docker – like overlay2.

We’ll break all this down more clearly in the next lecture, where we’ll talk about how Kubernetes makes managing storage across multiple servers much easier.

How Docker Storage Works on macOS, Windows, and Linux

Docker behaves differently depending on the operating system because containers require a Linux kernel. Here's how storage is handled across platforms:

Linux

On Linux, Docker runs natively without any virtualization layer.
Storage and volumes are created directly on the host filesystem.
You can access Docker volumes at:
```
/var/lib/docker/volumes
```

macOS and Windows

Docker does not run natively on macOS or Windows. Instead, Docker Desktop provides a Linux environment using a lightweight virtual machine.

OS	Virtualization Backend
macOS	Docker Desktop uses a Linux VM via the Apple Virtualization Framework (previously HyperKit)
Windows	Docker Desktop uses WSL 2 (Windows Subsystem for Linux) to run the Linux kernel

Can You Install Docker Engine Directly on macOS or Windows?

❌ No, not directly like on Linux.

Both macOS and Windows do not have a native Linux kernel, which Docker Engine requires to run containers.
Docker Engine relies heavily on Linux features like cgroups, namespaces, and UnionFS (e.g., overlay2) — which are unavailable on macOS and Windows.

NOTE: While you can install Docker Desktop on a Linux system, it’s generally not recommended because Linux natively supports Docker Engine, which is more lightweight and efficient. When you run Docker Desktop on Linux, it still creates a lightweight virtual machine using the system's virtualization technology, adding an unnecessary layer of overhead compared to using Docker Engine directly on the host.

Understanding Docker Volumes

Now that we’ve understood Docker image layers and how storage works during image creation, let’s move on to another critical aspect of Docker: Volumes.

In Docker, containers are ephemeral by default—this means any data created inside a container is lost when the container is deleted. To persist data beyond the container lifecycle, we use Docker volumes.

Benefits of Docker Volumes

Data Persistence:
Ensures data is not lost when containers restart or are removed.
Sharing Data Between Containers:
Enables multiple containers to access and modify the same data.
Performance Optimization:
Using external storage systems (via volume drivers) can improve performance and scalability.

Where Are Docker Volumes Stored?

By default, Docker stores volumes inside the Docker host at:

/var/lib/docker/volumes

Every time you create a named volume, Docker creates a corresponding directory under the path above. This allows data to survive container restarts, recreation, and even deletions.

Demo: With Persistent Storage (Docker Volume)

Now let’s do the same thing, but with a named volume mounted to /app.

🧪 We’ll create another container named my-cont-2 and mount a volume to persist data.

docker volume create my-vol
docker run -d --name my-cont-1 -v my-vol:/app my-image

Then, exec into the container and create the file again:

docker exec -it my-cont-1 bash
cd /app
echo "This is my delta data" > file.txt
cat file.txt   # ✅ File exists

Now, delete the container:

docker rm -f my-cont-1

Even though the container is gone, the data still exists. You can verify this by checking the volume’s data directly:

sudo cat /var/lib/docker/volumes/my-vol/_data/file.txt
# Output: This is my delta data

This is the power of Docker volumes—your data is decoupled from the container’s lifecycle.

Note for macOS and Windows Users

On Linux, Docker runs natively and stores volumes under:

/var/lib/docker/volumes

However, on macOS (and Windows), Docker runs inside a lightweight virtual machine (VM) using a technology like HyperKit or WSL2, depending on the system.

As a result, you won’t find the /var/lib/docker/volumes directory on your local Mac filesystem — it exists inside the Docker VM.

How to Access Volume Data on macOS:

If you're on macOS/Windows and want to inspect volume data:

Use Docker commands to access it via the container:

docker run -it --rm -v my-vol:/app alpine sh
cd /app
ls -l

Or use docker cp to copy data from a container to your local filesystem:
```
docker cp my-cont-2:/app/file.txt .
```

Types of Docker Volumes: Which to Use When?

Docker supports different volume types, and each has its own use case:

Type	Use Case	Pros	Cons
Named Volume	Default Docker-managed volumes (e.g., `my-vol`)	Easy to use, portable, survives container deletion	Abstracted path, may need extra step for backups
Bind Mount	Mount a specific host directory to the container	Full control, real-time syncing, easy for dev work	Tied to host path, can cause permission issues
tmpfs Mount	Temporary in-memory mount (data lost on restart)	Fast, doesn't write to disk	Data not persistent, only useful for short-term use

In most production use-cases, named volumes are preferred because they are managed, portable, and persistent.
For development and local testing, bind mounts are useful when you want to sync code from your local machine into the container.

Kubernetes Core and Extended Architecture

Kubernetes is a powerful container orchestration platform built on a modular design. This modularity enables flexibility, scalability, and extensibility. The core components handle essential orchestration tasks, while plugins, add-ons, and third-party extensions extend functionality without bloating the core system.

This section clarifies the distinction between Kubernetes Core and External Extensions, explaining how various components interact within the overall architecture.

Kubernetes Core Architecture

What is Kubernetes Core?

The Kubernetes Core consists of essential built-in components responsible for cluster management and orchestration. These components are categorized into Control Plane Components and Node Components.

1️⃣ Control Plane Components

The control plane manages cluster operations, making scheduling decisions and maintaining the desired state.

API Server: The central control plane component that validates and processes REST API requests, enforcing security policies and forwarding requests to relevant components.
Scheduler: Assigns Pods to nodes based on resource availability and scheduling policies.
Controller Manager: Runs control loops to maintain the desired state (e.g., replication, endpoint management).
etcd: A distributed, consistent key-value store that persistently stores all cluster state and configuration data.
Cloud Controller Manager: Manages cloud-provider-specific integrations such as external load balancers, persistent storage provisioning, and node lifecycle management.

2️⃣ Node Components

Nodes are the worker machines that run containerized workloads.

kubelet: The primary node agent that ensures containers are running as expected.
kube-proxy: Maintains network rules on each node, enabling seamless service discovery and communication between Pods.

Kubernetes Extensions: Beyond the Core

While the Kubernetes Core provides essential orchestration functionalities, additional features like networking, storage, monitoring, and security are implemented via external components.

1️⃣ Plugins

Plugins extend Kubernetes by enabling external integration while adhering to standardized APIs.

CNI (Container Network Interface), CRI (Container Runtime Interface), and CSI (Container Storage Interface) are standardized interfaces that define how networking, runtime, and storage components interoperate with Kubernetes. These interfaces adhere to specifications that are developed and maintained by the Kubernetes community under the governance of the CNCF. Although the CNCF endorses these standards, it is the community that actively defines and updates the specifications.

Anyone can develop their own plugins for CNI, CRI, and CSI as long as they conform to these specifications, ensuring compatibility and interoperability within Kubernetes environments.

Container Network Interface (CNI): Configures Pod networking and IP allocation.
Container Storage Interface (CSI): Manages external storage solutions.
Container Runtime Interface (CRI): Allows Kubernetes to interact with various container runtimes (e.g., containerd, CRI-O).

CRI Plugins (Container Runtimes)

(The following list is indicative, not exhaustive.)

Plugin	Description
containerd	Default for most Kubernetes setups; lightweight, optimized, and follows OCI standards.
CRI-O	Minimal runtime designed for Kubernetes; integrates tightly with OpenShift.
Kata Containers	Uses lightweight VMs for security; ideal for isolating untrusted workloads.
gVisor (by Google)	User-space sandboxing for enhanced security; limits direct host access.

CNI Plugins (Networking)

(The following list is indicative, not exhaustive.)

Plugin	Description
Calico	Supports network policies and BGP routing; ideal for security-focused environments.
Cilium	High-performance with eBPF-based networking; excels in observability and security.
Flannel	Lightweight and simple; lacks network policy support.
Weave Net	Provides encrypted pod-to-pod communication; supports multi-cluster setups.

CSI Plugins (Storage)

(The following list is indicative, not exhaustive.)

Plugin	Description
Amazon EBS CSI	Provides block storage for Kubernetes workloads on AWS; supports dynamic provisioning.
Azure Disk CSI	Offers high-performance, persistent storage for Kubernetes on Azure.
Google PD CSI	Integrates with Google Cloud Persistent Disks; supports snapshots and resizing.
Ceph RBD CSI	Ideal for scalable, distributed storage; supports snapshots and cloning.
Portworx CSI	Enterprise-grade storage with high availability, backups, and replication.
OpenEBS CSI	Lightweight and cloud-native storage for Kubernetes; optimized for local PVs.
Longhorn CSI	Rancher’s distributed block storage for Kubernetes; supports snapshots and disaster recovery.

Responsibilities of CRI, CNI, and CSI in Kubernetes

(The responsibilities listed below are indicative, not exhaustive.)

CRI (Container Runtime Interface) - Manages Container Lifecycle

Pulls container images from registries.
Starts, stops, and deletes containers.
Manages container networking via CNI integration.
Handles logging and monitoring of containers.
Allocates resources like CPU and memory to containers.
Ensures compatibility with Kubernetes via standardized gRPC APIs.

CNI (Container Network Interface) - Manages Pod Networking

Assigns IP addresses to pods.
Enables communication between pods across nodes.
Manages network policies for security and isolation.
Supports service discovery and DNS resolution.
Integrates with cloud and on-prem networking solutions.
Provides network metrics and observability features.

CSI (Container Storage Interface) - Manages Storage for Pods

Dynamically provisions persistent storage for workloads.
Supports mounting and unmounting of storage volumes.
Handles volume resizing, snapshots, and backups.
Ensures data persistence across pod restarts.
Integrates with various cloud and on-prem storage providers.
Manages access controls and multi-node storage sharing.

2️⃣ Add-Ons

Add-ons enhance Kubernetes with additional functionalities:

Ingress Controllers: Handle external access, load balancing, and routing.
Monitoring Tools: Observability tools like Prometheus and Grafana.
Service Meshes: Solutions like Istio and Linkerd enhance inter-service communication.

3️⃣ Third-Party Extensions

Third-party tools and solutions integrate seamlessly into Kubernetes:

Helm: Kubernetes package manager for simplified deployment.
Prometheus: Monitoring and alerting system for cloud-native applications.
Istio: Service mesh for security, traffic management, and observability.

Deep Dive into Kubernetes Interfaces

Kubernetes uses standardized interfaces for seamless extensibility. The three primary interfaces are CSI, CNI, and CRI, each designed to manage storage, networking, and runtime integration.

Overview of Kubernetes Interfaces

Interface	Purpose	Key Features	Common Implementations
Container Storage Interface (CSI)	Enables external storage integration without modifying Kubernetes core.	- Decouples storage drivers from Kubernetes. - Supports snapshots, volume expansion, and lifecycle management. - Uses gRPC-based APIs (`CreateVolume`, `DeleteVolume`, etc.).	- AWS EBS CSI Driver - GCE Persistent Disk CSI Driver - Ceph RBD CSI Driver
Container Network Interface (CNI)	Standardizes how Kubernetes manages networking.	- Configures Pod networking and IP allocation. - Supports network policies and encryption. - Enables scalable and secure communication.	- Calico (Network policies) - Cilium (eBPF-based performance) - AWS VPC CNI (AWS-native networking) - Weave Net (Encrypted multi-cluster networking)
Container Runtime Interface (CRI)	Defines how Kubernetes interacts with different container runtimes.	- Manages container lifecycle (image pulling, creation, execution, logging). - Ensures runtime consistency. - Enables Kubernetes to work with multiple runtimes.	- containerd (Lightweight, Kubernetes-native) - CRI-O (Minimal runtime for Kubernetes) - Podman (Daemonless alternative) - Docker (Previously supported via dockershim; now deprecated)

Why Kubernetes Uses a Plugin-Based Architecture?

Kubernetes’ plugin-based architecture is fundamental to its flexibility, scalability, and vendor neutrality. Here’s why:

Interoperability: Kubernetes interacts with various networking, storage, and runtime solutions without tight integration into its core.
Flexibility & Vendor Neutrality: Users can select the best tools for their workloads without being locked into a specific vendor.
Encourages Innovation: Plugin developers can iterate and improve their solutions independently, without requiring changes to Kubernetes itself.
Scalability & Maintainability: Individual components can be scaled and upgraded independently, improving reliability and maintainability.

For example, Cilium, a CNI plugin using eBPF, enhances network security and observability without requiring modifications to Kubernetes' core networking model. This level of extensibility allows Kubernetes to adapt seamlessly across different infrastructure environments.

Key Takeaways

Kubernetes Core consists of essential control plane and node components (API Server, Scheduler, Controller Manager, etc.).
Plugins (CNI, CSI, CRI) and Add-ons (Ingress, Monitoring, Service Mesh) extend Kubernetes functionality beyond the core.
CSI allows for scalable and flexible storage integrations while adhering to strict API compliance.
Modular architecture ensures vendor neutrality, encourages innovation, and simplifies upgrades.
Kubernetes’ plugin ecosystem plays a crucial role in its extensibility, allowing it to adapt to diverse infrastructure needs.

Ephemeral Storage

Ephemeral storage refers to storage that is temporary, meaning that any data written to it only lasts for the duration of the Pod’s lifetime. When the Pod is deleted, the data is also lost.

EmptyDir

What is EmptyDir?

emptyDir is an empty directory created when a Pod is assigned to a node. The directory exists for the lifetime of the Pod.
If you define an emptyDir volume in a Deployment, each Pod created by the Deployment will have its own unique emptyDir volume. Since emptyDir exists only as long as the Pod is running, any data stored in it is lost when the Pod is terminated or deleted.
Defining an emptyDir in a Deployment ensures that each Pod replica gets its own isolated temporary storage, independent of other replicas. This is particularly useful for workloads where each Pod requires scratch storage that doesn’t need to persist beyond the Pod’s lifecycle.

Why is it Used?
It is ideal for scratch space (Temporary workspace for processing.), caching, or temporary computations where data persistence isn’t required.

Sure! Here's a refined and enhanced version of your message that improves clarity, grammar, and flow, while keeping the technical concepts intact:

Writable vs Read-Only Layers in Containers (Day 24 Recap)

In Day 24, we explored how container images work under the hood—specifically the concept of read-only and writable layers.

Let’s break it down:

If a Pod has three containers that all use the same container image, they share the read-only image layer to save space and optimize resource usage. However, each container still gets its own writable layer. So, any file changes or modifications done by one container remain isolated and are not visible to the others.

But what if you want them to share data?

That’s where volumes come into play—specifically, an emptyDir volume. If you mount the same emptyDir volume into all three containers, they now have access to a shared writable space. This allows them to collaborate and share data during the Pod’s lifetime, effectively creating a shared writable layer across containers.

Check out the Day 24 content below: GitHub: Day 24 GitHub Notes
YouTube: Day 24 YouTube Video

Demo: emptyDir

apiVersion: v1  # Specifies the API version used to create the Pod.
kind: Pod       # Declares the resource type as a Pod.
metadata:
  name: emptydir-example  # Name of the Pod.
spec:
  containers:
  - name: busybox-container  # Name of the container inside the Pod.
    image: busybox           # Using the lightweight BusyBox image.
    command: ["/bin/sh", "-c", "sleep 3600"]  # Overrides the default command. Keeps the container running for 1 hour (3600 seconds).
    volumeMounts:
    - mountPath: /data       # Mount point inside the container where the volume will be accessible.
      name: temp-storage     # Refers to the volume defined in the `volumes` section below.
  - name: busybox-container-2  # Name of the container inside the Pod.
    image: busybox           # Using the lightweight BusyBox image.
    command: ["/bin/sh", "-c", "sleep 3600"]
    volumeMounts:
    - mountPath: /data
      name: temp-storage
  volumes:
  - name: temp-storage       # Name of the volume, must match the name in `volumeMounts`.
    emptyDir: {}             # Creates a temporary directory that lives as long as the Pod exists.
                            # Useful for storing transient data that doesn't need to persist.

Here, /data is an emptyDir volume that will be removed along with the Pod.

Verification

We will now verify that both containers within the same Pod can access the shared volume mounted using emptyDir.

Step 1: Create a file from busybox-container

kubectl exec emptydir-example -c busybox-container -- sh -c 'echo "What a file!" > /data/myfile.txt'

This command writes the string "What a file!" to a file named myfile.txt inside the shared /data directory.

Step 2: Read the file from busybox-container-2

kubectl exec emptydir-example -c busybox-container-2 -- cat /data/myfile.txt

Expected Output:

What a file!

Key Takeaway:

This demonstrates that both containers within the same Pod can access and share the same volume mounted using emptyDir.
This level of sharing is not possible with the Pod's default ephemeral storage, as each container has its own isolated writable layer.
Using emptyDir enables inter-container file sharing within a Pod.

Downward API

What is the Downward API?
The Downward API in Kubernetes provides a mechanism for Pods to access metadata about themselves or their environment. This metadata can include information such as the Pod's name, namespace, labels, annotations, or resource limits. It is injected into containers in a Pod either as environment variables or through mounted files via volumes.

When the Downward API is configured in a Deployment, each Pod created by the Deployment gets its own unique set of metadata based on the Pod's attributes. This allows Pods to retrieve runtime-specific details dynamically, without hardcoding or manual intervention.

Why is it Used?

Dynamic Configuration: Enables applications to dynamically retrieve Pod-specific metadata, such as labels or resource limits.
Self-Awareness: Makes Pods aware of their environment, including their name, namespace, and resource constraints.
Simplifies Configuration Management: Helps eliminate the need for manual configuration by providing metadata directly to the containers.

💡 Did You Know?

Back in Day 21, we discussed the sidecar pattern—a powerful design pattern in Kubernetes often used for logging, monitoring, and proxy use cases. These sidecar (helper) containers frequently rely on the Downward API to access real-time metadata such as the Pod name, namespace, labels, and resource limits.

Without the Downward API, these sidecars would need to continuously poll the Kubernetes API server to fetch this metadata, increasing API server load and introducing unnecessary network overhead. By using the Downward API, they can access this data locally within the Pod, improving performance and offloading the API server.

For example, imagine you're running a monitoring agent as a sidecar, and you want to collect metrics or logs for all Pods within a specific namespace like app1-ns. If the agent doesn’t know which Pod it's running in or which namespace it belongs to, it wouldn't be able to label or filter that data correctly. The Downward API solves this problem by injecting runtime-specific metadata directly into the container, making it self-aware.

👉 Explore Day 21 (Sidecar Pattern):
GitHub: Day 21 GitHub Notes YouTube: Day 21 YouTube Video

Demo: downwardAPI - Environment variables

apiVersion: v1
kind: Pod
metadata:
  name: downwardapi-example
  labels:
    app: demo
spec:
  containers:
  - name: metadata-container
    image: busybox
    command: ["/bin/sh", "-c", "env && sleep 3600"]
    # The container prints all environment variables and then sleeps for 1 hour.
    env:
    - name: POD_NAME
      valueFrom:
        fieldRef:
          fieldPath: metadata.name
      # Creates an environment variable named POD_NAME.
      # The value of this variable is set dynamically using the Downward API.
      # It pulls the Pod's name (in this case, "downwardapi-example") from its metadata.
    - name: POD_NAMESPACE
      valueFrom:
        fieldRef:
          fieldPath: metadata.namespace
      # Creates an environment variable named POD_NAMESPACE.
      # The value of this variable is set dynamically using the Downward API.
      # It pulls the Pod's namespace (e.g., "default") from its metadata.

Verification

Run the following kubectl exec command to execute env inside the container:

kubectl exec downwardapi-example -- env | grep POD_

You should see output like:

POD_NAME=downwardapi-example
POD_NAMESPACE=default

This confirms that:

POD_NAME is set to the Pod’s name.
POD_NAMESPACE is set to the namespace it's running in (usually default, unless specified otherwise).

Demo: downwardAPI - Files via Volumes

apiVersion: v1
kind: Pod
metadata:
  name: downwardapi-volume
  labels:
    app: good_app
    owner: hr
  annotations:
    version: "good_version"
spec:
  containers:
  - name: metadata-container
    image: busybox
    command: ["/bin/sh", "-c", "cat /etc/podinfo/* && sleep 3600"]
    # The container will display the contents of all files under /etc/podinfo (i.e., metadata)
    # and then sleep for an hour, keeping the pod alive for verification.
    volumeMounts:
    - name: downwardapi-volume
      mountPath: /etc/podinfo
      # Mounts the downward API volume at /etc/podinfo inside the container.
  volumes:
  - name: downwardapi-volume
    downwardAPI:
      items:
      - path: "labels"
        fieldRef:
          fieldPath: metadata.labels
        # Writes the Pod's labels to a file named 'labels' under /etc/podinfo.
      - path: "annotations"
        fieldRef:
          fieldPath: metadata.annotations
        # Writes the Pod's annotations to a file named 'annotations' under /etc/podinfo.

Verification

Step 1: Exec into the Pod

kubectl exec -it downwardapi-volume -- /bin/sh

Once inside the container shell, run:

cd /etc/podinfo
ls -l

You should see symbolic links:

annotations -> ..data/annotations
labels -> ..data/labels

These links are created because Kubernetes uses a projected volume with the Downward API, which manages file updates using symlinks pointing to the ..data/ directory. This allows for atomic updates.

Step 2: View the Contents

Check the content of each file:

cat labels

Expected output:

app="good_app"
owner="hr"

cat annotations

Expected output:

version="good_version"

These values are directly fetched from the pod’s metadata and written to files using the Downward API.

Step 3: Verify Using Pod Logs

Since the pod's container command was set to:

command: ["/bin/sh", "-c", "cat /etc/podinfo/* && sleep 3600"]

The contents of /etc/podinfo/labels and /etc/podinfo/annotations will be printed in the pod's logs when it starts. To view them:

kubectl logs downwardapi-volume

Expected output:

app="good_app"
owner="hr"
version="good_version"

This further confirms that the Downward API volume successfully mounted the metadata into the container at runtime.

ConfigMaps & Secrets (To Be Discussed in Next Lecture)

Overview:
ConfigMaps and Secrets are Kubernetes objects designed to inject configuration data and sensitive information into Pods. While they exist independently of Pods, when mounted as volumes, the data is temporary and only available for the Pod’s lifetime.
Why are they Used?
They allow the decoupling of configuration from application code and the secure injection of sensitive data, simplifying management across multiple Pods.

Evolution of Storage in Kubernetes: From In-Tree to CSI Drivers

Managing persistent storage in Kubernetes has come a long way. Initially, storage drivers were built directly into Kubernetes' core codebase, known as in-tree volume plugins. Over time, this tightly coupled model proved limiting, leading to the adoption of the Container Storage Interface (CSI)—a modular and extensible solution for storage integration.

This write-up explores the transition from in-tree plugins to CSI drivers and explains where commonly-used storage types fit into Kubernetes today.

1. In-Tree Volume Plugins: The Legacy Model

In-tree volume plugins were integrated directly into Kubernetes' codebase. Adding or updating these plugins required modifying Kubernetes itself, resulting in several drawbacks:

Maintenance was cumbersome and tied to Kubernetes release cycles.
Vendors could not independently develop or release updates.
Bugs in storage drivers could affect Kubernetes core functionality.

Examples of In-Tree Plugins:

awsElasticBlockStore (AWS EBS)
azureDisk, azureFile
gcePersistentDisk (GCE PD)
nfs, glusterfs
rbd (Ceph RADOS Block Device)
iscsi, fc (Fibre Channel)

Note: Most in-tree plugins are deprecated and replaced with CSI drivers.

2. Container Storage Interface (CSI): The Modern Standard

To address the limitations of in-tree plugins, Kubernetes adopted the Container Storage Interface (CSI), developed by the Cloud Native Computing Foundation (CNCF). CSI decouples storage driver development from Kubernetes core, allowing vendors to independently create and maintain their drivers.

Key Benefits of CSI:

Independent updates: Vendors can release drivers without waiting for Kubernetes updates.
Faster development: Features and fixes are delivered more quickly.
Flexibility: CSI supports advanced capabilities like snapshotting, resizing, cloning, and monitoring.
Easy integration: Drivers for custom use cases can be developed with ease.

Examples of CSI Drivers:

AWS EBS CSI Driver: ebs.csi.aws.com
GCE PD CSI Driver: pd.csi.storage.gke.io
Azure Disk CSI Driver: disk.csi.azure.com
Ceph CSI Driver
OpenEBS CSI Drivers (e.g., for cStor, Jiva, etc.)
Portworx CSI, vSphere CSI

Note: Starting with Kubernetes 1.21, most in-tree volume plugins were officially deprecated, and CSI became the default for handling persistent volumes.

Special Cases: `hostPath` and `local` Storage

`hostPath`

Mounts a directory from the node directly into the pod.
Primarily used for testing or simple workloads.
In-tree only; there is no CSI implementation.
Caution: Unsuitable for production due to security risks and lack of scheduling guarantees.

`local` Volumes

Mounts a physical disk attached to a node.
Can be implemented as either in-tree or CSI-based, depending on the setup.
Useful for tightly coupled environments like on-premises clusters.
Works well with PersistentVolume and supports node affinity for proper pod scheduling.

Transitioning from In-Tree Drivers

While in-tree drivers served their purpose in the early stages of Kubernetes, they are now being deprecated. CSI plugins are the recommended approach for modern storage management. For example:

In-Tree Driver Example:

apiVersion: v1
kind: PersistentVolume
metadata:
  name: in-tree-pv
  # Name of the PersistentVolume resource.
spec:
  capacity:
    storage: 10Gi
    # Defines the size of the volume. This PV provides 10Gi of storage.
  accessModes:
    - ReadWriteOnce
    # The volume can be mounted as read-write by a single node.
  awsElasticBlockStore:
    # This is the legacy in-tree volume plugin for AWS EBS.
    # It allows mounting an existing AWS EBS volume into a pod.
    volumeID: vol-0abcd1234efgh5678
    # The unique ID of the EBS volume to be mounted.
    fsType: ext4
    # The filesystem type of the volume. This must match the filesystem on the EBS volume.

CSI Driver Example:

apiVersion: v1
kind: PersistentVolume
metadata:
  name: csi-pv
  # The name of the PersistentVolume resource.
spec:
  capacity:
    storage: 10Gi
    # Defines the storage size of the volume. This volume offers 10Gi of space.
  accessModes:
    - ReadWriteOnce
    # The volume can be mounted as read-write by only one node at a time.
  storageClassName: gp3-sc
  # The StorageClass to which this volume belongs.
  # This allows dynamic provisioning and matching with a PVC that requests 'gp3-sc'.
  csi:
    # This specifies the use of a Container Storage Interface (CSI) driver,
    # which is the recommended way to provision external storage in modern Kubernetes clusters.
    driver: ebs.csi.aws.com
    # The name of the CSI driver used for AWS EBS volumes.
    volumeHandle: vol-0abcd1234efgh5678
    # The unique ID of the EBS volume in AWS.
    # This is used by the driver to locate and attach the correct volume.
    fsType: ext4
    # The filesystem type to mount. This must match the actual filesystem on the EBS volume.

Key Takeaways:

In-Tree Drivers: These legacy solutions are tightly coupled with Kubernetes and being phased out.
CSI Plugins: The preferred method for storage integration, offering scalability and extensibility.
Dynamic Provisioning: CSI supports automated volume creation and lifecycle management via StorageClasses.
File, Block, and Object Storage:
- File and Block Storage: Mountable as volumes in Pods using CSI plugins.
- Object Storage: Not natively mountable; access via application-level SDKs or APIs is recommended.

Kubernetes supports CSI (Container Storage Interface) plugins for both file (NFS) and block storage options. These plugins are provided by storage vendors such as NetApp, Dell EMC, and cloud providers like AWS, Azure, and Google Cloud Platform (GCP). CSI plugins enable Kubernetes Pods to access file and block storage seamlessly, offering advanced features like dynamic provisioning, snapshots, and volume resizing.

For object storage solutions like Amazon S3, Azure Blob Storage, or Google Cloud Storage (GCS), Kubernetes does not natively support mounting object storage as volumes because object storage operates differently from file systems. Instead, it is recommended to use application-specific SDKs or APIs to interact with object storage. These SDKs allow applications to efficiently access and manage object storage for tasks such as retrieving files, uploading data, and performing operations like versioning or replication.

The distinction lies in the use case:

File and Block Storage: Designed for direct mounting and integration with Kubernetes workloads using CSI plugins.
Object Storage: Better suited for application-level access via APIs or SDKs, as it was not designed to be mounted like file systems.

By leveraging CSI plugins for file and block storage, and SDKs for object storage, you can make the most of modern, scalable storage options tailored to your Kubernetes workloads.

Earlier, Kubernetes supported a lot of built-in drivers, called in-tree plugins. But today, the ecosystem has fully moved to CSI drivers, which are the future-proof way to provision and consume persistent storage. So whatever storage you’re dealing with — AWS EBS, NFS, iSCSI — if you’re doing it the modern way, you’re doing it with a CSI driver.

Persistent Storage

Before diving into Persistent Volumes (PVs) and Persistent Volume Claims (PVCs), let's first discuss hostPath, a persistent storage option in Kubernetes. While Kubernetes does not generally recommend using hostPath due to its limitations and security concerns, it can still be useful in specific scenarios.

hostPath

What is hostPath?
A hostPath volume mounts files or directories from the host node’s filesystem directly into the Pod. hostPath volumes are node-specific, meaning they are limited to the node where the Pod is scheduled. All Pods running on the same node can access and share data stored in a hostPath volume. However, since each node has its own independent storage, Pods on different nodes cannot share the same hostPath volume, making it unsuitable for distributed workloads requiring cross-node data sharing.
Why is it Used?
It is used for scenarios such as debugging, accessing host-level files (logs, configuration files), or sharing specific host resources with containers.

Why Kubernetes Recommends Avoiding hostPath

Security Risks: Pods can access sensitive host files if hostPath is misconfigured.
Limited Portability: Since hostPath is tied to a node, it reduces flexibility in scheduling.
Better Alternatives: Kubernetes recommends using PersistentVolumes (PV) with PersistentVolumeClaims (PVC) or local PersistentVolumes, which offer better control and security. We will discuss these later in this lecture.

Learn more: Kubernetes Documentation on hostPath.

With emptyDir, all containers within a single pod can access the shared volume, but it is not accessible to other pods.
With hostPath, any pod running on the same node that mounts the same host directory path can access the same volume data, thus enabling cross-pod sharing on the same node.

Understanding `hostPath` in KIND: How Storage Works Under the Hood

When using KIND (Kubernetes IN Docker), it’s important to understand where your hostPath volumes are actually created — especially because Docker behaves differently across operating systems.

1. On Ubuntu/Linux

On Linux distributions like Ubuntu, Docker Engine runs natively on the host OS.
So when you define a hostPath volume, like /tmp/hostfile, it points directly to the host’s actual filesystem (i.e., your Ubuntu machine).
The path /tmp/hostfile truly exists on the Ubuntu host, and the container will mount that exact path into the Pod.

2. On macOS and Windows

Docker Engine does not run natively on macOS or Windows, since it requires a Linux kernel.
Docker Desktop creates a lightweight Linux VM internally (via HyperKit on macOS or WSL2 on Windows) to run the Docker Engine.
KIND then runs each Kubernetes node (control-plane, worker-1, worker-2) as a Docker container inside that Linux VM.
When you define a hostPath in a Pod spec (e.g., /tmp/hostfile), it does not point to your macOS or Windows host filesystem.
Instead, it points to the filesystem of the specific Docker container (the Kubernetes node) running that Pod.

So, technically, the hostPath volume is inside the container representing your worker node — not on your macOS/Windows host, and not even directly inside the lightweight Linux VM used by Docker Desktop.

Key Takeaway

Platform	Docker Engine Runs On	`hostPath` Points To
Ubuntu/Linux	Natively	Host's actual filesystem (e.g., `/tmp/hostfile`)
macOS/Windows	Linux VM via Docker	Filesystem inside the Kubernetes node container

Why This Matters

When testing hostPath on macOS/Windows using KIND, any file you write via the volume:

Exists only inside the worker node container.
Is not visible on your macOS/Windows host filesystem.
Will be lost if the KIND cluster or node container is destroyed.

This is important when you're simulating persistent storage, as hostPath is not portable across nodes and shouldn't be used in production — but is often used for demos or local testing.

Demo: hostPath

In this demonstration, we showcase how to use the hostPath volume type in Kubernetes to mount a file from the host node into a container.

We begin by creating the following Pod:

apiVersion: v1
kind: Pod
metadata:
  name: hostpath-example
spec:
  containers:
  - name: busybox-container
    image: busybox
    command: ["sh", "-c", "cat /data && sleep 3600"]
    # The container reads and prints the content of /data, then sleeps for 1 hour.
    volumeMounts:
    - mountPath: /data
      name: host-volume
      # Mounts the 'host-volume' to the /data path inside the container.
      # This gives the container access to the file on the host.
  volumes:
  - name: host-volume
    hostPath:
      path: /tmp/hostfile
      type: FileOrCreate
      # If /tmp/hostfile doesn't exist on the host, it is created as an empty file before being mounted.

With this configuration, the file /tmp/hostfile on the host becomes accessible inside the container at /data.

Now, let’s populate the file with content using the command below:

kubectl exec -it hostpath-example -- sh -c 'echo "Hey you!!" > /data'

Understanding hostPath Types

Kubernetes supports several hostPath volume types that define how paths on the host are managed. For detailed information on supported types such as Directory, File, Socket, and BlockDevice, refer to the official documentation:

Kubernetes Documentation - hostPath Volume Types

Verification Across Pods on the Same Node

Since hostPath uses the underlying node’s filesystem, the data can be shared between different pods only if they are scheduled on the same node.

To determine where the initial pod was scheduled:

kubectl get pods -o wide

Assuming the pod was created on a node named my-second-cluster-worker2, we can now schedule a new pod on the same node to validate data sharing:

apiVersion: v1
kind: Pod
metadata:
  name: hostpath-verify
spec:
  nodeName: my-second-cluster-worker2
  containers:
  - name: busybox-container
    image: busybox
    command: ["sh", "-c", "cat /data && sleep 3600"]
    volumeMounts:
    - mountPath: /data
      name: host-volume
  volumes:
  - name: host-volume
    hostPath:
      path: /tmp/hostfile
      type: FileOrCreate

To verify that the new pod can access the same file content:

kubectl exec hostpath-verify -- cat /data

You should see the output:

Hey you!!

This confirms that both pods are using the same file from the host node via hostPath.

Persistent Volumes (PVs) & Persistent Volume Claims (PVCs)

Persistent Volumes (PVs)

What is a PV?
A PV is a piece of storage in your cluster that has been provisioned either manually by an administrator or dynamically using Storage Classes.
Key Characteristics:
PVs exist independently of Pod lifecycles and can be reused or retained even after the Pod is deleted. They have properties such as capacity, access modes, and reclaim policies.

Persistent Volume Claims (PVCs)

What is a PVC?
A PVC is a request for storage by a user. It functions similarly to how a Pod requests compute resources. When a PVC is created, Kubernetes searches for a PV that meets the claim's requirements.
Binding Process:
1. Administrator: Provisions PVs (or sets up Storage Classes for dynamic provisioning).
2. Developer: Creates a PVC in the Pod specification requesting specific storage attributes.
3. Kubernetes: Binds the PVC to a suitable PV, thereby making the storage available to the Pod.

Pods rely on Node resources—such as CPU, memory, and network—to run containers. On the other hand, when a Pod requires persistent storage, it uses a PersistentVolumeClaim (PVC) to request storage from a PersistentVolume (PV), which serves as the actual storage backend. This separation of compute and storage allows Kubernetes to manage them independently, improving flexibility and scalability.

Understanding Scope & Relationships of PV and PVC in Kubernetes

In Kubernetes, PersistentVolumes (PVs) and PersistentVolumeClaims (PVCs) play a central role in persistent storage — but they differ in how they're scoped and used.

PVs are Cluster-Scoped Resources

A PersistentVolume (PV) is a cluster-wide resource, just like Nodes or StorageClasses.
This means it is not tied to any specific namespace, and it can be viewed or managed from anywhere within the cluster.
You can verify this using:
```
kubectl api-resources | grep persistentvolume
```
This shows that the resource persistentvolumes has no namespace, indicating it's cluster-scoped.

PVCs are Namespace-Scoped

A PersistentVolumeClaim (PVC), on the other hand, is a namespaced resource, just like Pods or Deployments.
This means it exists within a specific namespace and is only accessible by workloads (Pods) within that namespace.
You can verify this using:
```
kubectl api-resources | grep persistentvolumeclaim
```
This shows that persistentvolumeclaims are scoped within a namespace.

Why Is This Important?

Let’s say you have a namespace called app1-ns. If a PVC is created in app1-ns and binds to a PV, only Pods in app1-ns can use that PVC.

If a Pod in app2-ns tries to reference the same PVC, it will fail — because the PVC is invisible and inaccessible outside its namespace.

1-to-1 Binding Relationship Between PVC and PV

A PVC can bind to only one PV.
Similarly, a PV can be bound to only one PVC.
This is a strict one-to-one relationship, ensuring data integrity and predictable access control.
Once a PV is bound, its claimRef field is populated, and it cannot be claimed by any other PVC unless explicitly released.

claimRef is a field in a PersistentVolume (PV) that records which PersistentVolumeClaim (PVC) has successfully claimed it. It includes details like the PVC’s name and namespace. This field ensures that the PV is not mistakenly claimed by any other PVC, enforcing a one-to-one binding between the PV and its assigned PVC.

Additional Key Points

PVCs request storage; PVs fulfill that request if they match capacity, access mode, and storage class.
Once a PVC is bound, it remains bound until:
- The PVC is deleted.
- The PV is manually reclaimed or deleted (depending on the reclaim policy).
The reclaim policy (Retain, Delete, or deprecated Recycle) determines what happens to the PV after the PVC is deleted.

Example Scenario

Let’s say:

You create a PVC named data-pvc in the namespace app1-ns.
It binds to a cluster-scoped PV.
Only Pods in app1-ns can now reference this PVC.

If a Pod in app2-ns tries to mount this PVC, it will result in an error like:

persistentvolumeclaims "data-pvc" not found

Because from app2-ns's perspective, that PVC does not exist.

Kubernetes Persistent Storage Flow (Manual Provisioning)

Step	Role	Action	Details / Notes
1	Developer	Requests 5Gi persistent storage for a Pod.	May request via a PVC or through communication with the Kubernetes Admin.
2	Kubernetes Admin	Coordinates with Storage Admin for backend volume.	Backend storage could be SAN/NAS exposed via iSCSI, NFS, etc.
3	Storage Admin	Allocates a physical volume from a 500Ti storage pool.	May involve LUN creation, NFS export, etc., based on the infrastructure.
4	Kubernetes Admin	Creates a PersistentVolume (PV) representing the physical volume in Kubernetes.	Specifies capacity, `accessModes`, `volumeMode`, `storageClassName`, etc.
5	Developer	Creates a PersistentVolumeClaim (PVC) requesting 5Gi with specific access and volume modes.	PVC must match criteria defined in the PV.
6	Kubernetes	Binds PVC to a suitable PV if all parameters match.	Matching criteria include: storage class, access mode, volume mode, size, etc.
7	Pod	References the PVC in its volume definition and mounts it in a container.	PVC acts as an abstraction; Pod doesn’t interact with the PV directly.

Important Notes

PV is a cluster-scoped resource.
PVC is a namespaced resource.
One PV can be claimed by only one PVC (1:1 relationship).
The Pod must be in the same namespace as the PVC it is using.
Communication with physical storage is handled by either:
- In-tree drivers (legacy; e.g., awsElasticBlockStore, azureDisk)
- CSI drivers (modern; e.g., ebs.csi.aws.com, azurefile.csi.azure.com)

In many cases, developers are well-versed with Kubernetes and can handle the creation of PersistentVolumeClaims (PVCs) themselves. With the introduction of StorageClasses, the process of provisioning PersistentVolumes (PVs) has been automated—eliminating the need for Kubernetes administrators to manually coordinate with storage admins and pre-create PVs. When a PVC is created with a StorageClass, Kubernetes dynamically provisions the corresponding PV. We’ll explore StorageClasses in detail shortly.

Access Modes in Kubernetes Persistent Volumes

Persistent storage in Kubernetes supports various access modes that dictate how a volume can be mounted. Access modes essentially govern how the volume is mounted across nodes, which is critical in clustered environments like Kubernetes.

Access Mode	Description	Example Use Case	Type of Storage & Examples
ReadWriteOnce (RWO)	The volume can be mounted as read-write by a single node. Multiple Pods can access it only if they are on the same node.	Databases that require exclusive access but may run multiple replicas per node.	Block Storage (e.g., Amazon EBS, GCP Persistent Disk, Azure Managed Disks)
ReadOnlyMany (ROX)	The volume can be mounted as read-only by multiple nodes simultaneously.	Sharing static data like configuration files or read-only datasets across multiple nodes.	File Storage (e.g., NFS, Azure File Storage)
ReadWriteMany (RWX)	The volume can be mounted as read-write by multiple nodes simultaneously.	Content management systems, shared data applications, or log aggregation.	File Storage (e.g., Amazon EFS, Azure File Storage, On-Prem NFS)
ReadWriteOncePod (RWOP) (Introduced in v1.29)	The volume can be mounted as read-write by only one Pod across the entire cluster.	Ensuring exclusive access to a volume for a single Pod, such as in tightly controlled workloads.	Block Storage (e.g., Amazon EBS with `ReadWriteOncePod` enforcement)

Explanation of Storage Types

Block Storage

Block storage is ideal for databases and applications requiring low-latency, high-performance storage. It provides raw storage blocks that applications can format and manage as individual disks.

Examples: Amazon EBS, GCP Persistent Disk, Dell EMC Block Storage.
Key Characteristic: Block storage is generally node-specific and does not support simultaneous multi-node access.
Access Modes: Commonly used with ReadWriteOnce or ReadWriteOncePod, as these modes restrict access to a single node or Pod at a time.

Analogy: Block storage is like attaching a USB drive to a single computer—it provides fast, reliable storage but cannot be shared concurrently across multiple systems.

File Storage

File storage is designed for shared storage scenarios, where multiple Pods or applications need simultaneous access to the same data. It is mounted as a shared filesystem, making it ideal for distributed workloads.

Examples: Amazon EFS, Azure File Storage, On-Prem NFS (Network File System).
Key Characteristic: File storage is purpose-built for multi-node concurrent access.
Access Modes: File storage often supports modes like ReadOnlyMany or ReadWriteMany, allowing multiple Pods—across different nodes—to read from and write to the same volume.

Analogy: File storage works like a network drive, where multiple systems can access, update, and share files simultaneously.

Key Differences: Block Storage vs. File Storage

Multi-Node Access: Block storage is single-node focused, whereas file storage allows concurrent access across multiple nodes.
Access Modes: ReadWriteOnce or ReadWriteOncePod are typical for block storage, while ReadWriteMany is common for file storage due to its multi-node capabilities.
Use Cases:
- Block Storage: Databases, transactional systems, or workloads requiring exclusive and high-performance storage.
- File Storage: Shared workloads like web servers, content management systems, and applications requiring shared configurations or assets.

When evaluating storage options, it's important to align the access modes and storage type with the needs of the workload. For example, "Many" in an access mode (ReadOnlyMany or ReadWriteMany) usually signals that the underlying storage is file-based and optimized for shared use.

Reclaim Policies in Kubernetes

Reclaim policies define what happens to a PersistentVolume (PV) when its bound PersistentVolumeClaim (PVC) is deleted. The available policies are:

1. Delete (Common for Dynamically Provisioned Storage)

When the PVC is deleted, the corresponding PV and its underlying storage resource (e.g., cloud disk, block storage) are automatically deleted.
This is useful in cloud environments where storage resources should be freed when no longer in use.

🔹 Example Use Case:

AWS EBS, GCP Persistent Disk, Azure Disk – Storage dynamically provisioned via CSI drivers gets deleted along with the PV, preventing orphaned resources.

2. Retain (Manual Intervention Needed for Reuse)

When the PVC is deleted, the PV remains in the cluster but moves to a "Released" state.
The data is preserved, and manual intervention is required to either:
- Delete and clean up the volume.
- Rebind it to another PVC by manually removing the claim reference (claimRef).

🔹 Example Use Case:

Auditing & Compliance: Ensures data is retained for logs, backups, or forensic analysis.
Manual Data Recovery: Useful in scenarios where storage should not be automatically deleted after PVC removal.

3. Recycle (Deprecated in Kubernetes v1.20+)

This policy would automatically wipe the data (using a basic rm -rf command) and make the PV available for new claims.
It was removed in favor of dynamic provisioning and more secure, customizable cleanup methods.

🔹 Why Deprecated?

Lacked customization for secure erasure methods.
Didn't support advanced cleanup operations (e.g., snapshot-based restoration).

Choosing the Right Reclaim Policy

Reclaim Policy	Behavior	Best Use Case	Common in
Delete	Deletes PV and storage resource when PVC is deleted.	Cloud-based dynamically provisioned storage.	AWS EBS, GCP PD, Azure Disk.
Retain	Keeps PV and storage, requiring manual cleanup.	Backup, auditing, manual data recovery.	On-prem storage, long-term retention workloads.
Recycle (Deprecated)	Cleans volume and makes PV available again.	(Not recommended)	Previously used in legacy systems.

PVC and PV Binding Conditions

For a PersistentVolumeClaim (PVC) to bind with a PersistentVolume (PV) in Kubernetes, the following conditions must be met:

Matching Storage Class
- The storageClassName of the PVC and PV must match.
- If the PVC does not specify a storage class, it can bind to a PV without a storage class.
Access Mode Compatibility
- The access mode requested by the PVC (ReadWriteOnce, ReadOnlyMany, ReadWriteMany) must be supported by the PV.
Sufficient Storage Capacity
- The PV’s storage must be equal to or greater than the requested capacity in the PVC.
Volume Binding Mode
- If set to Immediate, the PV binds as soon as a matching PVC is found.
- If set to WaitForFirstConsumer, binding happens only when a pod using the PVC is scheduled.
PV Must Be Available
- The PV must be in the Available state (i.e., not already bound to another PVC).
- If the PV is already bound, it cannot be reused unless manually released.
Matching Volume Mode

Volume Modes define how a Persistent Volume (PV) is presented to a Pod:
1. Block: Provides raw, unformatted storage for the Pod. The application handles formatting and usage.
2. Filesystem: Presents a formatted volume, ready for file-level operations.
Matching Modes:
- A PVC requesting volumeMode: Block must match a PV with volumeMode: Block.
- A PVC requesting volumeMode: Filesystem must match a PV with volumeMode: Filesystem.
Use Case for volumeMode: Block: This is typically used when an application, such as a database (e.g., PostgreSQL, MySQL), needs direct control over disk formatting, partitioning, or low-level I/O optimizations.

This ensures compatibility between Pods and their storage.
Claim Reference (Manual Binding Cases)
- If the PV has a claimRef field, it can only bind to the specific PVC mentioned in that field.

These conditions ensure a seamless and reliable binding process, providing persistent storage to Kubernetes workloads.

Summary Table: PVC and PV Binding Conditions

Condition	Requirement for Binding
Storage Class Match	`storageClassName` of PVC and PV must match (or both can be empty).
Access Mode Compatibility	PVC’s requested access mode must be supported by PV.
Sufficient Capacity	PV’s storage must be ≥ PVC’s requested capacity.
Volume Binding Mode	Either `Immediate` or `WaitForFirstConsumer`.
Volume State	PV must be in `Available` state to bind.
Matching Volume Mode	PVC and PV must have the same `volumeMode` (`Filesystem` or `Block`).
Claim Reference	If PV has a `claimRef`, it can only bind to that specific PVC.

Example Table: PVC vs. PV Matching

Condition	PVC Requirement	PV Must Have
Storage Capacity	`size: 10Gi`	`size ≥ 10Gi`
Access Mode	`ReadWriteMany`	`ReadWriteMany`
Storage Class	`fast-ssd`	`fast-ssd`
Volume State	`Unbound`	`Available`
Volume Mode	`Filesystem`	`Filesystem`

Critical Note for KIND/Minikube Users

If you're following along with this course, chances are you’ve installed KIND (Kubernetes IN Docker). KIND comes with a pre-configured default StorageClass out of the box.

If you're using Minikube instead, it's a good idea to check whether your cluster also includes a default StorageClass. You can verify this using the following command:

kubectl get storageclasses

Example output:

NAME                 PROVISIONER             RECLAIMPOLICY   VOLUMEBINDINGMODE      ALLOWVOLUMEEXPANSION   AGE
standard (default)   rancher.io/local-path   Delete          WaitForFirstConsumer   false                  27d

Why Modify the Default Storage Class?

The default storage class (standard) interferes with our demo of Persistent Volumes (PVs) and Persistent Volume Claims (PVCs). For this reason, we will temporarily delete it. However, before deleting it, we’ll take a backup of the YAML configuration. This will allow us to recreate the storage class later when moving to the Storage Classes section.

Steps to Back Up and Delete the Storage Class

Backup the Default Storage Class Configuration: Use the following command to back up the configuration into a file named sc.yaml in your current working directory:
```
kubectl get sc standard -o yaml > sc.yaml
```
- This ensures we can recreate the standard storage class later as needed.
Delete the Storage Class: Now, delete the standard storage class to prevent interference with the PV/PVC demo:
```
kubectl delete sc standard
```
Example output:
```
storageclass.storage.k8s.io "standard" deleted
```

By following these steps, we ensure that the default configuration doesn’t disrupt our hands-on exercises and we can restore it later when necessary.

Demo: Persistent Volumes and PVCs with Reclaim Policy

Step 1: Create a Persistent Volume (PV)

Create a file (for example, pv.yaml) with the following content:

apiVersion: v1                       # Kubernetes API version
kind: PersistentVolume              # Defines a PersistentVolume resource
metadata:
  name: example-pv                  # Unique name for the PV
spec:
  capacity:
    storage: 5Gi                    # Total storage provided (5 GiB)
  accessModes:
    - ReadWriteOnce                # Volume can be mounted as read-write by a single node at a time
  persistentVolumeReclaimPolicy: Retain  # Retain the volume and data even when the PVC is deleted
  hostPath:
    path: /mnt/data                # Uses a directory on the node (for demo purposes only)

Sure! Here's an improved and clearer version of your note:

Note: When the ReclaimPolicy is set to Retain, the PersistentVolume (PV) and its data will not be deleted even if the associated PersistentVolumeClaim (PVC) is removed. This means the storage is preserved for manual recovery or reassignment, and must be manually handled by an administrator before it can be reused.

Apply the PV:

kubectl apply -f pv.yaml

Verify the PV:

kubectl get pv
kubectl describe pv example-pv

Step 2: Create a Persistent Volume Claim (PVC)

Create a file (for example, pvc.yaml) with the following content:

apiVersion: v1                       # Kubernetes API version
kind: PersistentVolumeClaim         # Defines a PVC resource
metadata:
  name: example-pvc                 # Unique name for the PVC
spec:
  accessModes:
    - ReadWriteOnce                # Request volume to be mounted as read-write by a single node
  resources:
    requests:
      storage: 2Gi                 # Ask for at least 2Gi of storage (must be ≤ PV capacity)

Key Point:
Since this PVC doesn’t explicitly specify a StorageClass, it will bind to a compatible PV if available. In this demo, the PV created above offers 5Gi, making it a suitable candidate for a 2Gi claim.

Apply the PVC:

kubectl apply -f pvc.yaml

Verify the PVC status:

kubectl get pvc
kubectl describe pvc example-pvc

Step 3: Create a Pod That Uses the PVC

Create a file (for example, pod.yaml) with the following content:

apiVersion: v1                       # Kubernetes API version
kind: Pod                           # Defines a Pod resource
metadata:
  name: example-pod                 # Unique name for the Pod
spec:
  containers:
    - name: nginx-container         # Name of the container
      image: nginx                  # Container image to use
      volumeMounts:
        - mountPath: /usr/share/nginx/html  # Directory inside the container where the volume will be mounted
          name: persistent-storage  # Logical name for the volume mount
  volumes:
    - name: persistent-storage      # Volume's name referenced above
      persistentVolumeClaim:
        claimName: example-pvc      # Bind this volume to the previously created PVC

Important:
When this Pod is created, Kubernetes will bind the PVC to the appropriate PV (if not already bound) and mount the volume. At this point, the PVC status should change from "Pending" to "Bound".

Apply the Pod:

kubectl apply -f pod.yaml

Verify the Pod and its Volume Attachment:

kubectl describe pod example-pod

Final Verification

After creating these resources, use the following commands to check that everything is in order:

Persistent Volumes:

kubectl get pv
kubectl describe pv example-pv

Persistent Volume Claims:

kubectl get pvc
kubectl describe pvc example-pvc

Pod Details:
```
kubectl describe pod example-pod
```

By following these steps, you’ll see that the PVC is bound to the PV and the Pod successfully mounts the storage. This demo illustrates how the Retain reclaim policy preserves data on the PV and how the dynamic binding between PVCs and PVs works within Kubernetes.

Storage Classes & Dynamic Provisioning

What is a Storage Class?

A Storage Class in Kubernetes is a way to define different storage configurations, enabling dynamic provisioning of Persistent Volumes (PVs). It eliminates the need to manually pre-create PVs and provides flexibility for managing storage across diverse workloads.

Purpose: Storage Classes define storage backends and their parameters, such as disk types, reclaim policies, and binding modes.
Dynamic Provisioning: When a Persistent Volume Claim (PVC) is created, Kubernetes uses the referenced Storage Class to automatically provision a corresponding PV.
Flexibility: Multiple Storage Classes can coexist in a Kubernetes cluster, allowing administrators to tailor storage types for varying application needs (e.g., high-performance SSDs, low-cost storage, etc.).

Why Is a Storage Class Required?

Simplifies the storage lifecycle by automating PV creation using dynamic provisioning.
Offers flexibility to define and manage multiple storage tiers.
Optimizes storage resource allocation, especially in environments spanning multiple Availability Zones (AZs).

StorageClass takes over the role of provisioning PVs dynamically, replacing many of the static configurations you used to define in PVs manually. But not everything from PV moves into the StorageClass—some things like access modes, size, volumeMode still come from PVC.

Example Storage Classes

Below are two examples of AWS EBS Storage Classes, demonstrating how multiple classes can coexist in the same cluster:

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: ebs-sc-gp3  # Name of the StorageClass for AWS EBS gp3 volumes.
provisioner: ebs.csi.aws.com  # Specifies the CSI driver for AWS EBS.
parameters:
  type: gp3  # Defines the volume type as gp3 (general purpose SSD with configurable performance).
reclaimPolicy: Delete  # Deletes the provisioned volume when the PVC is deleted.
volumeBindingMode: WaitForFirstConsumer  # Delays volume creation until the Pod is scheduled.

apiVersion: storage.k8s.io/v1
kind: StorageClass
metadata:
  name: ebs-sc-io1  # Name of the StorageClass for AWS EBS io1 volumes.
provisioner: ebs.csi.aws.com  # Specifies the CSI driver for AWS EBS.
parameters:
  type: io1  # Defines the volume type as io1 (high-performance SSD).
reclaimPolicy: Delete  # Deletes the provisioned volume when the PVC is deleted.
volumeBindingMode: WaitForFirstConsumer  # Ensures the volume is created in the same AZ as the Pod.

Key Points

Reclaim Policy:
- The Delete reclaim policy ensures that dynamically provisioned volumes are automatically cleaned up when their corresponding PVCs are deleted.
- This prevents orphaned resources and is the most common choice for dynamically provisioned storage.
WaitForFirstConsumer:

In a Kubernetes cluster spanning multiple Availability Zones (AZs), EBS volumes and EC2 instances are AZ-specific resources.
If a volume is immediately provisioned in one AZ when a PVC is created, and the Pod using the PVC is scheduled in another AZ, the volume cannot be mounted.
The WaitForFirstConsumer mode ensures that the volume is created only after the Pod is scheduled, ensuring both the Pod and the volume are in the same AZ.
This prevents inefficiencies and reduces unnecessary costs for resources provisioned in the wrong AZ.

Dynamic Provisioning in Action

Let’s see how the ebs-sc-gp3 Storage Class is used with a PVC, a dynamically provisioned PV, and a Pod.

Persistent Volume Claim (PVC)

The PVC requests dynamic provisioning by referencing the ebs-sc-gp3 Storage Class.

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: ebs-csi-pvc  # Name of the PVC to be used by Pods.
spec:
  accessModes:
    - ReadWriteOnce  # The volume can be mounted as read-write by a single node.
  resources:
    requests:
      storage: 10Gi  # Minimum storage capacity requested.
  storageClassName: ebs-sc-gp3  # References the gp3 StorageClass for dynamic provisioning.

Persistent Volume (PV)

This is an example of a PV dynamically created by the CSI driver when the above PVC is applied.

apiVersion: v1
kind: PersistentVolume
metadata:
  name: ebs-csi-pv  # Name of the dynamically provisioned Persistent Volume.
spec:
  capacity:
    storage: 10Gi  # Defines the storage capacity for the volume.
  volumeMode: Filesystem  # Specifies the volume is presented as a filesystem (default mode).
  accessModes:
    - ReadWriteOnce  # Restricts volume to a single node for read-write operations.
  persistentVolumeReclaimPolicy: Delete  # Automatically deletes the volume when the PVC is deleted.
  storageClassName: ebs-sc-gp3  # Matches the StorageClass that provisioned this PV.
  csi:
    driver: ebs.csi.aws.com  # The AWS EBS CSI driver responsible for provisioning this volume.
    volumeHandle: vol-0abcd1234efgh5678  # Identifies the volume in the AWS backend.
    fsType: ext4  # The filesystem type for the volume.

Pod Using PVC

The Pod dynamically mounts the volume provisioned by the PVC.

apiVersion: v1
kind: Pod
metadata:
  name: ebs-csi-pod  # Name of the Pod.
spec:
  containers:
    - name: app-container  # Name of the container in the Pod.
      image: nginx  # The container image to run.
      volumeMounts:
        - mountPath: /usr/share/nginx/html  # Mounts the volume at this path inside the container.
          name: ebs-storage  # References the volume defined in the Pod spec.
  volumes:
    - name: ebs-storage  # Volume name referenced in the container's volumeMounts.
      persistentVolumeClaim:
        claimName: ebs-csi-pvc  # Links the volume to the PVC created earlier.

Key Takeaways

Storage Classes simplify storage management in Kubernetes, allowing dynamic provisioning of Persistent Volumes based on application needs.
The reclaimPolicy: Delete ensures proper cleanup of volumes once they are no longer needed.
The WaitForFirstConsumer binding mode optimizes placement and ensures resources like EBS volumes and Pods are aligned in multi-AZ environments.
By combining Storage Classes, PVCs, and dynamic provisioning, Kubernetes provides a powerful and flexible storage solution for managing workloads efficiently.

Demo: Storage Class

Step 1: Reapply the Storage Class

Before proceeding with the demo, we need to restore the StorageClass configuration that we backed up (sc.yaml). Run the following command to reapply it:

kubectl apply -f sc.yaml

This re-establishes the default standard StorageClass in your KIND cluster.

Step 2: Create the PersistentVolumeClaim (PVC)

Below is the YAML to create a PVC. It requests storage but does not explicitly reference any StorageClass:

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: example-pvc  # Name of the PersistentVolumeClaim
spec:
  accessModes:
    - ReadWriteOnce  # The volume can be mounted as read-write by a single node.
  resources:
    requests:
      storage: 2Gi  # Requests a minimum of 2Gi storage capacity.

Key Explanation:

Even though we didn’t specify a StorageClass, Kubernetes defaults to using the standard StorageClass (if one is configured as the default).
The status of the PVC will remain as "Pending" initially since no Persistent Volume (PV) is created at this point.

To understand why the PVC is pending, describe the StorageClass with:

kubectl describe sc standard

You’ll see that the standard StorageClass is configured as default:

metadata:
  annotations:
    storageclass.kubernetes.io/is-default-class: "true"
provisioner: rancher.io/local-path
reclaimPolicy: Delete
volumeBindingMode: WaitForFirstConsumer

Step 3: Understand VolumeBindingMode

The WaitForFirstConsumer mode plays a critical role:

It delays PV creation until a Pod is scheduled, ensuring cost optimization and proper resource placement.
For example, in multi-AZ environments like AWS, if the PVC triggers volume creation in AZ-1 but the Pod is scheduled in AZ-2, the volume won’t be accessible. WaitForFirstConsumer avoids this by creating the volume only after a Pod is scheduled, ensuring both the Pod and volume are in the same AZ.

Step 4: Create a Pod Using the PVC

Below is the YAML to create a Pod that uses the PVC:

apiVersion: v1
kind: Pod
metadata:
  name: example-pod  # Name of the Pod
spec:
  containers:
    - name: nginx-container  # Container name
      image: nginx  # The container image to use
      volumeMounts:
        - mountPath: /usr/share/nginx/html  # Mounts the volume to this path in the container
          name: persistent-storage  # References the volume defined in the Pod
  volumes:
    - name: persistent-storage  # Name of the volume
      persistentVolumeClaim:
        claimName: example-pvc  # Links the PVC to the Pod volume

Key Explanation:

Once the Pod is created, Kubernetes finds the PVC (example-pvc) and provisions a PV using the default standard StorageClass.
The PVC status changes to Bound, and a new PV is created and attached to the Pod.

Step 5: Verify the Status

Run the following commands to check the status of PVs and PVCs:

Check PVs:

kubectl get pv

Example output:

NAME                                       CAPACITY   ACCESS MODES   RECLAIM POLICY   STATUS   CLAIM                 STORAGECLASS   AGE
pvc-24d1f4ee-d3f8-40eb-8120-21f232087a19   2Gi        RWO            Delete           Bound    default/example-pvc   standard       6m

Check PVCs:

kubectl get pvc

Example output:

NAME          STATUS   VOLUME                                     CAPACITY   ACCESS MODES   STORAGECLASS   AGE
example-pvc   Bound    pvc-24d1f4ee-d3f8-40eb-8120-21f232087a19   2Gi        RWO            standard       6m

Key Takeaways

Default StorageClass:
- If no StorageClass is specified in the PVC, Kubernetes uses the default StorageClass (standard, in this case).
- The is-default-class annotation ensures it acts as the default.
VolumeBindingMode (WaitForFirstConsumer):
- Prevents PV creation until a Pod is scheduled, optimizing resource placement and cost in multi-AZ environments.
Reclaim Policy (Delete):
- Automatically deletes PVs once their associated PVCs are deleted, preventing storage clutter.

By following these steps, you can understand how dynamic provisioning works in Kubernetes with StorageClasses, PVCs, and Pods.

ConfigMaps

Why Do We Need ConfigMaps?

In real-world Kubernetes deployments:

Maintaining a large number of hardcoded environment variables in Pod specs can become unmanageable.
You may want to update configuration without rebuilding your container image.
You might need to inject configuration data via environment variables, CLI arguments, or mounted files.

ConfigMaps allow you to decouple configuration from your container images, making your applications more portable and easier to manage.

What is a ConfigMap?

A ConfigMap is a Kubernetes API object used to store non-confidential key-value configuration data.

Pods can consume ConfigMaps in three primary ways:

As environment variables
As command-line arguments (Less Common)
As configuration files via mounted volumes

Important: ConfigMaps do not provide encoding. For sensitive information, use a Secret instead.

What are Environment Variables?

Environment variables are key-value pairs used by the operating system and applications to store configuration settings. They help control how processes behave without modifying the underlying code.

Example on a Linux system:

export APP_NAME=frontend
export ENVIRONMENT=production

You can access these values using the echo command:

echo $APP_NAME     # Output: frontend
echo $ENVIRONMENT  # Output: production

These variables are commonly used in shell scripts or passed to applications during execution to configure them dynamically.

Without ConfigMap: Hardcoded Environment Variables

apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend-deploy
spec:
  replicas: 3
  selector:
    matchLabels:
      app: frontend
  template:
    metadata:
      labels:
        app: frontend
    spec:
      containers:
        - name: frontend-container
          image: nginx
          env:
            - name: APP
              value: frontend
            - name: ENVIRONMENT
              value: production

While this works, hardcoding environment variables is not scalable or reusable across environments.

Demo 1: Using ConfigMap as Environment Variables

For this demo, we’ll build on the frontend-deploy configuration introduced in Day 12 of this course. If you'd like a deeper understanding of Kubernetes Services, feel free to explore the following resources:

Step 1: Create ConfigMap

apiVersion: v1  # Defines the API version for the Kubernetes object.
kind: ConfigMap  # Declares this resource as a ConfigMap.
metadata:
  name: frontend-cm  # The name used to reference this ConfigMap in pods or other resources.
data:
  APP: "frontend"  # Key-value pair representing configuration data (e.g., application name).
  ENVIRONMENT: "production"  # Key-value pair used to define the deployment environment.

Apply:

kubectl apply -f frontend-cm.yaml

Note: Always apply the ConfigMap before the Deployment, so that the pods can reference and consume the configuration data during startup.

Step 2: Reference ConfigMap in Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend-deploy  # Name of the Deployment resource
spec:
  replicas: 3  # Number of pod replicas to maintain
  selector:
    matchLabels:
      app: frontend  # Selector to match pods managed by this Deployment
  template:
    metadata:
      labels:
        app: frontend  # Label assigned to pods created by this Deployment
    spec:
      containers:
      - name: frontend-container  # Name of the container within each pod
        image: nginx  # Using the official Nginx image
        env:
        - name: APP  # Environment variable name inside the container
          valueFrom:
            configMapKeyRef:
              name: frontend-cm  # Name of the ConfigMap from which the value is pulled
              key: APP  # Key in the ConfigMap whose value is used for this environment variable
        - name: ENVIRONMENT  # Another environment variable inside the container
          valueFrom:
            configMapKeyRef:
              name: frontend-cm
              key: ENVIRONMENT

        # NOTE:
        # The value of key "APP" will be picked up from the key "APP" in the ConfigMap named "frontend-cm".
        # The 'name' field here (APP) is the environment variable name that will be visible inside the container.
        # It does NOT need to match the 'key' from the ConfigMap.
        # For example:
        # - You could write: name: SERVICE and key: APP
        # - Inside the container, the environment variable would be called SERVICE and hold the value of APP from the ConfigMap.

Apply:

kubectl apply -f frontend-deploy.yaml

Verification

Pick a Pod from the Deployment:

kubectl get pods -l app=frontend

Then exec into one of them:

kubectl exec -it <pod-name> -- printenv | grep -E 'APP|ENVIRONMENT'

Expected Output:

APP=frontend
ENVIRONMENT=production

NOTE: I forgot to cover this in the demo, but you can also create a ConfigMap imperatively using the kubectl create configmap command.
For example:

kubectl create configmap <name-of-configmap> --from-literal=key1=value1 --from-literal=key2=value2

A real-world example would be:

kubectl create configmap frontend-cm --from-literal=APP=frontend --from-literal=ENVIRONMENT=production

This method is quick and useful for creating simple ConfigMaps imperatively from the command line, without needing to write and apply a YAML manifest.

When to Use Imperative vs Declarative Approach

Imperative Commands (kubectl create configmap) are best when you:
- Need to quickly create a ConfigMap for testing or small demos.
- Are experimenting or working interactively.
- Don't need to track the resource in version control (like Git).
Declarative Approach (YAML manifests + kubectl apply -f) is preferred when you:
- Are working in production environments.
- Want your ConfigMaps (and all Kubernetes resources) to be version-controlled.
- Need better team collaboration, auditing, and repeatable deployments.

Rule of Thumb:
Use imperative for quick, temporary tasks.
Use declarative for production-grade, repeatable, and auditable setups.

Demo 2: Using ConfigMap as a Configuration File (Volume Mount)

For this demo, we’ll build on the frontend-deploy configuration introduced in Day 12 of this course. If you'd like a deeper understanding of Kubernetes Services, feel free to explore the following resources:

Step 1: Modify ConfigMap to Include HTML File

apiVersion: v1
kind: ConfigMap
metadata:
  name: frontend-cm  # Name of the ConfigMap, used for reference in Pods or Deployments.
data:
  APP: "frontend"  # Key-value pair that can be used as an environment variable in a Pod.
  ENVIRONMENT: "production"  # Another environment variable for defining the environment.
  index.html: |  # When mounted as a volume, this key creates a file named 'index.html' with the following contents.
    <!DOCTYPE html>
    <html>
    <head><title>Welcome</title></head>
    <body>
      <h1>This page is served by nginx. Welcome to Cloud With VarJosh!!</h1>
    </body>
    </html>

The | tells YAML:

“Treat the following lines as a literal block of text. Preserve all line breaks and indentation exactly as they appear.”

In YAML, the | symbol is called a block scalar indicator — specifically, it's used for literal block style. This is especially useful when you're writing multi-line values, such as HTML, scripts, or configuration files inside a YAML field.

Apply:

kubectl apply -f frontend-cm.yaml

Step 2: Mount ConfigMap Volume in Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend-deploy  # Name of the Deployment
spec:
  replicas: 3  # Number of pod replicas
  selector:
    matchLabels:
      app: frontend  # Label selector to identify Pods managed by this Deployment
  template:
    metadata:
      labels:
        app: frontend  # Label to match with the selector above
    spec:
      containers:
      - name: frontend-container  # Name of the container
        image: nginx  # NGINX image to serve web content
        env:
        - name: APP
          valueFrom:
            configMapKeyRef:
              name: frontend-cm  # Name of the ConfigMap to pull the key from
              key: APP  # Key in the ConfigMap whose value will become the value of the env variable APP
        - name: ENVIRONMENT
          valueFrom:
            configMapKeyRef:
              name: frontend-cm
              key: ENVIRONMENT  # Key in the ConfigMap whose value becomes the value of ENVIRONMENT variable
        volumeMounts:
        - name: html-volume
          mountPath: /usr/share/nginx/html  # Mount point inside the container (default HTML dir for NGINX)
          readOnly: true  # Make the volume read-only
      volumes:
      - name: html-volume
        configMap:
          name: frontend-cm  # The ConfigMap being mounted as a volume
          items:
          - key: index.html  # The key in the ConfigMap to be used as a file
            path: index.html  # The filename that will be created inside the mount path

Understand that ConfigMaps are mounted as directories in Kubernetes. If you try to mount a ConfigMap at a path that is already a file (like /usr/share/nginx/html/index.html), the container will fail to start, because Kubernetes cannot mount a directory over an existing file.

That’s why we only use /usr/share/nginx/html as the mountPath, which is a directory, not a file.

If you omit the items: section, like this:

volumes:
  - name: html-volume
    configMap:
      name: frontend-cm

Then all the keys in the ConfigMap (APP, ENVIRONMENT, index.html) will be mounted as individual files inside /usr/share/nginx/html.

So inside the container, you’d get:

/usr/share/nginx/html/APP
/usr/share/nginx/html/ENVIRONMENT
/usr/share/nginx/html/index.html

If you only want index.html to be mounted (and not APP, ENVIRONMENT), you should use the items: section like this:

volumes:
  - name: html-volume
    configMap:
      name: frontend-cm
      items:
        - key: index.html
          path: index.html

What if you do want to mount the ConfigMap as a single file?

You cannot mount a directory on top of an existing file — but you can mount a specific key as a file using subPath. Here’s how:

volumeMounts:
  - name: html-volume                    # References the volume named 'html-volume' defined in the 'volumes' section
    mountPath: /usr/share/nginx/html/index.html  # The exact file path inside the container where the file should be mounted
    subPath: index.html                  # Mount only the 'index.html' key from the ConfigMap as a file (not the whole directory)

This tells Kubernetes:

“Mount only the file named index.html from the ConfigMap into the container at /usr/share/nginx/html/index.html.”

This works even if index.html already exists in the NGINX image because you're not replacing a file with a directory, but a file with a file.

Advantages of Using subPath

Allows fine-grained control over what file is mounted and where.
Helps you inject configuration (like index.html) without overriding entire directories.
Enables mixing static content from image and dynamic content from ConfigMap.

Disadvantages of subPath

The mounted file is not updated automatically if the ConfigMap changes (unless the pod is restarted).
Slightly more complex syntax.
If the mount path already exists and is a file, mounting may fail without proper use of subPath.

So, in summary:

Use mountPath: /usr/share/nginx/html to mount a directory.
Use subPath to mount a single file precisely over a specific path.
Use items: in the volume to control which keys from the ConfigMap are mounted.

Apply:

kubectl apply -f frontend-deploy.yaml

Step 3: Expose the Deployment using a NodePort Service

We’ll now expose our NGINX-based frontend deployment using a NodePort service. This allows access to the application from outside the cluster by targeting any worker node’s IP and the assigned NodePort.

NodePort Service Manifest

apiVersion: v1
kind: Service
metadata:
  name: frontend-svc  # Name of the service
spec:
  type: NodePort       # Exposes the service on a static port on each node
  selector:
    app: frontend      # Targets pods with this label
  ports:
    - protocol: TCP
      port: 80         # Port exposed inside the cluster (ClusterIP)
      targetPort: 80   # Port the container is listening on
      nodePort: 31000  # External port accessible on the node (must be between 30000–32767)

Apply the service:

kubectl apply -f frontend-svc.yaml

Verification

1. Get the Pod name

kubectl get pods -l app=frontend

2. Verify the `index.html` content inside the container

kubectl exec -it <pod-name> -- cat /usr/share/nginx/html/index.html

Expected Output:

<!DOCTYPE html>
<html>
<head><title>Welcome</title></head>
<body>
  <h1>This page is served by nginx. Welcome to Cloud With VarJosh!!</h1>
</body>
</html>

3. Access the Application via NodePort

You can access the application using:

http://<Node-IP>:31000

Or with curl:

curl http://<Node-IP>:31000

Replace <Node-IP> with the IP address of any node in your cluster (typically a worker node).

4. If You're Using KIND (Kubernetes in Docker)

If you've been following this course using a KIND cluster, the worker nodes are running inside a Docker container. In this case, KIND maps NodePorts to your host (Mac/Windows/Linux) via localhost.

For more details, refer to the Day 12 GitHub notes:
Setting up a KIND Cluster with NodePort Service

So you can directly access the app using:

http://localhost:31000

Or:

curl http://localhost:31000

This will display the content served by NGINX from the ConfigMap-mounted index.html.

Best Practices for ConfigMap

Avoid storing sensitive data in ConfigMaps.
Mount only the necessary keys using items to limit volume content.
Use version control tools (e.g., Kustomize, Helm) to manage changes.
Combine ConfigMaps with subPath if you want to mount specific files.

Kubernetes Secrets

Why Do We Need Secrets in Kubernetes?

In production environments, applications often require access to sensitive data such as:

Database credentials: Used by applications to authenticate securely with backend databases.
API tokens: Serve as secure keys to authorize and access APIs or third-party services.
SSH private keys: Enable secure, encrypted access to remote systems over SSH.
TLS certificates: Provide encryption and identity verification for secure network communication (e.g., HTTPS).

Storing these directly in your container image or Kubernetes manifests as plain text is insecure. Kubernetes Secrets provide a way to manage this data securely.

What is a Kubernetes Secret?

A Secret is a Kubernetes object used to store and manage sensitive information. Secrets are base64-encoded and can be made more secure by:

Enabling encryption at rest
Limiting RBAC access to Secrets
Using external secret managers like HashiCorp Vault, AWS Secrets Manager, or Sealed Secrets

Accessible to Pods via:

Environment variables
Mounted volumes (as files)
Command-line arguments (less common)

Note: By default, Kubernetes stores secrets unencrypted in etcd. It is recommended to enable encryption at rest for better security.

Important Distinction: Encoding vs. Encryption

It's crucial to understand that Kubernetes Secrets use base64 encoding, not encryption.
This means the data is obfuscated but not secured. Anyone who gains access to the Secret object can easily decode it.

Why Use Encoding (e.g., base64)?

Encoding is useful when you want to hide the data from casual observation, such as:

Preventing someone looking over your shoulder from instantly seeing a password.
Making binary data safe to transmit in systems that expect text.

However, encoding is not encryption. It's not secure by itself.

Anyone who has access to your encoded data can easily decode it.

For example, base64 is reversible using a simple decoding command.
If you need to protect sensitive data, you should use encryption or a Kubernetes Secret, which at least provides better handling and access controls.

We'll see how to encode and decode in the demo section.

Encoding vs. Encryption

Feature	Encoding	Encryption
Purpose	Data formatting for safe transport	Data protection and confidentiality
Reversible	Yes (easily reversible)	Yes (only with the correct key)
Security	Not secure	Secure
Use Case	Data transmission/storage compatibility	Protect sensitive data (passwords, tokens)
Example	Base64, URL encoding	AES, RSA, TLS
Tool Needed to Decode	None (any base64 tool)	Requires decryption key

Note: If you need to store sensitive data securely, consider enabling encryption at rest for Secrets in Kubernetes and restrict access using RBAC.

Demo 1: Injecting Secrets into a Pod

We’ll enhance the existing frontend-deploy and frontend-svc resources by securely injecting database credentials using a Kubernetes Secret.

For this demo, we’ll build on the frontend-deploy configuration introduced in Day 12 of this course. If you'd like a deeper understanding of Kubernetes Services, feel free to explore the following resources:

These resources provide clear examples and explanations of how Kubernetes Services work in real-world deployments.

Step 1: Create the Secret

Create a Secret manifest frontend-secret.yaml:

apiVersion: v1
kind: Secret  # Declares the resource type as a Secret.
metadata:
  name: frontend-secret  # Unique name for this Secret object.
type: Opaque  # 'Opaque' means this Secret contains user-defined (arbitrary) key-value pairs.

data:
  DB_USER: ZnJvbnRlbmR1c2Vy  # Base64-encoded value of 'frontenduser'
  DB_PASSWORD: ZnJvbnRlbmRwYXNz  # Base64-encoded value of 'frontendpass'

  # NOTE:
  # Values under the 'data:' section must be base64-encoded.
  # These can be referenced by Pods to inject as environment variables or mounted as files.

To generate the base64-encoded values:

echo -n 'frontenduser' | base64      # ZnJvbnRlbmR1c2Vy
echo -n 'frontendpass' | base64      # ZnJvbnRlbmRwYXNz

To decode the values on a Linux system:

echo 'ZnJvbnRlbmR1c2Vy' | base64 --decode   # frontenduser
echo 'ZnJvbnRlbmRwYXNz' | base64 --decode   # frontendpass

Note: The -n flag with echo ensures no trailing newline is added before encoding.

Apply the Secret:

kubectl apply -f frontend-secret.yaml

Step 2: Update the Deployment to Use the Secret

Here’s the updated deployment manifest (frontend-deploy.yaml) using the frontend-secret Secret as environment variables:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: frontend-deploy  # Name of the Deployment
spec:
  replicas: 1  # Run a single replica of the frontend Pod
  selector:
    matchLabels:
      app: frontend  # This selector ensures the Deployment manages only Pods with this label
  template:
    metadata:
      labels:
        app: frontend  # Label added to the Pod; matches the selector above
    spec:
      containers:
        - name: frontend-container  # Name of the container running inside the Pod
          image: nginx  # Using official NGINX image
          env:
            - name: DB_USER  # Environment variable DB_USER inside the container
              valueFrom:
                secretKeyRef:
                  name: frontend-secret  # Name of the Secret resource
                  key: DB_USER  # Key in the Secret to pull the value from
            - name: DB_PASSWORD  # Environment variable DB_PASSWORD inside the container
              valueFrom:
                secretKeyRef:
                  name: frontend-secret  # Same Secret object
                  key: DB_PASSWORD  # Another key from the Secret object

  # The environment variables DB_USER and DB_PASSWORD will be injected into the container at runtime.
  # Kubernetes will automatically base64-decode the values from the Secret and inject them as plain-text.
  # That means inside the container, these environment variables will appear as plain-text,
  # even though they are stored in base64-encoded format in the Kubernetes Secret object.

Apply the deployment:

kubectl apply -f frontend-deploy.yaml

Step 3: Verify Secret Injection

List the running Pods:

kubectl get pods -l app=frontend

Exec into one of the Pods:

kubectl exec -it <pod-name> -- /bin/sh

Print the environment variables:

echo $DB_USER       # Expected output: frontenduser
echo $DB_PASSWORD   # Expected output: frontendpass

Alternative: Mount Secret as Files

If you prefer to mount secrets as files (instead of environment variables), here’s how:

Update container spec:

Certainly! Here's your volumeMounts section with clear and concise inline comments:

        volumeMounts:
          - name: secret-volume               # Refers to the volume named 'secret-volume' defined in the 'volumes' section
            mountPath: /etc/secrets           # Directory inside the container where the secret files will be mounted
            readOnly: true                    # Ensures the mounted volume is read-only to prevent modifications from within the container

Additional Notes:

Each key in the Secret will be mounted as a separate file under /etc/secrets.
For example, if your Secret has DB_USER and DB_PASSWORD, you’ll find:
```
/etc/secrets/DB_USER
/etc/secrets/DB_PASSWORD
```
These files will contain the decoded plain-text values from the Secret.

Add volume to spec:

Certainly! Here's the corresponding volumes: section with detailed inline comments to pair with the volumeMounts section above:

      volumes:
        - name: secret-volume                # The volume name referenced in volumeMounts
          secret:
            secretName: frontend-secret     # The name of the Secret object from which to pull data

            # Optional: you could use 'items' here to mount only specific keys
            # For example:
            # items:
            #   - key: DB_USER
            #     path: db-user.txt
            #   - key: DB_PASSWORD
            #     path: db-password.txt

            # Without 'items', all keys from the Secret will be mounted as individual files
            # in the mountPath directory (e.g., /etc/secrets/DB_USER, /etc/secrets/DB_PASSWORD)

Best Practices for Using Kubernetes Secrets

Avoid storing secrets in Git repositories.
Use kubectl create secret or Helm to avoid manually encoding data.
Enable encryption at rest in etcd.
Use Role-Based Access Control (RBAC) to restrict access to secrets.
Use external secret managers for enhanced security and auditability.
Consider using subPath when mounting specific keys from a Secret as individual files.

Understanding Dynamic Updates with ConfigMaps and Secrets

Environment variables defined via env.valueFrom.configMapKeyRef or secretKeyRef are evaluated only once when the pod starts.
Updating the underlying ConfigMap or Secret does not affect the values already injected as environment variables in a running container.
ConfigMaps or Secrets mounted as volumes (without subPath) do reflect updates dynamically inside the container.
Kubernetes handles dynamic updates using symlinks to new file versions, but the application must re-read the files to detect changes.
When mounting individual keys using subPath, the file is copied, not symlinked, so updates to the ConfigMap or Secret will not propagate.
To enable live updates without restarting pods, prefer volume mounts without subPath and ensure the application supports hot reloading or use a config-reloader.

Conclusion

By the end of this MASTERCLASS, you will have a strong practical and conceptual understanding of:

How storage is managed in Docker using image layers, storage drivers, and volumes
The differences between ephemeral and persistent storage in Kubernetes
How to use volumes like emptyDir, hostPath, and CSI-backed Persistent Volumes
How ConfigMaps and Secrets interact with volume mounts and environment variables
The inner workings of Kubernetes' plugin-based architecture via CRI, CNI, and CSI
Best practices around PVs, PVCs, StorageClasses, access modes, reclaim policies, and binding conditions

Whether you're deploying applications in development clusters or managing production-grade workloads, this foundational understanding of Kubernetes storage equips you to design scalable, portable, and resilient systems.

References

Below are the official references, presented in the order concepts were covered:

Docker Storage Overview https://docs.docker.com/storage/
Docker Volume Types https://docs.docker.com/storage/volumes/
Docker Volume Drivers https://docs.docker.com/engine/extend/legacy_plugins/
Kubernetes Volumes https://kubernetes.io/docs/concepts/storage/volumes/
emptyDir Volume https://kubernetes.io/docs/concepts/storage/volumes/#emptydir
hostPath Volume https://kubernetes.io/docs/concepts/storage/volumes/#hostpath
Downward API https://kubernetes.io/docs/tasks/inject-data-application/downward-api-volume-expose-pod-information/
ConfigMaps https://kubernetes.io/docs/concepts/configuration/configmap/
Secrets https://kubernetes.io/docs/concepts/configuration/secret/
Persistent Volumes https://kubernetes.io/docs/concepts/storage/persistent-volumes/
Persistent Volume Claims https://kubernetes.io/docs/concepts/storage/persistent-volumes/#persistentvolumeclaims
StorageClasses https://kubernetes.io/docs/concepts/storage/storage-classes/
Volume Binding Mode https://kubernetes.io/docs/concepts/storage/storage-classes/#volume-binding-mode
Access Modes https://kubernetes.io/docs/concepts/storage/persistent-volumes/#access-modes
Volume Modes https://kubernetes.io/docs/concepts/storage/persistent-volumes/#volume-mode
Reclaim Policy https://kubernetes.io/docs/concepts/storage/persistent-volumes/#reclaiming
Container Storage Interface (CSI) https://kubernetes.io/docs/concepts/storage/volumes/#csi
CSI Drivers (List) https://kubernetes-csi.github.io/docs/drivers.html
CRI, CNI, and CSI Interfaces Overview https://kubernetes.io/docs/concepts/extend-kubernetes/compute-storage-net/

Name		Name	Last commit message	Last commit date
Latest commit History 7 Commits
images		images
README.md		README.md

CloudWithVarJosh/Storage-In-Kubernetes-Masterclass

Folders and files

Latest commit

History

Repository files navigation

Storage in Kubernetes MASTERCLASS

Video reference for the MASTERCLASS is the following:

⭐ Support the Project

Table of Contents

Introduction

Understanding Storage in Docker

Layers in a Dockerfile

Example: Layers in Our Dockerfile

How to Inspect Image Layers

How Docker Containers Use Image Layers

Storage Calculation Example

Handling Data Loss in Writable Layers

Need for Persistent Storage

Storage in Docker: How Does It Work?

1. Storage Drivers

2. Volume Drivers

How Docker Storage Works on macOS, Windows, and Linux

Linux

macOS and Windows

Understanding Docker Volumes

Where Are Docker Volumes Stored?

Demo: With Persistent Storage (Docker Volume)

Note for macOS and Windows Users

How to Access Volume Data on macOS:

Types of Docker Volumes: Which to Use When?

Kubernetes Core and Extended Architecture

Kubernetes Core Architecture

What is Kubernetes Core?

1️⃣ Control Plane Components

2️⃣ Node Components

Kubernetes Extensions: Beyond the Core

1️⃣ Plugins

CRI Plugins (Container Runtimes)

CNI Plugins (Networking)

CSI Plugins (Storage)

Responsibilities of CRI, CNI, and CSI in Kubernetes

2️⃣ Add-Ons

3️⃣ Third-Party Extensions

Deep Dive into Kubernetes Interfaces

Overview of Kubernetes Interfaces

Why Kubernetes Uses a Plugin-Based Architecture?

Key Takeaways

Ephemeral Storage

EmptyDir

Demo: emptyDir

Downward API

Why is it Used?

Demo: downwardAPI - Environment variables

Demo: downwardAPI - Files via Volumes

ConfigMaps & Secrets (To Be Discussed in Next Lecture)

Evolution of Storage in Kubernetes: From In-Tree to CSI Drivers

1. In-Tree Volume Plugins: The Legacy Model

Examples of In-Tree Plugins:

2. Container Storage Interface (CSI): The Modern Standard

Key Benefits of CSI:

Examples of CSI Drivers:

Special Cases: hostPath and local Storage

hostPath

local Volumes

Transitioning from In-Tree Drivers

Key Takeaways:

Persistent Storage

hostPath

Understanding hostPath in KIND: How Storage Works Under the Hood

1. On Ubuntu/Linux

2. On macOS and Windows

Key Takeaway

Why This Matters

Demo: hostPath

Persistent Volumes (PVs) & Persistent Volume Claims (PVCs)

Persistent Volumes (PVs)

Persistent Volume Claims (PVCs)

Understanding Scope & Relationships of PV and PVC in Kubernetes

PVs are Cluster-Scoped Resources

PVCs are Namespace-Scoped

Special Cases: `hostPath` and `local` Storage

`hostPath`

`local` Volumes

Understanding `hostPath` in KIND: How Storage Works Under the Hood

2. Verify the `index.html` content inside the container
