Replies: 2 comments 1 reply
-
Please use latest rolling ans show us logs covering the restart. |
Beta Was this translation helpful? Give feedback.
1 reply
-
Sorry didn‘t have time . Think will check next week |
Beta Was this translation helpful? Give feedback.
0 replies
Sign up for free
to join this conversation on GitHub.
Already have an account?
Sign in to comment
Uh oh!
There was an error while loading. Please reload this page.
-
Made a fresh install of 13.0.1.
After configuring reference picture , marks and digits and rebooting multiple times performance gets bad ...
Board is even not reacting well
Log is telling:
2022-11-30T15:18:12 [MAIN] =============================================================================================
2022-11-30T15:18:12 [MAIN] Branch: 'HEAD', Revision: b60c2d6, Date/Time: 2022-11-30 09:26, Web UI: Development-Branch: HEAD (Commit: b60c2d6)
2022-11-30T15:18:12 [MAIN] Reset reason: Exception/panic
2022-11-30T15:18:15 [MAIN] Initialization completed successfully!
2022-11-30T15:18:15 [TFLITE] Restarted due to an Exception/panic! Postponing first round start by 5 minutes to allow for an OTA or to fetch the log!
2022-11-30T15:18:15 [TFLITE] Setting logfile level to DEBUG until the next reboot!
2022-11-30T15:18:26 [MAIN SERVER] info_get_handler
2022-11-30T15:18:26 [MAIN SERVER] info_get_handler
2022-11-30T15:18:26 [MAIN SERVER] info_get_handler
2022-11-30T15:18:57 [MAIN SERVER] info_get_handler
2022-11-30T15:18:57 [MAIN SERVER] info_get_handler
2022-11-30T15:18:59 [MAIN SERVER] info_get_handler
2022-11-30T15:19:01 [MAIN SERVER] info_get_handler
2022-11-30T15:19:02 [MAIN SERVER] info_get_handler
My config :
[MakeImage]
;LogImageLocation = /log/source
WaitBeforeTakingPicture = 5
;LogfileRetentionInDays = 15
Brightness = 0
Contrast = 1
Saturation = 0
LEDIntensity = 35
ImageQuality = 12
ImageSize = VGA
FixedExposure = false
[Alignment]
InitialRotate = 95
InitialMirror = false
SearchFieldX = 20
SearchFieldY = 20
AlignmentAlgo = default
FlipImageSize = false
/config/ref0.jpg 382 76
/config/ref1.jpg 489 147
[Digits]
Model = /config/dig-cont_0600_s3.tflite
CNNGoodThreshold = 0.5
;LogImageLocation = /log/digit
;LogfileRetentionInDays = 3
main.dig1 264 124 34 62 false
main.dig2 305 124 34 62 false
main.dig3 345 124 34 62 false
main.dig4 382 124 34 62 0
main.dig5 417 124 34 62 0
;[Analog]
Model = /config/ana-cont_11.3.0_s2.tflite
;LogImageLocation = /log/analog
;LogfileRetentionInDays = 3
main.ana1 432 230 92 92 false
main.ana2 379 332 92 92 false
main.ana3 283 374 92 92 false
main.ana4 155 328 92 92 false
[PostProcessing]
main.DecimalShift = -2
main.AnalogDigitalTransitionStart = 9.2
PreValueUse = true
PreValueAgeStartup = 720
AllowNegativeRates = false
main.MaxRateValue = 1
;main.MaxRateType = AbsoluteChange
;main.ExtendedResolution = false
;main.IgnoreLeadingNaN = true
ErrorMessage = true
CheckDigitIncreaseConsistency = false
;[MQTT]
;Uri = mqtt://IP-ADRESS:1883
;MainTopic = wasserzaehler
;ClientID = wasser
;user = USERNAME
;password = PASSWORD
;SetRetainFlag = true
;HomeassistantDiscovery =
;MeterType =
;[InfluxDB]
;Uri = undefined
;Database =
;Measurement = undefined
;user = undefined
;password = undefined
[GPIO]
;IO0 = input disabled 10 false false
;IO1 = input disabled 10 false false
;IO3 = input disabled 10 false false
IO4 = built-in-led disabled 10 false false
;IO12 = external-flash-ws281x disabled 10 false false
;IO13 = input-pullup disabled 10 false false
LEDType = WS2812
LEDNumbers = 5
LEDColor = 150 150 150
[AutoTimer]
AutoStart = true
Intervall = 5
[DataLogging]
DataLogActive = false
DataLogRetentionInDays = 3
[Debug]
Logfile = 1
LogfileRetentionInDays = 3
[System]
TimeZone = CET-1CEST,M3.5.0,M10.5.0/3
;TimeServer = undefined
;AutoAdjustSummertime = false
;Hostname = undefined
SetupMode = false
12.0.1 ran very well.....
